2010.5 Peugeot 508 Dag battery

129
Instruments and controls
Warning lampis onCauseAction/Obser vations
Engine oil pressure fixed. There is a fault with the engine lubrication system. You must stop as soon it is safe to do so. Park, switch off the ignition and contact a PEUGEO T dealer or a qualified workshop.
Batter y charge fixed. The battery charging circuit has a fault (dir ty or loose terminals, slack or cut alternator belt, ...).
The warning lamp should go off when the engine is star ted. If it does not go off, contact a PEUGEOT dealer or a qualified workshop
Door(s) open fixed, associated with a message identifying the door, if the speed is below 6 mph (10 km/h).
A door or the boot is still open. Close the door or boot.
fixed, associated with a message identifying the door, and accompanied by an audible signal if the speed is above 6 mph (10 km/h).
Seat belt(s) not fastened/unfastened
fixed then flashing accompanied by an increasing audible signal.
A seat belt has not been fastened or has been unfastened. Pull the strap then inser t the tongue in the buckle.

34
i
i
Instruments and controls
Service overdue
For 5 seconds after the ignition is switched on, the spanner flashes to indicate that the service must be carried out as soon as possible. Example: the service is overdue by 300 miles (300 km). For 5 seconds after the ignition is switched on, the screen indicates:
The distance remaining may be weighted by the time factor, depending on the driving conditions. Therefore, the spanner may also come on if you have exceeded the two year ser vice inter val.
Following this operation, if you wish to disconnect the battery, lock the vehicle and wait at least five minutes for the zero reset to be taken into account.
5 seconds after the ignition is switched on, the distance recorder resumes its normal operation. The spanner remains on.
Service indicator zero reset
After each ser vice, the ser vice indicator must be reset to zero. The procedure for resetting to zero is as follows:  switch off the ignition,  press and hold the trip distance recorder zero reset button,
 switch on the ignition; the distance recorder display begins a countdown,
 when the display indicates "=0" , release the button; the spanner disappears.
Retrieving the service information
You can access the ser vice information at any time.  Press the trip distance recorder zero reset button. The ser vice information is displayed for a few seconds, then disappears.

42
i
!
i!
Access
As a safety measure (children on board), never leave the vehicle without taking your key, even for a shor t period.
Guard against theft when the electronic key is in the defined zone with the vehicle unlocked.
Maintaining any locking action automatically closes the windows and sunroof. Locking is confirmed by fixed lighting of the direction indicators for approximately two seconds. According to version, the door mirrors fold at the same time.
If one of the doors or the boot is still open or if an electronic key has been left inside the vehicle, the central locking does not take place. When the vehicle is locked, if it is unlocked inadver tently, it will relock automatically after about thir ty seconds unless a door is opened.
It is not possible to lock the vehicle if an electronic key is left inside the vehicle. After a long period of parking, the automatic detection functions of the electronic key are inhibited so as to not discharge the vehicle's battery. You should then use the remote control function of the electronic key to unlock the vehicle.
The folding and unfolding of the door mirrors by the remote control can be deactivated by a PEUGEOT dealer.
Deadlocking
Deadlocking renders the exterior and interior door controls inoperative. It also deactivates the manual central control button. Therefore, never leave anyone inside the vehicle when it is deadlocked.
Using the key
 Turn the key to the rear in the driver's door lock to lock the vehicle completely.  Turn the key to the rear again within five seconds to deadlock the vehicle.

245
Access
Emergency procedure
Emergency unlocking/
locking
using the electronic key
The integral key is used to lock and unlock the vehicle when the electronic key cannot operate: - cell battery flat, vehicle battery discharged or disconnected, ... - vehicle located in an area with strong electromagnetic emissions.  Pull on button 1 , to extract the integral key 2 .  Unlock or lock the vehicle using the key.
Manual locking
Driver's door
Inser t the key in the lock to lock or unlock the door.
Passenger doors
 On the rear doors, check that the child lock is not on.  Remove the black cap located on the edge
of the door, using the key.  Insert the key into the aperture without forcing, then without turning, move the latch
sideways towards the inside of the door.  Remove the key and refit the cap.
Remote control problem
Following disconnection of the vehicle battery, replacement of the remote control battery or in the event of a remote control malfunction, you can no longer unlock, lock or locate your vehicle.  First of all, use the key in the lock to unlock or lock your vehicle.  Then, reinitialise the remote control. If the problem persists, contact a PEUGEOT dealer or a qualified workshop as soon as possible.
Reinitialisation with the remote control
 Switch on the ignition.  Immediately press one of the remote control buttons for a few seconds.  Switch off the ignition. The remote control is fully operational again.

