2010.5 Peugeot 508 Dag display

34
i
i
Instruments and controls
Service overdue
For 5 seconds after the ignition is switched on, the spanner flashes to indicate that the service must be carried out as soon as possible. Example: the service is overdue by 300 miles (300 km). For 5 seconds after the ignition is switched on, the screen indicates:
The distance remaining may be weighted by the time factor, depending on the driving conditions. Therefore, the spanner may also come on if you have exceeded the two year ser vice inter val.
Following this operation, if you wish to disconnect the battery, lock the vehicle and wait at least five minutes for the zero reset to be taken into account.
5 seconds after the ignition is switched on, the distance recorder resumes its normal operation. The spanner remains on.
Service indicator zero reset
After each ser vice, the ser vice indicator must be reset to zero. The procedure for resetting to zero is as follows:  switch off the ignition,  press and hold the trip distance recorder zero reset button,
 switch on the ignition; the distance recorder display begins a countdown,
 when the display indicates "=0" , release the button; the spanner disappears.
Retrieving the service information
You can access the ser vice information at any time.  Press the trip distance recorder zero reset button. The ser vice information is displayed for a few seconds, then disappears.

135
i
Instruments and controls
Low oil level
This is indicated by a message in the instrument panel screen. If the low oil level is confirmed by a check using the dipstick, the level must be topped up to
avoid damage to the engine.
Oil level gauge fault
This is indicated by a message in the instrument panel screen. Contact a PEUGEOT dealer or a qualified workshop.
Dipstick
Refer to the "Checks" section to locate the dipstick and the oil filler cap on your engine.
There are 2 marks on the dipstick:
The total mileage is displayed in zone A of the screen and the trip mileage in zone B .
With the trip mileage displayed, press the
button for a few seconds.
Mileage recorder
Trip recorder zero reset
System which informs the driver of the validity or invalidity of the engine oil level. This information is indicated for a few seconds when the ignition is switched on, after the ser vice information.
The level read will only be correct if
the vehicle is on level ground and the engine has been off for more than 30 minutes.
- A = max; never exceed this level, - B = min; top up the level via the oil filler cap, using the grade of oil suited to your engine.
Oil level correct
This is indicated by a message in the instrument panel screen.

36
Instruments and controls
System which provides current information concerning the trip (range, consumption…).
Trip computer
Instrument panel screen
Information display
 Press the button, located at the end of the wiper stalk , to display the various trip computer tabs in succession.
- The current information tab with:

137
i
i
i
Instruments and controls
If dashes are displayed continuously
while driving in place of the digits, contact a PEUGEOT dealer or a qualified workshop.
This function is only displayed from 20 mph (30 km/h).
This value may vary following a change in the style of driving or the relief, resulting in a significant change in the current fuel consumption.
A few definitions…
Range
(miles or km) This indicates the distance which can still be travelled with the fuel remaining in the tank
in relation to the average fuel consumption over the last few miles (kilometres) travelled.
When the range falls below 20 miles (30 km),
dashes are displayed. After filling with at least 5 litres of fuel, the range is recalculated and is displayed when it exceeds 60 miles (100 km).
Current fuel consumption
(mpg or l/100 km or km/l) This is the average fuel consumption during the last few seconds.
Average fuel consumption
(mpg or l/100 km or km/l) This is the average fuel consumption since the last trip computer zero reset.
Average speed
(mph or km/h) This is the average speed calculated since the last trip computer zero reset (ignition on).
Trip reset
 When the trip required is displayed, press the control for more than two seconds or use the left hand thumbwheel of the steering mounted controls. Trips "1" and "2" are independent but their use is identical. For example, trip "1" can be used for daily
figures, and trip "2" for monthly figures.

46
Access
Changing the battery of the key
Battery ref.: CR2032/3 volts. This replacement battery is available from a PEUGEOT dealer or a qualified workshop. A message appears in the instrument panel screen when replacement of the battery is needed.  Unclip the cover using a small screwdriver at the cutout.  Lift off the cover.
 Remove the flat battery from its location.  Fit the new battery into its location obser ving the original direction of fitment.  Clip the cover onto the casing.
Do not throw the remote control batteries away, they contain metals which are harmful to the environment. Take them to an approved collection point.
Reinitialisation with the electronic key
 Switch of the ignition.  Immediately press one of the remote control buttons for a few seconds.  Switch on the ignition The electronic key is fully operational again.
Changing the battery of the electronic key
Battery ref.: CR2032/3 volts. This replacement battery is available from a PEUGEOT dealer or a qualified workshop. A message is displayed in the instrument panel screen when replacement of the battery is needed.  Unclip the cover using a pointed object at the key ring.  Slide the flat battery out of its location.
 Slide the new battery into its location obser ving the original direction of fitment.  Clip the cover in place star ting at the front.  Reinitialise the electronic key.

46
Access
Changing the battery of the key
Battery ref.: CR2032/3 volts. This replacement battery is available from a PEUGEOT dealer or a qualified workshop. A message appears in the instrument panel screen when replacement of the battery is needed.  Unclip the cover using a small screwdriver at the cutout.  Lift off the cover.
 Remove the flat battery from its location.  Fit the new battery into its location obser ving the original direction of fitment.  Clip the cover onto the casing.
Do not throw the remote control batteries away, they contain metals which are harmful to the environment. Take them to an approved collection point.
Reinitialisation with the electronic key
 Switch of the ignition.  Immediately press one of the remote control buttons for a few seconds.  Switch on the ignition The electronic key is fully operational again.
Changing the battery of the electronic key
Battery ref.: CR2032/3 volts. This replacement battery is available from a PEUGEOT dealer or a qualified workshop. A message is displayed in the instrument panel screen when replacement of the battery is needed.  Unclip the cover using a pointed object at the key ring.  Slide the flat battery out of its location.
 Slide the new battery into its location obser ving the original direction of fitment.  Clip the cover in place star ting at the front.  Reinitialise the electronic key.

46
Access
Changing the battery of the key
Battery ref.: CR2032/3 volts. This replacement battery is available from a PEUGEOT dealer or a qualified workshop. A message appears in the instrument panel screen when replacement of the battery is needed.  Unclip the cover using a small screwdriver at the cutout.  Lift off the cover.
 Remove the flat battery from its location.  Fit the new battery into its location obser ving the original direction of fitment.  Clip the cover onto the casing.
Do not throw the remote control batteries away, they contain metals which are harmful to the environment. Take them to an approved collection point.
Reinitialisation with the electronic key
 Switch of the ignition.  Immediately press one of the remote control buttons for a few seconds.  Switch on the ignition The electronic key is fully operational again.
Changing the battery of the electronic key
Battery ref.: CR2032/3 volts. This replacement battery is available from a PEUGEOT dealer or a qualified workshop. A message is displayed in the instrument panel screen when replacement of the battery is needed.  Unclip the cover using a pointed object at the key ring.  Slide the flat battery out of its location.
 Slide the new battery into its location obser ving the original direction of fitment.  Clip the cover in place star ting at the front.  Reinitialise the electronic key.

255
Access
Emergency release
(Saloon and SW)
System for mechanical unlocking of the boot in the event of a battery or central locking fault.
Unlocking
 Fold back the rear seats to gain access to the lock from inside the boot.  Inser t a small screwdriver into hole A of the
lock to unlock the tailgate.
"Boot open" warning
With the engine running or when the vehicle is moving, if the tailgate is not properly closed, a message accompanied by an audible signal (from 6 mph (10 km/h)) is displayed in the instrument panel screen.
