IX
137
D R I V I N G
The position of the gear lever the the
driving mode are displayed in dial C
of the instrument panel.
A selection grille alongside the gear
lever also allows you to see the
selected position.
Displays in the instrument panel Moving off
To start the engine, the gear lever
must be in position N .
Press the brake pedal down fully.
Operate the starter
N appears in the instrument panel
screen.
N fl a s h e s i n t h e i n s t r u m e n t p a n e l ,
accompanied by an audible signal
and a message on the multifunc-
tion screen, if the gear lever is not
in position N on starting.
S e l e c t fi r s t g e a r ( p o s i t i o n M or A )
or reverse (position R ).
Release the parking brake un-
less it is programmed in auto-
matic mode.
Release the brake pedal, then
accelerate.
With your foot on the brake, push
the lever forwards.
Reverse
Only engage reverse with
the vehicle immobilised.
To avoid any jerking, wait a
moment before accelerating.
Neutral Never select position N with
the vehicle moving.
Page 164 of 336
IX
!
143
D R I V I N G
Mode selection Displays on the instrument panel
automatic mode: gear lever in
position D ,
sequential mode: gear lever in
position M ,
SPORT mode: gear lever in po-
sition D and button A pressed,
SNOW mode: gear lever in posi-
tion D and button B pressed. The position of the gear lever and
the driving mode are displayed on
the instrument panel dial
C .
A position grille associated with the
gear lever allows you to view the
selected position.
For safety:
- position P can be disen-
gaged only if you press
the brake pedal,
- when a door is opened, an au- dible signal is heard if the gear
lever is not in position P ,
- always make sure that the gear lever is in position P before you
leave your vehicle.
I f t h e g e a r b o x i s i n p o s i t i o n P but
the position of the gear lever is dif-
ferent, reposition the gear lever on
P so that you can start the vehicle.
AUTOMATIC GEARBOX
A u t o m a t i c g e a r b o x w h i c h o f f e r s a
choice between the comfort of fully
automatic operation, enhanced by
the sport and snow programmes, or
manual gear changing.
Four driving modes are provided:
- automatic operation for elec-
tronic control of the gears by the
g e a r b o x ,
- the SPORT programme for a
more dynamic driving style,
- the SNOW programme to im-
prove driving when the grip is
poor,
- manual operation for sequen-
tial changing of the gears by the
driver.
Page 168 of 336
IX
147
D R I V I N G
FIXED CENTRED CONTROLS STEERING WHEEL
1
Rotation - S c r o l l t h e v a r i o u s p a g e s o f i n f o r m a t i o n o n t h
e i n s t r u m e n t p a n e l
screen.
- Move through the various menus on the instrume nt panel screen.
- Increase/decrease values.
S h o r t p r e s s
- Open the menu on the instrument panel screen (only when stationary).
- S e l e c t a n d c o n fi r m i n f o r m a t i o n .
Long press Trip computer zero reset (if the trip computer page is displayed).
2 S h o r t p r e s s - Cancel the current operation.
- Return to the previous screen on the instrumen
t panel screen.
Long press Return to the initial page on the ins trument panel screen.
3 S h o r t p r e s s Increase the speed in steps of 1 mph (1 km/h)/stor ing the speed.
Maintained press Increase the speed in steps of 5 mph (5 km/h).
4 S h o r t p r e s s Decrease the speed in steps of 1 mph (1 km/h)/stor ing the speed.
Maintained press Decrease the speed in steps of 5 mph (5 km/h).
5 S h o r t p r e s s S u s p e n d o r r e s u m e c r u i s e c o n t r o l / s p e e d l i m i t e r ( d e
p e n d i n g o n t h e
mode selected).
6 S h o r t p r e s s S e l e c t c r u i s e c o n t r o l o r s p e e d l i m i t e r m o d e ( t h e c
y c l e o n t h i s b u t t o n
will always begin with selection of the speed limit er).
7 S h o r t p r e s s Deactivate cruise control/speed limiter.
8 S h o r t p r e s s - Pick up an incoming call.
- Hang up the current call.
- Open the telephone short-cut menu.
- C o n fi r m o n t h e l i s t a n d t h e t e l e p h o n e m e n u .
Long press Refuse an incoming call.
9 S h o r t p r e s s / L o n g p r e s s Horn.
10 S h o r t p r e s s Activate/deactivate Black Panel mode (night drivin g).
11 S h o r t p r e s s Activate the voice command.
Long press Navigation instruction repeat.
Page 169 of 336
IX
148
D R I V I N G
12
Rotation - R a d i o s o u r c e : S c r o l l t h e p r e - s e t s t a t i o n s .
- C D / M P 3 C D / C D c h a n g e r / j u k e b o x s o u r c e : S c r o l l t h
e C D s o r
directories.
- On the multifunction screen menus: Movement an d increase/
decrease.