46
Access
Changing the battery of the key
Battery ref.: CR2032/3 volts. This replacement battery is available from a PEUGEOT dealer or a qualified workshop. A message appears in the instrument panel screen when replacement of the battery is needed.  Unclip the cover using a small screwdriver at the cutout.  Lift off the cover.
 Remove the flat battery from its location.  Fit the new battery into its location obser ving the original direction of fitment.  Clip the cover onto the casing.
Do not throw the remote control batteries away, they contain metals which are harmful to the environment. Take them to an approved collection point.
Reinitialisation with the electronic key
 Switch of the ignition.  Immediately press one of the remote control buttons for a few seconds.  Switch on the ignition The electronic key is fully operational again.
Changing the battery of the electronic key
Battery ref.: CR2032/3 volts. This replacement battery is available from a PEUGEOT dealer or a qualified workshop. A message is displayed in the instrument panel screen when replacement of the battery is needed.  Unclip the cover using a pointed object at the key ring.  Slide the flat battery out of its location.
 Slide the new battery into its location obser ving the original direction of fitment.  Clip the cover in place star ting at the front.  Reinitialise the electronic key.

42
i
!
i!
Access
As a safety measure (children on board), never leave the vehicle without taking your key, even for a shor t period.
Guard against theft when the electronic key is in the defined zone with the vehicle unlocked.
Maintaining any locking action automatically closes the windows and sunroof. Locking is confirmed by fixed lighting of the direction indicators for approximately two seconds. According to version, the door mirrors fold at the same time.
If one of the doors or the boot is still open or if an electronic key has been left inside the vehicle, the central locking does not take place. When the vehicle is locked, if it is unlocked inadver tently, it will relock automatically after about thir ty seconds unless a door is opened.
It is not possible to lock the vehicle if an electronic key is left inside the vehicle. After a long period of parking, the automatic detection functions of the electronic key are inhibited so as to not discharge the vehicle's battery. You should then use the remote control function of the electronic key to unlock the vehicle.
The folding and unfolding of the door mirrors by the remote control can be deactivated by a PEUGEOT dealer.
Deadlocking
Deadlocking renders the exterior and interior door controls inoperative. It also deactivates the manual central control button. Therefore, never leave anyone inside the vehicle when it is deadlocked.
Using the key
 Turn the key to the rear in the driver's door lock to lock the vehicle completely.  Turn the key to the rear again within five seconds to deadlock the vehicle.

245
Access
Emergency procedure
Emergency unlocking/
locking
using the electronic key
The integral key is used to lock and unlock the vehicle when the electronic key cannot operate: - cell battery flat, vehicle battery discharged or disconnected, ... - vehicle located in an area with strong electromagnetic emissions.  Pull on button 1 , to extract the integral key 2 .  Unlock or lock the vehicle using the key.
Manual locking
Driver's door
Inser t the key in the lock to lock or unlock the door.
Passenger doors
 On the rear doors, check that the child lock is not on.  Remove the black cap located on the edge
of the door, using the key.  Insert the key into the aperture without forcing, then without turning, move the latch
sideways towards the inside of the door.  Remove the key and refit the cap.
Remote control problem
Following disconnection of the vehicle battery, replacement of the remote control battery or in the event of a remote control malfunction, you can no longer unlock, lock or locate your vehicle.  First of all, use the key in the lock to unlock or lock your vehicle.  Then, reinitialise the remote control. If the problem persists, contact a PEUGEOT dealer or a qualified workshop as soon as possible.
Reinitialisation with the remote control
 Switch on the ignition.  Immediately press one of the remote control buttons for a few seconds.  Switch off the ignition. The remote control is fully operational again.

46
Access
Changing the battery of the key
Battery ref.: CR2032/3 volts. This replacement battery is available from a PEUGEOT dealer or a qualified workshop. A message appears in the instrument panel screen when replacement of the battery is needed.  Unclip the cover using a small screwdriver at the cutout.  Lift off the cover.
 Remove the flat battery from its location.  Fit the new battery into its location obser ving the original direction of fitment.  Clip the cover onto the casing.
Do not throw the remote control batteries away, they contain metals which are harmful to the environment. Take them to an approved collection point.
Reinitialisation with the electronic key
 Switch of the ignition.  Immediately press one of the remote control buttons for a few seconds.  Switch on the ignition The electronic key is fully operational again.
Changing the battery of the electronic key
Battery ref.: CR2032/3 volts. This replacement battery is available from a PEUGEOT dealer or a qualified workshop. A message is displayed in the instrument panel screen when replacement of the battery is needed.  Unclip the cover using a pointed object at the key ring.  Slide the flat battery out of its location.
 Slide the new battery into its location obser ving the original direction of fitment.  Clip the cover in place star ting at the front.  Reinitialise the electronic key.
