2009 RENAULT TWINGO RS Trim And Upholstery Workshop Manual

77A-11
FRONT SEAT TRIM
Front seatback trim: Removal - Refitting
77A
aUnclip the headrest guides (29) .
aRemove:
-the seatback cover,
-the seatback foam.
REFITTING
I - REFITTING OPERATION FOR PART
CONCERNED
1 - 1st type
aRefit:
-the seatback foam,
-the seatback cover partially.
aClip on the headrest guides (6) .
aFit the clips (5) (available from the Spare Parts De-
partment) using the (Car. 1521).
aRefit:
-the retaining sections (4) ,
-the elastic securing straps (3) for the seatback trim.
aClip on the control accessing the rear seats.
aRefit:
-the cover (2) ,
-the headrest.2 - 2nd type
aRefit:
-the seatback foam,
-the seatback cover partially.
aClip on the headrest guides (16) .
aRefit:
-the retaining section (15) ,
-the clips (14) .
aFit the clips (13) and (12) (available from the Spare
Parts Department) using the (Car. 1521).
aRefit:
-the retaining sections (11) ,
-the elastic securing straps (10) for the seatback
trim,
-the plate for the control accessing the rear seats,
-the bolts (9) ,
-the lever for the control accessing the rear seats,
-the bolt (8) ,
-the headrest.
3 - 3rd type
aRefit:
-the seatback foam,
-the seatback cover partially.
aClip on the headrest guides (29) .
aRefit:
-the retaining section (28) ,
-the clips (27) .
aFit the clips (25) and (26) (available from the Spare
Parts Department) using the (Car. 1521).
aRefit:
-the retaining sections (24) ,
-the elastic securing straps (23) and (22) for the
seatback trim.
aClip:
-the casings (19) ,
-the seatback plate.
aRefit:
-the plate for the control accessing the rear seats,
-the bolts (21) ,
-the lever for the control accessing the rear seats,
120838

77A-12
FRONT SEAT TRIM
Front seatback trim: Removal - Refitting
77A
-the bolt (20) ,
-the headrest.
II - FINAL OPERATION.
aRefit the complete front seat (see 75A, Front seat
frames and mechanisms, Complete front seat:
Removal - Refitting, page 75A-8) .
aConnect the battery ( (see Battery: Removal - Re-
fitting) ).
aUnlock the airbag computer using the Diagnostic
tool (see MR 413 Fault finding, 88C, Airbags and
seat belt pretensioners, Fault finding - Replace-
ment of components).

78A-1
REAR SEAT TRIM
Rear seat base trim: Removal - Refitting
78A
REMOVAL
I - REMOVAL PREPARATION OPERATION
aRemove:
-the complete rear seat (see 76A, Rear seat fra-
mes and mechanisms, Complete rear seat: Re-
moval - Refitting, page 76A-1) ,
-the rear seatback trim (see 78A, Rear seat trim,
Rear seatback trim: Removal - Refitting, page
78A-4) .
II - OPERATION FOR REMOVAL OF PART
CONCERNED
aDrill out rivets (1) .
aRemove the front lower retaining sections.aRemove the side retaining sections (2) .
aRemove the under seat trim (3) . Special tooling required
Car. 1521Clip cr imping pliers.
120857
120858
120860

78A-2
REAR SEAT TRIM
Rear seat base trim: Removal - Refitting
78A
aRemove the retaining sections (4) .
aCut the clips (5) using a cutting tool.aUnclip the seatback tilting mechanism (6) .
aRemove:
-the rear seat belt buckle ( (see Rear seat belt buc-
kle: Removal - Refitting) ),
-the retaining sections (7) ,
-the rear seat cushion trim.
120861
120862120882
120884

78A-3
REAR SEAT TRIM
Rear seat base trim: Removal - Refitting
78A
REFITTING
I - REFITTING OPERATION FOR PART
CONCERNED
aRefit:
-the rear seat cushion trim,
-the retaining sections (7) ,
-the rear seat belt buckle ( (see Rear seat belt buc-
kle: Removal - Refitting) ).
aClip on the seatback tilting mechanism (6) .
aRefit:
-the clips (5) (available from the Spare Parts De-
partment) using the (Car. 1521),
-the retaining sections (4) ,
-the under seat trim (3) ,
-the side retaining sections (2) ,
-the front lower retaining sections.
aRefit the rivets (1) .
II - FINAL OPERATION.
aRefit:
-the rear seatback trim (see 78A, Rear seat trim,
Rear seatback trim: Removal - Refitting, page
78A-4) ,
-the complete rear seat (see 76A, Rear seat fra-
mes and mechanisms, Complete rear seat: Re-
moval - Refitting, page 76A-1) .

78A-4
REAR SEAT TRIM
Rear seatback trim: Removal - Refitting
78A
REMOVAL
I - REMOVAL PREPARATION OPERATION
aRemove the complete rear seat (see 76A, Rear seat
frames and mechanisms, Complete rear seat:
Removal - Refitting, page 76A-1) .
II - OPERATION FOR REMOVAL OF PART
CONCERNED
aUndo the backrest zip fastener.aPartially remove the seatback cover.
aCut the clips (1) using a cutting tool.
aUnclip the headrest guides (2) .
aRemove:
-the seatback cover,
-the seatback foam. Special tooling required
Car. 1521Clip cr imping pliers.
Car. 1558Pliers for zip fasteners.
120853
120854
120855

78A-5
REAR SEAT TRIM
Rear seatback trim: Removal - Refitting
78A
REFITTING
I - REFITTING OPERATION FOR PART
CONCERNED
aRefit:
-the seatback foam,
-the seatback cover partially.
aClip on the headrest guides (2) .
aFit the clips (1) (available from the Spare Parts De-
partment) using the (Car. 1521).
aClose the backrest zip fastener using the (Car.
1558).
II - FINAL OPERATION.
aRefit the complete rear seat (see 76A, Rear seat
frames and mechanisms, Complete rear seat:
Removal - Refitting, page 76A-1) .

78A-6
REAR SEAT TRIM
Single unit rear bench seatback trim: Removal - Refitting78A
REMOVAL
I - REMOVAL PREPARATION OPERATION
aRemove the rear bench seatback (see 76A, Rear
seat frames and mechanisms, Rear bench seat-
back: Removal - Refitting, page 76A-5) .
II - OPERATION FOR REMOVAL OF PART
CONCERNED
aOpen the zip fasteners.
aRemove:
-the retaining sections (1) ,
-the clips (2) ,
-the « cover - foam » assembly.aCut the clips (3) using a cutting tool.
aRemove the cover from the foam.
REFITTING
I - REFITTING OPERATION FOR PART
CONCERNED
aRefit the cover on the foam.
aFit the clips (3) (available from the Spare Parts De-
partment) using the (Car. 1521).
aRefit:
-the « cover - foam » assembly onto the rear bench
seatback frame,
-the clips (2) ,
-the retaining strips (1) .
aClose the zip fasteners .
II - FINAL OPERATION.
aRefit the rear bench seatback (see 76A, Rear seat
frames and mechanisms, Rear bench seatback:
Removal - Refitting, page 76A-5) . Special tooling required
Car. 1521Clip cr imping pliers.
120806
120807
120808
