2009 RENAULT SCENIC Automatic Transmission AJ0 BVA Workshop Manual

2Transmission
V3 MR-372-J84-23A000$TOC.mif
V3
23A
"The repair procedures given by the manufacturer in this document are based on the
technical specifications current when it was prepared.
The procedures may be modified as a result of changes introduced by the
manufacturer in the production of the various component units and accessories from
which his vehicles are constructed."
V3
All rights reserved by Renault s.a.s.
Edition Anglaise
Copying or translating, in part or in full, of this document or use of the service part
reference numbering system is forbidden without the prior written authority of
Renault s.a.s.
© Renault s.a.s. 2009
AUTOMATIC TRANSMISSION
AJ0 BVA
Vdiag No.: 04, 05
Fault finding - Introduction 23A - 2
Fault finding - List and location of components 23A - 7
Fault finding - Role of components 23A - 9
Fault finding - Operating diagram 23A - 10
Fault finding - Role of components 23A - 12
Fault finding - Replacement of components 23A - 21
Diagnostics - Configuration and programming 23A - 25
Fault finding - Fault summary table 23A - 26
Fault finding - Interpretation of faults 23A - 28
Fault finding - Conformity check 23A - 114
Fault finding - Status summary table 23A - 115
Fault finding - Interpretation of statuses 23A - 116
Fault finding - Parameter summary table 23A - 134
Fault finding - Interpretation of parameters 23A - 135
Fault finding - Command summary table 23A - 145
Fault finding - Interpretation of commands 23A - 146
Fault finding - Customer complaints 23A - 155
Fault finding - Fault Finding Chart 23A - 156

AUTOMATIC TRANSMISSION
Fault finding - Introduction
23A
23A-2V3 MR-372-J84-23A000$045.mif
123A
AJ0 BVA
Vdiag No.: 04, 05AUTOMATIC TRANSMISSION
Fault finding - Introduction
1. SCOPE OF THIS DOCUMENT
This document presents the fault finding procedure applicable to all computers with the following specifications:
2. PREREQUISITES FOR FAULT FINDING
Documentation type:
Fault finding procedures (this document):
–Assisted fault finding (integrated into the diagnostic tool), Dialogys.
Wiring Diagrams:
–Visu-Schéma (CD-ROM)
Type of diagnostic tools:
–CLIP
Special tooling required:
3. REMINDERS
Procedure
To perform fault finding on the vehicle's computers, switch on the ignition in fault finding mode.
Proceed as follows:
–vehicle's card in reader;
–press and hold the Start button (longer than 5 seconds) with start-up conditions not fulfilled,
–connect the diagnostic tool and perform the required operations.
To cut off the + after ignition feed, proceed as follows:
–disconnect the diagnostic tool,
–press the Start button twice briefly (less than 3 seconds),
–ensure that the + after ignition feed has been cut off by checking that the computer indicator lights on the
instrument panel have gone out. Vehicle(s): SCENIC II ph2
Function concerned: Automatic transmissionName of computer: Automatic transmission
Vdiag No.: 04, 05
Special tooling required
Multimeter
Elé. 1681Universal bornier
AJ0_V04_PRELI/AJ0_V05_PRELI
MR-372-J84-23A000$045.mif

AUTOMATIC TRANSMISSION
Fault finding - Introduction
23A
23A-3V3 MR-372-J84-23A000$045.mif
AJ0 BVA
Vdiag No.: 04, 05
Faults
Faults are declared present or stored (depending on whether they appeared in a certain context and have
disappeared since, or whether they remain present but are not diagnosed within the current context).
The present or stored status of faults should be considered when using the diagnostic tool after the + after ignition
feed is switched on (without any action on the system components).
For a present fault, apply the procedure described in the Interpretation of faults section.
For a stored fault, note the faults displayed and apply the Notes section.
If the fault is confirmed when the instructions are applied, the fault is present. Deal with the fault.
If the fault is not confirmed, check:
–the electrical lines which correspond to the fault,
–the connectors for these lines (for oxidation, bent pins, etc.),
–the resistance of the component detected as faulty,
–the condition of the wires (melted or split insulation, wear).
Conformity check
The aim of the conformity check is to check data that does not produce a fault on the diagnostic tool when the data
is inconsistent. Therefore, this stage is used to:
–carry out fault finding on faults that do not have a fault display, and which may correspond to a customer
complaint.
–check that the system is operating correctly and that there is no risk of a fault recurring after repairs.
This section gives the fault finding procedures for statuses and parameters and the conditions for checking them.
If a status is not behaving normally or a parameter is outside the permitted tolerance values, consult the
corresponding fault finding page.
Customer complaints - Fault finding chart
If the test with the diagnostic tool is OK but the customer complaint is still present, the fault should be processed by
customer complaints.
A synopsis of the general procedure to follow is provided on the following page in the
form of a flow chart.

