{ WARNING: Snow can trap engine exhaust under the vehicle.
This may cause exhaust gases to get inside.
Engine exhaust contains carbon monoxide (CO)
which cannot be seen or smelled. It can cause
unconsciousness and even death.
If the vehicle is stuck in the snow: .
Clear away snow from around the base of
your vehicle, especially any that is blocking
the exhaust pipe. .
Check again from time to time to be sure
snow does not collect there. .
Open a window about 5 cm (two inches) on
the side of the vehicle that is away from the
wind to bring in fresh air. .
Fully open the air outlets on or under the
instrument panel. .
Adjust the Climate Control system to a setting
that circulates the air inside the vehicle and
set the fan speed to the highest setting. See
Climate Control System in the Index.
(Continued)WARNING: (Continued) For more information about carbon monoxide, see
Engine Exhaust on page 3 ‑ 41 .
Snow can trap exhaust gases under your vehicle.
This can cause deadly CO (carbon monoxide) gas
to get inside. CO could overcome you and kill you.
You cannot see it or smell it, so you might not
know it is in your vehicle. Clear away snow from
around the base of your vehicle, especially any
that is blocking the exhaust.
Run the engine for short periods only as needed to
keep warm, but be careful.
To save fuel, run the engine for only short periods as
needed to warm the vehicle and then shut the engine
off and close the window most of the way to save heat.
Repeat this until help arrives but only when you feel
really uncomfortable from the cold. Moving about to
keep warm also helps.
If it takes some time for help to arrive, now and then
when you run the engine, push the accelerator pedal
slightly so the engine runs faster than the idle speed.
This keeps the battery charged to restart the vehicle
and to signal for help with the headlamps. Do this as
little as possible to save fuel.
6-29

Black plate (54,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Trailer Wiring Harness Heavy-Duty Trailer Wiring Harness Package
The vehicle has a seven-pin universal heavy-duty trailer
connector attached to the rear bumper beam next to the
integrated trailer hitch. The seven-wire harness contains the following trailer
circuits: .
Yellow: Left Stop/Turn Signal .
Dark Green: Right Stop/Turn Signal .
Brown: Taillamps .
White: Ground .
Light Green: Back-up Lamps .
Red: Battery Feed* .
Dark Blue: Trailer Brake*
*The fuses for these two circuits are installed in the
underhood electrical center, but the wires are not
connected. They should be connected by your dealer or
a qualified service center.
If charging a remote (non-vehicle) battery, press the
tow/haul mode button located at the end of the shift
lever. This will boost the vehicle system voltage and
properly charge the battery. If the trailer is too light for
tow/haul mode, turn on the headlamps as a second way
to boost the vehicle system and charge the battery.
6-54

Black plate (1,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Section 7 Service and Appearance CareService . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Accessories and Modifications . . . . . . . . . . . . . . . . . . 7-4
California Proposition 65 Warning . . . . . . . . . . . . . . . 7-5
California Perchlorate Materials
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Doing Your Own Service Work . . . . . . . . . . . . . . . . . . 7-6
Adding Equipment to the Outside of the
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Gasoline Octane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Gasoline Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
California Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Additives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Fuel E85 (85% Ethanol) . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Fuels in Foreign Countries . . . . . . . . . . . . . . . . . . . . . 7-10
Filling the Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
Filling a Portable Fuel Container . . . . . . . . . . . . . . . 7-13
Checking Things Under the Hood . . . . . . . . . . . . . . . 7-14
Hood Release . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-15
Engine Compartment Overview . . . . . . . . . . . . . . . . 7-16
Engine Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-17
Engine Oil Life System . . . . . . . . . . . . . . . . . . . . . . . . 7-20
Engine Air Cleaner/Filter . . . . . . . . . . . . . . . . . . . . . . . 7-22 Automatic Transmission Fluid . . . . . . . . . . . . . . . . . . 7-24
Cooling System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-27
Engine Coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-29
Engine Overheating . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-34
Overheated Engine Protection
Operating Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-37
Engine Fan Noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-37
Power Steering Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 7-38
Windshield Washer Fluid . . . . . . . . . . . . . . . . . . . . . . 7-39
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-40
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-43
Jump Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-44
All-Wheel Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-49
Rear Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-50
Front Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-51
Headlamp Aiming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-52
Bulb Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-54
High Intensity Discharge (HID) Lighting . . . . . . . . 7-54
LED Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-55
Back-Up Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-55
License Plate Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-56
Replacement Bulbs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-56
7-1

