2010 Hyundai Accent key

1FEATURES OF YOUR HYUNDAI
12
B070D03MC-GAT Disarmed Stage The system will be disarmed when the driver's or passenger's door is unlocked by depressing the button on the trans- mitter after the system was armed. After completion of the step above, the turn signal lights will blink twice toindicate that the system is disarmed. If any door, trunk lid (4 Door) / tail gate (3 Door) included, is not opened within 30 seconds, the system will be rearmed (For Europe).If any door, tail gate (3 Door) included, is not opened within 30 seconds, the system will be rearmed (Except Eu-rope). B070D02AMC
CAUTION:
Only the transmitter can disarm thearmed stage. If the transmitter doesnot disarm the system, it is neces- sary to take the following steps; Without immobilizer system: 1. Unlock and open the door with the key, which will cause the alarm to be activated.
2. Insert the key in the ignition key
cylinder and turn the ignition keyto "ON" position.
3. Wait for 30 seconds. With immobilizer system: 1. Unlock and open the door with the
key, which will cause the alarm to be activated.
2. Insert the key in the ignition key
cylinder and turn the ignition keyto "START" position.
After completing the steps above,the system will be disarmed.
!
NOTE: When the system is disarmed with the interior light switched to "DOOR", the interior light will illuminate for 30seconds.
CAUTION:
Do not change, alter or adjust thetheft-alarm system because it couldcause the theft-alarm system to mal- function and should only be ser- viced by an authorized Hyundaidealer. Malfunctions caused by improper alterations, adjustments or modifi-cations to the theft-alarm system are not covered by your vehicle manu- facturer warranty.
!

1
FEATURES OF YOUR HYUNDAI
13
B070E02MC-AAT Replacing the battery When the transmitter's battery begins to get weak, it may take several pusheson the button to lock or unlock the doors, and the LED will not light. Re- place the battery as soon as possible. Battery type : CR1220
1. Remove the screw with a phillips
screwdriver.
2. Carefully separate the case with a
flat-head screwdriver.
3. Remove the battery cover with a coin. OMC025004
- The weather is extremely cold.
- The transmitter is close to a radio
transmitter such as a radio station or an airport which can interfere with normal operation of the trans-mitter.
When the transmitter does not workcorrectly, open and close the doorwith the ignition key. If you have a problem with the transmitter, con- tact an authorized Hyundai Dealer. NOTE: Keep the transmitter away from wa- ter or any liquid. If the keyless entry system is inoperative due to expo-sure to water or liquids, it will not be covered by your manufacturer ve- hicle warranty. Replacement instructions:
B070F03A-GAT Keyless Entry System
(If Installed) Locking doors
1. Close all doors.
2. Push the button on the transmitter.
3. At the same time all doors lock, the
turn signal lights will blink once toindicate that the system is armed.
Unlocking doors 1. Push the button on the transmitter once more after all doors were locked.
2. At the same time all doors unlock,
the turn signal lights will blink twice to indicate that the system is dis- armed.
NOTE: The transmitter will not work if any of following occur:
- The ignition key is in ignition switch.
- You exceed the operating distance limit (10 m).
- The battery in the transmitter is weak.
- Other vehicles or objects may be
blocking the signal.

1FEATURES OF YOUR HYUNDAI
14
B060A02MC-GAT POWER WINDOWS (If Installed)
The power windows operate when the ignition key is in the "ON" position. The main switches are located on the driver's
armrest and control the front (4/3 Door)
and rear windows (4 Door) on both sides
of the vehicle. The windows may beopened by depressing the appropriate window switch and closed by pulling up the switch. To open the window on the
driver's side, press the switch (1) halfway down. The window moves as long as the switch is operated. To fully open thedriver's window automatically, press the switch fully down. In automatic operation, the window will fully open even if you letgo of the switch. To stop at the desired opening, pull up and release the switch.
4 Door 3 Door
OMC029048
!
WINDOW GLASS
B050A01MC-AAT
To lower or raise the window, turn the window regulator handle clockwise or counterclockwise. WARNING:
When opening or closing the win- dows, make sure your passenger'sarms, hands and body are safely out of the way.
3FDA2015
CAUTION:
An inappropriately disposed battery can be harmful to the environment and human health. Dispose the bat-tery according to your local law(s) or regulation.
!
4. Remove the old battery from the
case and note the polarity. Make sure the polarity of the new battery is the same (+side facing up), then insert it in the transmitter.

