Vehicle identification

VEHICLE IDENTIFICATION PLATE
The Vehicle Identification Number (VIN) and
recommended maximum vehicle weights, are
shown on a plate adhered to the hinge side of
the left-hand (right-hand in China) front door.
VIN should match the VIN recorded in the
Service Portfolio, and the VIN visible through
the windscreen.
ENGINE NUMBER
Note: To access the number, it may be
necessary to remove the engine covers. For
further assistance, contact your Dealer/
Authorised Repairer.
V6 Petrol engines
The number is located on the lower left-hand
side of the cylinder bloc k, near the bedplate.
V8 Petrol engines
The number is located on the front of the
right-hand cam cover.
Diesel engines
The number is located on a metal label attached
to the top of the left-hand camshaft cover
TRANSMISSION NUMBER
The transmission number is located on a label
attached to the transmission casing.
VEHICLE IDENTIFICATION NUMBER
(VIN)
As a deterrent to thieves, and to assist the
Police, the VIN is stamped on a plate which is
visible through the lowest part of the left side of
the windscreen.
Note: If you need to communicate with a
Dealer/Authorised repairer, you may be asked
to quote the VIN number.
VEHICLE BUILD DATE PLATE
This is the calendar mont h and year in which
the body and power train assemblies were
conjoined and the vehicle was driven from the
production line.
The vehicle built date is shown on the VIN
plate.
E95305
E95306

Technical specifications
258


ENGINE SPECIFICATIONS
DataV6 Diesel
Number of cylinders 6
Displacement 2998 cc
Compression ratio 16:1
DataV6 Petrol
Number of cylinders 6
Displacement 2967 cc
Compression ratio 10.5:1
DataV8 Normally Aspirated Petrol
Number of cylinders 8
Displacement 5000 cc
Compression ratio 11.5:1
DataV8 Supercharged Petrol
Number of cylinders 8
Displacement 5000 cc
Compression ratio 9.5:1

259
Technical specifications

WEIGHTS
Note: ¹The maximum permitted lugga ge compartment load can be exceeded, provided the
requirements regarding the maximu m permissible axle weights and tyre pressures are followed.
¹ The maximum permissible weight of the vehicle incl uding passengers and load.
² The front and rear axle maximum loads can not be reached simultaneously as this will exceed the
GVW limit.
³ The maximum permissible weight of the vehicle and braked trailer including their respective loads.
Variant Vehicle weight
fromFront axle weight
from Rear axle weight
from Max. luggage
compartment load¹
V6 Diesel 1820 kg 4012 lbs1016 kg
2240 lbs 804 kg
1772 lbs 35 kg
77 lbs
V6 Petrol 1679 kg 3702 lbs 878 kg
1936 lbs 801 kg
1766 lbs 35 kg
77 lbs
V8 Normally
Aspirated Petrol 1780 kg
3924 lbs 961 kg
2119 lbs 819 kg
1806 lbs 35 kg
77 lbs
V8 Supercharged Petrol 1891 kg
4169 lbs 1022 kg
2253 lbs 869 kg
1916 lbs 35 kg
77 lbs
Variant Gross Vehicle
Weight (GVW)¹ Maximum front
axle load² Maximum rear
axle load² Gross Train
Weight³
V6 Diesel 2360 kg 5203 lbs 1200 kg
2646 lbs 1215 kg
2679 lbs 4210 kg
9281 lbs
V6 Petrol 2215 kg 4883 lbs 1090 kg
2403 lbs 1180 kg
2601 lbs 4065 kg
8962 lbs
V8 Normally
Aspirated Petrol 2285 kg
5038 lbs 1130 kg
2491 lbs 1200 kg
2646 lbs Not
Applicable
V8 Supercharged Petrol 2345 kg
5170 lbs 1165 kg
2568 lbs 1200 kg
2646 lbs Not
Applicable

Technical specifications
260

DIMENSIONS
¹ Narrowest dimension applies to 20 inch wheels only.
E95307
1
2
3
4
5
6
7
Item Description mm/inches
1 Width 2053/80.5
2 Width with mirrors folded 1877/74.0
3 Track - front 1559/61.4
4 Maximum height 1460/57.5
5 Track - rear¹ 1571-1605/61.9-63.2
6 Wheelbase 2909/114.5
7 Length excluding numbe r plate plinth 4961/195.3
- Turning circle (kerb to kerb)11.5 m/37.7 ft.

261
Technical specifications

Wheel alignment data (China only)
Brake pedal travel (China only)
The brake pedal travel is set at the factory and
is non-adjustable.Wheel alignment - front
+0.25°
Wheel alignment - rear +0.13°
Camber - front -0.30°
Camber - rear -0.69°
Castor - front 6.61°
Castor - rear non-adjustable

Type approvals
262

DECLARATIONS OF CONFORMITY
E97083

263
Type approvals

E97084

Type approvals