S h o r t p r e s s - O n t h e m u l t i f u n c t i o n s c r e e n m e n u s : c o n fi r m .
- Open the short-cut menus (depending on the mul
tifunction
screen page).
Long press Open the multifunction screen main me nu.
13 S h o r t p r e s s Cancel the current operation and return to the pre
vious page on the
multifunction screen.
When an incoming telephone call is received: Refus e the call.
Long press Return to the initial page on the mul tifunction screen.
14 S h o r t p r e s s Access to the multifunction screen general menu.
15 S h o r t p r e s s / M a i n t a i n e d p r e s s Volume increase.
16 S h o r t p r e s s / M a i n t a i n e d p r e s s Volume decrease.
17 S h o r t p r e s s - First press: mute.
- S e c o n d p r e s s : r e s t o r e s o u n d .
18 S h o r t p r e s s - Radio source: Automatic search of higher freq uencies.
- C D / M P 3 C D / C D c h a n g e r / j u k e b o x s o u r c e : S e a r c h f o r t h e n e x t t r a c k .
Maintained press - C D / M P 3 C D / C D c h a n g e r / j u k e b o x s o u r c e : F a s t f o r w a r d p l a y .
19 S h o r t p r e s s - Radio source: Automatic search of lower frequ
encies.
- C D / M P 3 C D / C D c h a n g e r / j u k e b o x s o u r c e : S e a r c h f o r t h e
previous track.
Maintained press C D / M P 3 C D / C D c h a n g e r / j u k e b o x s o u r c e : F a s t b a c k w a r d s .
20 S h o r t p r e s s - Radio source: display the list of radio stati
ons available.
- CD/MP3 CD and CD changer source: display the l ist of CD
tracks and directories.
- J u k e b o x s o u r c e : d i s p l a y t h e l i s t o f a l b u m s .
Long press Update the list of radio stations.
21 S h o r t p r e s s / L o n g p r e s s Horn.
22 S h o r t p r e s s MODE: selection of the type of information present ed on the multifunction screen.
Page 170 of 336
IX
149
D R I V I N G
SPEED LIMITER
S y s t e m w h i c h p r e v e n t s t h e v e h i -
c l e f r o m e x c e e d i n g t h e s p e e d p r o -
grammed by the driver.
When the limit speed is reached, the
accelerator pedal no longer has any
effect.
The speed limiter is switched
on manually: a speed of at least
2 0 m p h ( a p p r o x . 3 0 k m / h ) m u s t b e
programmed.
The speed limiter can in no way re-
place respect for speed limits or vigi-
lance and responsibility on the part
of the driver.
Steering mounted controls
The speed limiter switches are lo-
cated on the left-hand side of the
steering wheel. Displays on the instrument
panel
The speed limiter information is dis-
played in zone
A of the instrument
panel.
Programming
Press on button 4 to select speed
limiter mode " LIMIT ".
T h e s e l e c t i o n i s c o n fi r m e d b y t h e
display of the function in zone A of
the instrument panel. Activation
Press on button 3 when the de-
s i r e d m a x i m u m s p e e d i s d i s -
played.
The information "ON" then appears
in zone A .
When the function is selected, the
last memorised speed and the infor-
mation "PAUSE" are displayed.
With the engine running, you can
a d j u s t t h e m e m o r i s e d m a x i m u m
speed, displayed in zone A , by
pressing on:
Button 1 to increase the memo-
r i s e d m a x i m u m s p e e d .
Button 2 to decrease the memo-
r i s e d m a x i m u m s p e e d . S u c c e s s i v e p r e s s e s w i l l m o d i f y t h e
m a x i m u m s p e e d i n s t e p s o f 1 m p h
and a continuous press in steps of
5 mph.
Page 171 of 336
IX
150
D R I V I N G
In the event of a steep descent or
u n d e r e x c e s s i v e a c c e l e r a t i o n , t h e
speed limiter (which does not act
on the brakes) may not be able to
p r e v e n t t h e v e h i c l e f r o m e x c e e d i n g
the programmed speed.
U s e o f a fl o o r m a t o t h e r t h a n t h a t
recommended by CITROËN may
affect the normal operation of the
accelerator pedal and hamper the
operation of the speed limiter.
Floor mats approved by CITROËN
a r e fi t t e d w i t h a 3 r d fi x i n g l o c a t e d i n
the pedal area to avoid any risk of
interference with the pedals.
Suspension/Resumption
Press on button 3 .
This action causes the information
"PAUSE" to appear in zone A of the
instrument panel.
This action does not cancel the
m e m o r i s e d m a x i m u m s p e e d w h i c h
remains displayed in zone A of the
instrument panel. Overriding the programmed
speed
The accelerator pedal has an end-
o f - t r a v e l s w i t c h . I n o r d e r t o e x c e e d
t h e m e m o r i s e d m a x i m u m s p e e d a t
any time, you can press the pedal
all the way down. While the speed
i s b e i n g e x c e e d e d , t h e s p e e d d i s -
played in zone
A w i l l fl a s h . Y o u h a v e
only to release the accelerator pedal
t o r e t u r n b e l o w t h e m a x i m u m s p e e d ,
to restore the function.