1
FEATURES OF YOUR HYUNDAI
15
!WARNING:
1) Be careful that someone's head, hands and body are not trapped by a closing window.
2) Never try to operate the main
switch on the driver's door andthe individual door window switch in opposing directions at the same time. If this is done, the windowwill stop and cannot be opened or closed.
3) Do not leave children alone in the car. Always remove the ignitionkey for their safety.
OMC025015
CLOSE
OPEN
In order to prevent operation of the passenger front (4/3 Door) and rear windows (4 Door), a window lock switch(2) is provided on the armrest of the
driver's door. To disable the power win- dows, press the window lock switch. Torevert to normal operation, press the window lock switch a second time. NOTE: The power windows can be operated for 30 seconds after the ignition key is turned to the "ACC" or "LOCK"positions, or removed from the igni- tion switch. If the front doors are opened during this 30 second pe-riod, the power windows can no longer be operated without the igni- tion key turned to the "ON" position.OMC029049
NOTE: While driving with the rear windows down or with the sunroof (if installed) in an open (or partially open) posi-
tion, your vehicle may demonstrate
a wind buffeting or pulsation
noise. This noise is a normal occur-rence and can be reduced or elimi- nated by taking the following ac-
tions. If the noise occurs with oneor both of the rear windows down,
partially lower both front windows
approximately one inch. If you ex-perience the noise with the sunroof open, slightly reduce the size of the sunroof opening.

1FEATURES OF YOUR HYUNDAI
20
B130A01A-AAT REAR SEAT ENTRY (3 Door) The front passenger's seatback should be tilted to enter the rear seat. By pulling up on the recliner control lever (1) at the outside of the frontpassenger's seat, the seatback will tilt forward and the seat will automatically slide forward.Rear seat occupants can tilt the front passenger's seatback by depressing the foot lever (2) as shown in the illus-tration. HTB258
(1)
(2)B100A01Y-AAT SEAT WARMER (If Installed) The seat warmer is provided to warm the front seats during cold weather.With the ignition key in the "ON" posi- tion, push either of the switches to warm the driver's seat or the passenger'sseat. During mild weather or under conditions that the operation of the seat warmer isnot needed, keep the switches in the "OFF" position.
OMC029033
B080G01A-GAT Adjusting Armrest Angle (Driver's side only) (If Installed)
OMC025031
The armrest will be raised or lowered manually. To raise the armrest, pull it up. To lower it, press the armrest down.

1
FEATURES OF YOUR HYUNDAI
29
*1) When the ignition key is turned from "OFF" position to "ON" within 1 minute.
*2) The switch returns to "ON" when you let go of the key.
*3) If the vehicle speed exceeds 9km/
h, the seat belt chime also sounds for about 1~2 minutes. If the vehicle speed is below 9km/h, 1 minute later the seat belt chimealso sounds for about 1~2 minutes.
NOTE: If the driver's seat belt is operated in this order "unbuckled

buckled



unbuckled" within 9 seconds after the seat belt is buckled, the seat belt warning light and chime will notactivate.
The seat belt warning light and chimewill activate to the following table.
B265E01MC-GAT
Seat Belt Warning Light
and Chime (E.C only)
User (Driver) Condition
Seat Belt WarningLight
Seat Belt Ignition Switch
Unbuckled ON Stay on until buckled up
Buckled ON Come on for 6 seconds
Unbuckled ON * 1
Blink until buckled up
START * 2
Blink until buckled up* 3
Buckled



