2009 KIA Sedona Owner's Manual

Page 321 of 356

KIA Sedona 2009 2.G Owners Manual 619
Maintenance
Front windshield wiper blade1. Raise the wiper arm and turn the wiperblade assembly to expose the plastic
locking clip.
2. Compress the clip and slide the bladeassembly downward.
3. Li

Page 322 of 356

KIA Sedona 2009 2.G Owners Manual Maintenance20
6FUSESA vehicle’s electrical system is protected
from electrical overload damage by
fuses. This vehicle has three fuse panels, one
located in the driver’s side panel bolster,
another

Page 323 of 356

KIA Sedona 2009 2.G Owners Manual 621
Maintenance
Engine compartment1. Turn the ignition switch and all otherswitches off.
2. Remove the fuse box cover by press- ing the tap and pulling up.
3. Check the removed fuse; replace it if it

Page 324 of 356

KIA Sedona 2009 2.G Owners Manual Maintenance22
63. Pull the suspected fuse straight out.
Use the removal tool provided on the
main fuse box in the engine compart-
ment.
4. Check the removed fuse; replace it if it is blown.Spare fuses

Page 325 of 356

KIA Sedona 2009 2.G Owners Manual 623
Maintenance
Fuse/Relay panel descriptionInside the fuse/relay box covers, you can find the fuse/relay label describing fuse/relay
name and capacity.Driver’s side panel
Engine compartmentOVA06701

Page 326 of 356

KIA Sedona 2009 2.G Owners Manual Maintenance24
6Drivers side fuse panel
Description Fuse rating Protected component
AUDIO15A Audio, Step lamp
MEMORY 7.5A Climate control module, Clock, Cluster, Trip computer, Front area module, Powe

Page 327 of 356

KIA Sedona 2009 2.G Owners Manual 625
Maintenance
Description Fuse ratingProtected component
ENG7.5A Automatic shift lever switch, Vehicle speed sensor, Inhibitor switch, Transaxle control module,
Input speed sensor, Output speed sen

Page 328 of 356

KIA Sedona 2009 2.G Owners Manual Maintenance26
6
Description Fuse rating Protected component
P/TRAIN 7.5A Theft alarm relay, Main relay,
TCM, Generator, ECM, Injector
15A, ECU 2 15A, ECU 1 10A,
Air conditioner compressor relay,
Inlet
