2010.5 Peugeot 508 Dag display

363
Comfort
Storing driving positions
System which stores the electrical settings of the driver's seat and door mirrors as well as the head-up display settings. It enables you to store up to two positions using the buttons on the side of the driver's seat.
Storing a position
using buttons M/1/2
 Switch on the ignition.  Adjust your seat, the door mirrors and the head-up display.  Press button M , then press button 1 or 2within four seconds. An audible signal indicates that the position has been stored. Storing a new position cancels the previous position.
Recalling a stored position
Ignition on or engine running
 Briefly press button 1 or 2 to recall the corresponding position. An audible signal indicates the end of the
adjustment. You can interrupt the current movement by pressing button M , 1 or 2 or by using one of the seat controls. A stored position cannot be recalled while driving. Recalling stored positions is deactivated 45 seconds after switching off the ignition.
Welcome function
The welcome function assists entry and leaving the vehicle. After switching off the ignition and opening the driver’s door, the seat moves back automatically and then stays in this position, ready for the next entry to the vehicle. When switching on the ignition, the seat moves for ward to the stored driving position. When moving the seat, take care that no person or object hinders the automatic movement of the seat. To activate or deactivate this function, contact a PEUGEOT or a qualified workshop.

373
i
Comfort
Peugeot Connect USB
auxiliary socket and a USB por t, is located in the front armrest (under the cover). It permits the connection of por table device, such as a digital audio player of the iPod ® type ®
or a USB memory stick.
It reads the audio file formats (MP3, OGG, WMA, WAV, ...) which are transmitted to your audio equipment and played via the vehicle's
speakers. You can manage these files using the steering mounted controls or the audio system control panel and display them in the instrument panel screen.
When the USB por t is used, the por table device charges automatically.
For more information on the use of this system, refer to the "Audio and
Telematics" section.
Ski flap
Device for storing and transpor ting long objects.
Opening
 Lower the armrest.  Press the flap opening control.  Lower the flap.  Load the objects from inside the boot.

373
i
Comfort
Peugeot Connect USB
auxiliary socket and a USB por t, is located in the front armrest (under the cover). It permits the connection of por table device, such as a digital audio player of the iPod ® type ®
or a USB memory stick.
It reads the audio file formats (MP3, OGG, WMA, WAV, ...) which are transmitted to your audio equipment and played via the vehicle's
speakers. You can manage these files using the steering mounted controls or the audio system control panel and display them in the instrument panel screen.
When the USB por t is used, the por table device charges automatically.
For more information on the use of this system, refer to the "Audio and
Telematics" section.
Ski flap
Device for storing and transpor ting long objects.
Opening
 Lower the armrest.  Press the flap opening control.  Lower the flap.  Load the objects from inside the boot.

84
i
Comfort
Dual-zone digital air conditioning
The air conditioning system operates when the engine is running.
Automatic operation
1. Automatic comfort programme
 Press this "AUTO" button. The indicator lamp comes on.
We recommend that you use this mode. It
automatically adjusts all settings to provide optimum operation for the comfor t level chosen: passenger compar tment temperature, air flow, air distribution and air recirculation. This system is designed to operate effectively in all seasons, with the windows closed.
When the engine is cold, to prevent too great a distribution of cold air, the air flow will reach its optimum level gradually. In cold weather, it favours the distribution of warm air to the windscreen, side windows and footwells only.
2 - 3. Driver-passenger side adjustment
The driver and front passenger can each adjust the temperature to their requirements. The value indicated on the display corresponds to a level of comfor t and not to a temperature in degrees Celsius or Fahrenheit.
 Turn control 2 or 3 to the left (blue) or to the right (red) respectively to decrease or increase this value.
A setting around the value 21 provides optimum comfor t. However, depending on
your requirements, a setting between 18 and 24 is normal. It is recommended that the difference between
left and right should not be greater 3.

385
i
i
i
Comfort
On entering the vehicle, if the interior temperature is much colder or warmer than the comfor t value, there is no need to change the value displayed in order to obtain the comfor t required. The system corrects the difference in temperature automatically and as quickly as possible.
4. Automatic visibility programme
For maximum cooling or heating of the passenger compar tment, it is possible to exceed the minimum value 14 or the maximum value 28.  Turn control 2 or 3 to the left until "LO" is displayed or to the right until "HI" is displayed.
See "Front demisting-defrosting".
 Press this button to equalise the comfor t value on the passenger's side with that on the driver's side (mono-zone). The indicator lamp on the button comes on.
If you wish, you can change one of settings provided by the system. The other functions will still be controlled automatically.  Pressing the "AUTO" button returns the system to completely automatic operation.
Manual operation
5. Mono-zone/Dual-zone
The air conditioning is designed to operate effectively in all seasons, with the windows closed.
6. Air conditioning On/Off
It allows you: - in summer, to lower the temperature, - in winter, above 3 °C, to improve demisting per formance.
7. Maximum air conditioning
If you want to temporarily refresh the air in the passenger compar tment, press this button and "LO" is displayed. To return to the previous settings, press the button again.
With Stop & Star t, when demisting has been activated, the STOP mode is not available.
Switching on Press the "A /C" button, the associated
green indicator lamp comes on. The air conditioning does not operate when the air flow control is set to off.
Switching off
 Press the "A /C" button again, the associated green indicator lamp goes off. Switching off the air conditioning may result in
some discomfor t (humidity, misting).