T h e s p e e d w i l l a l s o fl a s h i f t h e s p e e d
limiter is not able to prevent the vehi-
c l e f r o m e x c e e d i n g t h e p r o g r a m m e d
speed (e.g. on a steep descent or
u n d e r e x c e s s i v e a c c e l e r a t i o n ) .
To reactivate the speed limiter, re-
lease the accelerator to slow to a
speed lower than the programmed
speed. Return to normal driving
Either press on button 5 .
Or select the speed limiter function.
Or stop the engine.
Operating fault
If there is a malfunction, a mes-
sage is displayed accompanied by
an audible signal and lighting of the
SERVICE warning lamp.
Have it checked by a CITROËN
dealer.
Page 172 of 336
IX
151
D R I V I N G
CRUISE CONTROL
S y s t e m w h i c h a u t o m a t i c a l l y m a i n -
tains the vehicle speed programmed
by the driver, without any action on
the accelerator pedal.
The cruise control is switched on
manually: the vehicle speed must be
at least 25 mph (40 km/h) and you
must be in at least:
- 4 t h g e a r f o r m a n u a l g e a r b o x e s ,
- 2 n d g e a r f o r a u t o m a t i c g e a r b o x e s . Displays on the instrument
panel
The programmed information is
grouped together in zone
A of the
instrument panel.
Programming
Press button 4 to select cruise
control mode " CRUISE ".
Steering mounted controls
The cruise control switches are lo-
cated on the left-hand side of the
steering wheel. T h e s e l e c t i o n i s c o n fi r m e d b y t h e
display of the function in zone
A of
the instrument panel.
When the function is selected, no
cruising speed has yet been
memorised . Once the desired speed has been
reached using the accelerator, press
button
1 or button 2 . The cruising
speed is then memorised and cruise
control is activated. The cruising
speed is displayed in zone A of the
instrument panel, and "ON" is dis-
played.
Adjustment of the memorised
speed while cruise control is
in operation
You can adjust the memorised speed, displayed in zone A , by pressing:
- Button 1 to increase the speed.
- Button 2 to reduce the speed.
S u c c e s s i v e p r e s s e s w i l l m o d i f y t h e
cruise speed in steps of 1 mph and a
continuous press in steps of 5 mph.
You can then release the accelera-
tor pedal. The vehicle will automati-
cally keep to the speed chosen.
The vehicle speed may vary slightly
from that memorised.
If during cruise control the system
cannot keep to the cruise speed
(e.g. on a steep descent), then the
s p e e d fl a s h e s . I f n e c e s s a r y , b r a k e t o
curb your speed.
Page 173 of 336
IX
!
152
D R I V I N G
Cruise control must only be
u s e d w h e r e t h e t r a f fi c c o n d i -
tions permit driving at a con-
stant speed .
Do not use it on congested
roads or when the weather or the
road conditions are poor .
The driver must remain attentive
and in complete control of the ve-
hicle .
You are recommended to keep your
feet within range of the pedals .
Overriding the programmed
speed
While cruise control is in operation,
it is always possible to go above the
programmed speed simply by press-
i n g t h e a c c e l e r a t o r p e d a l ( f o r e x a m -
ple to overtake another vehicle).
The speed displayed in zone
A
fl a s h e s .
You only have to release the ac-
celerator pedal to return to the pro-
grammed speed.
Suspension/Resumption
Either by pressing the brake
pedal or the clutch pedal.
Or by pressing button 3 .
O r b y t h e E S P o r A S R s y s t e m s
being active.
F o r v e h i c l e s w i t h a m a n u a l g e a r b o x ,
cruise control is deactivated if the
gear lever is in neutral. Reactivation
-
By recalling the memorised
speed
After deactivation, press button 3 .
Your vehicle automatically returns
to the memorised cruising speed.
The memorised speed and "ON"
are displayed in zone A .
If the memorised cruising speed is higher than the current speed,
the vehicle will accelerate strong-
ly to reach the current speed.
- By selecting the current speed
Press button 1 or 2 once the de-
sired speed has been reached.
The new speed and "ON" will
appear in zone A .
Return to normal driving
Either press on button 5 .
Or select the cruise control function.
Or stop the engine.
The speed that was chosen is no
longer memorised.
"PAUSE" will be displayed in zone A
of the instrument panel.
These actions do not cancel the
cruising speed which remains dis-
played on the instrument panel. Operating fault
If there is a malfunction, a mes-
sage is displayed accompanied by
an audible signal and lighting of the
SERVICE warning lamp.
Have it checked by a CITROËN
dealer.