Unbuckled
B180A01MC-GAT SEAT BELTS 3-Point System with Emergency Locking Retrac-torTo Fasten Your Belt
To fasten your seat belt, pull it out of the retractor and insert the metal tab into the buckle. There will be an audible "click" when the tab locks into thebuckle. The seat belt automatically adjusts to the proper length only after the lap beltis adjusted manually so that it fits snugly around your hips. If you lean forward in a slow, easy motion, the beltwill extend and let you move around. If there is a sudden stop or impact, how- ever, the belt will lock into position. It
B180A01NF will also lock if you try to lean forward too quickly. Check to make sure thatthe belt is properly locked and that the belt is not twisted. NOTE: If the seat belt is not fastened when the ignition key is turned from the "OFF" position to the "ON" position, the seat belt warning will activate toremind the driver to fasten the seat belt as follows. B260E01TB-GAT
Seat Belt Warning Light
(Except E.C)
The seat belt warning light blinks for about 6 seconds when the ignition key is turned from the "OFF" position to the "ON".

1
FEATURES OF YOUR HYUNDAI
43
!
o Although it is harmless, the fine
dust may cause skin irritation and should not be breathed for pro- longed periods. Wash your hands and face thoroughly after an acci-dent in which the pre-tensioner seat belts were activated.
CAUTION:
o Because the sensor that activates the SRS airbag is connected with pre-tensioner seat belt, the SRS airbag warning light on the instrument panel will illuminatefor approximately 6 seconds after the ignition key has been turned to the "ON" position, and then itshould turn off.
o If pre-tensioner seat belt is not
working properly, this warninglight will illuminate even if there is no malfunction of the SRS airbag.
! If the SRS airbag warning light does not illuminate when the igni-tion key is turned to "ON", or if it blinks for a second and remains illuminated after illuminating forapproximately 6 seconds, or if it illuminates while the vehicle is being driven, please have an au-thorized Hyundai dealer inspect the pre-tensioner seat belt or SRS airbag system as soon as pos-sible.
WARNING:
o Pre-tensioners are designed to operate only one time. After acti-vation, pre-tensioner seat beltsmust be replaced. All seat belts, of any type, should always be re- placed after they have been wornduring a collision.
o The pre-tensioner seat belt assem-
bly mechanisms become hot dur-ing activation. Do not touch the pre-tensioner seat belt assemblies for several minutes after they havebeen activated. o Do not attempt to inspect or re-
place the pre-tensioner seat belts yourself. This must be done by an authorized Hyundai dealer.
o Do not strike the pre-tensioner seat belt assemblies.
o Do not attempt to service or repair
the pre-tensioner seat belt system in any manner.
o Improper handling of the pre-
tensioner seat belt assemblies, andfailure to heed the warnings to not strike, modify, inspect, replace,service or repair the pre-tensioner seat belt assemblies may lead to improper operation or inadvertentactivation and serious injury.
o Always wear seat belts when driv-
ing or riding in a motor vehicle.
o If the vehicle or pre-tensioner seat belt must be discarded, contact anauthorized HYUNDAI dealer.

1
FEATURES OF YOUR HYUNDAI
47
The SRS consists of the following com- ponents: - Driver's Airbag Module
- Passenger's Front Airbag Module
- SRS Service Reminder Indicator (SRI)
- SRS Control Module (SRSCM)
The SRSCM continually monitors all elements while the ignition is "ON" to determine if a frontal or near-frontalimpact is severe enough to require airbag deployment. B240B01MC-GAT SRS Components and Functions
B240B01L
The SRS service reminder indicator (SRI) on the instrument panel will illumi-nate for about 6 seconds after the ignition key is turned to the "ON" posi- tion or after the engine is started, afterwhich the SRI should go out.
The airbag modules are located both inthe center of the steering wheel and in the front passenger's panel above the glove box. When the SRSCM detects aconsiderable impact to the front of the vehicle, it will automatically deploy the airbags.
B240B02L