387
Comfort
Quad-zone digital air conditioning
The air conditioning system operates when the engine i s running.
Automatic operation
1. Automatic comfort programme
The Soft /Auto/Fast modes allow the driver and front seat passenger to select their desired comfor t settings for the passenger compar tment:
2. Activating/deactivating the rear air conditioning
3 - 4. Driver-passenger side adjustment
The driver and front passenger can each adjust the temperature to their requirements. The value indicated on the display corresponds
to a level of comfor t and not to a temperature in degrees Celsius or Fahrenheit.
Favours optimum gentle and silent operation by limiting the air flow.
Offers the best compromise between thermal comfor t and silence of operation.
Favours dynamic and effective air flow.
Press this button to deactivate the rear air conditioning and lock the system. A padlock appears in the LCD screen. When the rear system is reactivated, automatic mode is selected with the last temperature settings used.
 Turn control 3 or 4 to the left (blue) or to the right (red) respectively to decrease or increase this value.
A setting around the value 21 provides optimum comfor t. However, depending on your requirements, a setting between 18 and 24 is normal. It is recommended that the difference between left and right should not be greater 3.

88
i
i
i
Comfort
5. Automatic visibility programme
6. Mono-zone/Quad-zone
7. Air conditioning On/Off
Manual operation
If you wish, you can change one of settings provided by the system. The other functions will still be controlled automatically. Press one of the Soft /Auto/Fast buttons to return to fully automatic operation.
On entering the vehicle, if the interior temperature is much colder or warmer than the comfor t value, there is no need to change the value displayed in order to obtain the comfor t required. The system corrects the difference in temperature automatically and as quickly as possible.
See "Front demisting-defrosting".
Press this button to apply the driver's comfort setting value to the front and rear passengers (mono-zone). The indicator lamp on the button comes on.
The air conditioning is designed to operate effectively in all seasons, with the windows closed. It allows you:
- in summer, to lower the temperature, - in winter, above 3 °C, to improve demisting per formance.
Switching on Press the "A /C" button, the associated green indicator lamp comes on. The air conditioning does not operate when the air flow control is set to off.
Switching off
 Press the "A /C" button again, the associated green indicator lamp goes off. Switching off the air conditioning may result in some discomfor t (humidity, misting).
For maximum cooling or heating of the passenger compar tment, it is possible to exceed the minimum value 14 or the maximum value 28.  Turn the dial 3 or 4 to the left until "LO" is displayed or to the right until "HI" is displayed.
With Stop & Star t, when demisting has been activated, the STOP mode is not available.

96
!
!
Driving
It is recommended that you do not apply the parking brake in very cold conditions (ice) and during towing
(breakdown, caravan...). Deactivate the automatic functions and release the parking brake manually.
Before leaving the vehicle, check that parking brake warning lamps in the instrument panel and the control lever Aare on, not flashing.
The electric parking brake combines 2 operating modes: - Automatic Application/Release Application is automatic when the engine stops, release is automatic on use of the accelerator (this mode is activated by default), - Manual Application/Release Manual application of the parking brake is done by pulling control lever A. manual release is done by pushing and
releasing the control lever, while pressing the brake pedal. When the driver's door is opened, there is an audible signal and a message is displayed if the
brake is not applied.
Programming the mode
Depending on the country of sale of the vehicle, the automatic application when the engine is switched off and the automatic release when you press the accelerator can be deactivated.
With the vehicle stationary, to apply the parking brake whether the engine is running or off, pullcontrol lever A .
Manual application
Activation/deactivation is done via the menu in the instrument panel screen.
The parking brake is then applied and released manually.
The application of the parking brake is confirmed by:
- lighting of the braking warning lamp and of the P warning lamp in the control lever A ,
- display of the message "Handbrake on".
When the driver’s door is opened with the engine running, there is an audible signal and a message is displayed if the parking brake has not been applied, unless the selector lever is in position P (Park) in the case of an automatic gearbox.
Electric parking brake
If this warning lamp comes on in the instrument panel, the automatic mode is deactivated.