AUTOMATIC TRANSMISSION
Fault finding - Introduction
23A
23A-4V3 MR-372-J84-23A000$045.mif
AJ0 BVA
Vdiag No.: 04, 05
4. FAULT FINDING PROCEDURE
Perform a pre-diagnostic on the
system
Print the system fault finding log
(available on CLIP and in the
Workshop Repair Manual or
Technical Note)
Connect CLIP
no
Dialogue with
computer?
yes
Read the faults
no
Faults present
yes
Deal with present faults
Deal with stored faults
no
The cause is still
presentFault
solved
yes
See ALP no. 1
Conformity check
no
The cause is still
presentFault
solved
yes
Use fault finding charts (ALPs)
no
The cause is still
presentFault
solved
yes
Contact the Techline with the
completed fault finding log

AUTOMATIC TRANSMISSION
Fault finding - Introduction
23A
23A-5V3 MR-372-J84-23A000$045.mif
AJ0 BVA
Vdiag No.: 04, 05
4. FAULT FINDING PROCEDURE (continued)
Wiring check
Fault finding problems
Disconnecting the connectors and/or manipulating the wiring may temporarily remove the cause of a fault.
Electrical measurements of voltage, resistance and insulation are generally correct, especially if the fault is not
present when the analysis is made (stored fault).
Visual inspection
Look for damage under the bonnet and in the passenger compartment.
Carefully check the fuses, insulators and wiring harness routing.
Look for signs of oxidation.
Physical inspection
While manipulating the wiring, use the diagnostic tool to note any change in fault status from stored to present.
Make sure that the connectors are properly locked.
Apply light pressure to the connectors.
Twist the wiring harness.
If there is a change in status, try to locate the source of the fault.
Inspection of each component
Disconnect the connectors and check the appearance of the clips and tabs, as well as the crimping (no crimping on
the insulating section).
Make sure that the clips and tabs are properly locked in the sockets.
Check that no clips or tabs have been dislodged during connection.
Check the clip contact pressure using an appropriate model of tab.
Resistance check
Check the continuity of entire lines, then section by section.
Look for a short circuit to earth, to + 12 V or with another wire.
If a fault is detected, repair or replace the wiring harness.

AUTOMATIC TRANSMISSION
Fault finding - Introduction
23A
23A-6V3 MR-372-J84-23A000$045.mif
AJ0 BVA
Vdiag No.: 04, 05
5. FAULT FINDING LOG
You will always be asked for this log:
●when requesting technical assistance from Techline,
●for approval requests when replacing parts for which approval is mandatory,
●to be attached to monitored parts for which reimbursement is requested. The log is needed for warranty
reimbursement, and enables better analysis of the parts removed.
6. SAFETY INSTRUCTIONS
Safety rules must be observed during any work on a component to prevent any damage or injury:
–check the battery voltage to avoid incorrect operation of computer functions,
–use the proper tools. IMPORTANT!IMPORTANT
Any fault on a complex system requires thorough fault finding with the appropriate tools. The
FAULT FINDING LOG, which should be completed during the fault finding procedure, ensures a
record is kept of the procedure carried out. It is an essential document when consulting the
manufacturer.
IT IS THEREFORE MANDATORY TO FILL OUT A FAULT FINDING LOG EACH TIME FAULT FINDING IS
CARRIED OUT.

AUTOMATIC TRANSMISSION
Fault finding - List and location of components23A
23A - 7V3 MR-372-J84-23A000$090.mif
AJ0 BVA
Vdiag No.: 04, 05AUTOMATIC TRANSMISSION
Fault finding - List and location of components
*LS: line pressure.
*EVS: sequence solenoid valve.Number Description
1Oil temperature sensor
2Clutch 1 solenoid valve
3Clutch 2 solenoid valve
4Clutch 3 solenoid valve
5LS* pressure regulation solenoid valve
6"EVS1"* shift solenoid
7"EVS2"* shift solenoid
8Converter lock-up and brake 1 solenoid valve
9Brake 2 solenoid valve
10 Clutch 1 solenoid valve pressure switch
11 Clutch 2 solenoid valve pressure switch
12 Clutch 3 solenoid valve pressure switch
13 Brake 1 solenoid valve pressure switch
14 Brake 2 solenoid valve pressure switch
MR-372-J84-23A000$090.mif

AUTOMATIC TRANSMISSION
Fault finding - List and location of components23A
23A - 8V3 MR-372-J84-23A000$090.mif
AJ0 BVA
Vdiag No.: 04, 05