Black plate (52,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Headlamp Aiming The vehicle has a visual optical headlamp aiming
system. The aim of the headlamps have been preset at
the factory and should need no further adjustment.
However, if the vehicle is damaged in a crash, the aim
of the headlamps may be affected and adjustment may
be necessary.
If oncoming vehicles flash their high beams at you, this
may mean the vertical aim of your headlamps needs to
be adjusted.
It is recommended that the vehicle is taken to your
dealer for service if the headlamps need to be adjusted.
It is possible however, to re-aim the headlamps as
described.
The vehicle should: .
Be placed so the headlamps are 25 ft. (7.6 m) from
a light colored wall or other flat surface. .
Have all four tires on a level surface which is level
all the way to the wall or other flat surface. .
Be placed so it is perpendicular to the wall or other
flat surface. .
Not have any snow, ice, or mud on it. .
Be fully assembled and all other work stopped
while headlamp aiming is being performed. .
Be normally loaded with a full tank of fuel and one
person or 160 lbs (75 kg) sitting on the driver seat. .
Have the tires properly inflated. .
Have the spare tire is in its proper location in the
vehicle.
Headlamp aiming is done with the vehicle's low-beam
headlamps. The high-beam headlamps will be correctly
aimed if the low-beam headlamps are aimed properly.
To adjust the vertical aim:
1. Open the hood. See Hood Release
on page 7 ‑ 15
for more information.
2. Locate the center of
the projector lens of
the low ‐ beam
headlamp.
3. Record the distance from the ground to the center
of the projector lens of the low ‐ beam headlamp.
7-52

Black plate (53,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
4. At a wall, measure from the ground upward (A) to
the recorded distance from Step 3 and mark it.
5. Draw or tape a horizontal line (B) on the wall the
width of the vehicle at the height of the mark in
Step 4.
Notice: Do not cover a headlamp to improve beam
cut-off when aiming. Covering a headlamp may
cause excessive heat build-up which may cause
damage to the headlamp.
6. Turn on the low-beam headlamps and place a
piece of cardboard or equivalent in front of the
headlamp not being adjusted. This allows only the
beam of light from the headlamp being adjusted to
be seen on the flat surface. 7. Locate the vertical headlamp aiming screws, which
are under the hood near each headlamp assembly.
The adjustment screw can be turned with a E8
Torx ®
socket.
8. Turn the vertical aiming screw until the headlamp
beam is aimed to the horizontal tape line. Turn it
clockwise or counterclockwise to raise or lower the
angle of the beam.
7-53

Black plate (54,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
9. Make sure that the light from the headlamp is
positioned at the bottom edge of the horizontal
tape line. The lamp on the left (A) shows the
correct headlamp aim. The lamp on the right (B)
shows the incorrect headlamp aim.
10. Repeat Steps 7 through 9 for the opposite
headlamp. Bulb Replacement For the proper type of replacement bulbs, see
Replacement Bulbs on page 7 ‑ 56 .
For any bulb changing procedure not listed in this
section, contact your dealer.
High Intensity Discharge (HID)
Lighting
{ WARNING: The low beam high intensity discharge lighting
system operates at a very high voltage. If you try
to service any of the system components, you
could be seriously injured. Have your dealer or a
qualified technician service them.
The vehicle may have HID headlamps. After an HID
headlamp bulb has been replaced, you may notice that
the beam is a slightly different shade than it was
originally. This is normal.
7-54

Black plate (55,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
LED Lighting The vehicle may have LED headlamps.
For replacement of the LED lighting assembly
contact your dealer.
Back-Up Lamps To replace this bulb:
1. Open the liftgate.
See Power Liftgate
on
page 3 ‑ 14 for more
information. 2. Remove the two
screws from the
taillamp assembly.
3. Pull the taillamp assembly rearward until you
disengage the inner pins on the taillamp assembly
from the vehicle.
4. Press the release tab, if the bulb socket has one,
and turn the socket counterclockwise to remove it
from the taillamp assembly.
5. Pull the old bulb straight out from the socket.
6. Press a new bulb into the socket, insert the socket
into the taillamp assembly and turn the socket
clockwise into the taillamp assembly until it clicks.
7-55

Black plate (78,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
If you need to replace any of your wheels, wheel bolts,
wheel nuts, or Tire Pressure Monitor System (TPMS)
sensors, replace them only with new GM original
equipment parts. This way, you will be sure to have the
right wheel, wheel bolts, wheel nuts, and TPMS sensors
for your vehicle.
{ WARNING: Using the wrong replacement wheels, wheel bolts,
or wheel nuts on your vehicle can be dangerous.
It could affect the braking and handling of your
vehicle, make your tires lose air and make you
lose control. You could have a collision in which
you or others could be injured. Always use the
correct wheel, wheel bolts, and wheel nuts for
replacement.
Notice: The wrong wheel can also cause problems
with bearing life, brake cooling, speedometer or
odometer calibration, headlamp aim, bumper height,
vehicle ground clearance, and tire or tire chain
clearance to the body and chassis.
See Changing a Flat Tire on page 7 ‑ 80 for more
information. Used Replacement Wheels
{ WARNING: Putting a used wheel on the vehicle is dangerous.
You cannot know how it has been used or how far
it has been driven. It could fail suddenly and
cause a crash. If you have to replace a wheel, use
a new GM original equipment wheel.
Tire Chains
{ WARNING: Do not use tire chains. There is not enough
clearance. Tire chains used on a vehicle without
the proper amount of clearance can cause
damage to the brakes, suspension, or other
vehicle parts. The area damaged by the tire
chains could cause you to lose control of the
vehicle and you or others may be injured in a
crash. Use another type of traction device only if
its manufacturer recommends it for use on the
(Continued)
7-78
