2009 INFINITI QX56 air condition

A
B
C
D
E
F
G
H
I
J
K
L
M
N
P
O
QUICK REFERENCE INDEX
AGENERAL INFORMATIONGIGeneral Information
BENGINEEMEngine Mechanical
LUEngine Lubrication System
COEngine Cooling System
ECEngine Control System
FLFuel System
EXExhaust System
STRStarting System
ACCAccelerator Control System
CHYBRIDHBCHybrid Control System
HBBHybrid Battery System
HBRHybrid Brake System
DTRANSMISSION & DRIVE-
LINETMTransaxle & Transmission
DLNDriveline
FAXFront Axle
RAXRear Axle
ESUSPENSIONFSUFront Suspension
RSURear Suspension
SCSSuspension Control System
WTRoad Wheels & Tires
FBRAKESBRBrake System
PBParking Brake System
BRCBrake Control System
GSTEERINGSTSteering System
STCSteering Control System
HRESTRAINTSSBSeat Belt
SBCSeat Belt Control System
SRSRS Airbag
SRCSRS Airbag Control System
IVENTILATION, HEATER &
AIR CONDITIONERVTLVentilation System
HAHeater & Air Conditioning System
HACHeater & Air Conditioning Control System
JBODY INTERIORINTInterior
IPInstrument Panel
SESeat
ADPAutomatic Drive Postioner
APAdjustable Pedal
KBODY EXTERIOR,
DOORS, ROOF & VEHICLE
SECURITYDLKDoor & Lock
SECSecurity Control System
GWGlass & Window System
PWCPower Window Control System
RFRoof
EXTExterior
BRMBody Repair Manual
LDRIVER CONTROLSMIRMirrors
EXLExterior Lighting System
INLInterior Lighting System
WWWiper & Washer
DEFDefogger
HRNHorn
MELECTRICAL & POWER
CONTROLPWOPower Outlet
BCSBody Control System
LANLAN System
PCSPower Control System
CHGCharging System
PGPower Supply, Ground & Circuit Elements
NDRIVER INFORMATION &
MULTIMEDIAMWIMeter, Warning Lamp & Indicator
WCSWarning Chime System
SNSonar System
AVAudio, Visual & Navigation System
OCRUISE CONTROLCCSCruise Control System
PMAINTENANCEMAMaintenance
All rights reserved. No part
of this Service Manual may
be reproduced or stored in a
retrieval system, or transmit-
ted in any form, or by any
means, electronic, mechani-
cal, photo-copying, record-
ing or otherwise, without the
prior written permission of
Nissan North America, Inc.
Edition: June 2008
Revision: December 2009
Publication No. SM9
E-1J60U1

2009
QUICK REFERNCE CHART: QX56
Front Disc Brake
INFOID:0000000005987155
Unit: mm (in)
Rear Disc BrakeINFOID:0000000005987156
Unit: mm (in)
Fluids and LubricantsINFOID:0000000005987154
Brake model AD41VA
Brake pad Standard thickness (new) 12.0 (0.476)
Repair limit thickness 1.0 (0.039)
Disc rotor Standard thickness (new) 30 (1.181)
Repair limit thickness 28.5 (1.122)
Maximum uneven wear (measured at 8 positions) 0.015 (0.0006)
Runout limit (with it attached to the vehicle) 0.03 (0.001)
Brake model
AD14VE
Brake pad Standard thickness (new) 12.0 (0.472)
Repair limit thickness 1.0 (0.039)
Disc rotor Standard thickness (new) 14.0 (0.551)
Repair limit thickness 12.5 (0.492)
Maximum uneven wear (measured at 8 positions) 0.015 (0.0006)
Runout limit (with it attached to the vehicle) 0.05 (0.002)
Description
Capacity (Approximate)
Metric US measure Imp measure
Fuel 105.8 28 gal 23 1/4 gal
Engine oil
Drain and refill With oil filter change
6.5 6 7/8 qt 5 3/4 qt
Without oil filter change 6.2 6 1/2 qt 5 1/2 qt
Dry engine (engine overhaul) 7.6 8 qt 6 3/4 qt
Cooling system With reservoir
at MAX level
14.4
15 1/4 qt 12 5/8 qt
Automatic transmission fluid (ATF) 10.6 11 1/4 qt 9 3/8 qt
Rear differential gear oil 1.75 3 3/4 pt 3 1/8 pt
Transfer fluid 3.0 3 1/8 qt 2 5/8 qt
Front differential gear oil 1.6 3 3/8 pt 2 7/8 pt
Power steering fluid (PSF) 1.0 1 1/8 qt 7/8 qt
Brake fluid — — —
Brake grease — — —
Multi-purpose grease — — —
Windshield washer fluid 4.5 4 3/4 qt 4 qt
Air conditioning system refrigerant 1.08 ± 0.05 kg 2.38 ± 0.11 lb 2.38 ± 0.11 lb
Air conditioning system oil 290 m9.8 fl oz 10.2 fl oz

ADP-3
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
RECLINING SENSOR .................................... ....76
Description .......................................................... ....76
Component Function Check ..................................76
Diagnosis Procedure ..............................................76
LIFTING SENSOR (FRONT) ..............................78
Description .......................................................... ....78
Component Function Check ..................................78
Diagnosis Procedure ..............................................78
LIFTING SENSOR (REAR) ................................80
Description .......................................................... ....80
Component Function Check ..................................80
Diagnosis Procedure ..............................................80
TILT SENSOR ....................................................82
Description .......................................................... ....82
Component Function Check ..................................82
Diagnosis Procedure ..............................................82
PEDAL ADJUSTING SENSOR ..........................84
Description .......................................................... ....84
Component Function Check ..................................84
Diagnosis Procedure ..............................................84
MIRROR SENSOR .............................................86
DRIVER SIDE ........................................................ ....86
DRIVER SIDE : Description ....................................86
DRIVER SIDE : Component Function Check ........86
DRIVER SIDE : Diagnosis Procedure ....................86
PASSENGER SIDE ...................................................88
PASSENGER SIDE : Description ....................... ....88
PASSENGER SIDE :
Component Function Check ..................................
88
PASSENGER SIDE : Diagnosis Procedure ...........88
SLIDING MOTOR ...............................................90
Description .......................................................... ....90
Component Function Check ..................................90
Diagnosis Procedure ..............................................90
RECLINING MOTOR ..........................................92
Description .......................................................... ....92
Component Function Check ..................................92
Diagnosis Procedure ..............................................92
LIFTING MOTOR (FRONT) ................................94
Description .......................................................... ....94
Component Function Check ..................................94
Diagnosis Procedure ..............................................94
LIFTING MOTOR (REAR) ..................................96
Description .......................................................... ....96
Component Function Check ..................................96
Diagnosis Procedure ..............................................96
TILT MOTOR ......................................................98
Description .......................................................... ....98
Component Function Check ..................................98
Diagnosis Procedure ..............................................98
PEDAL ADJUSTING MOTOR ........................100
Description ........................................................... ..100
Component Function Check ................................100
Diagnosis Procedure ............................................100
DOOR MIRROR MOTOR ................................102
Description .............................................................102
Component Function Check ..................................102
Diagnosis Procedure .............................................102
Component Inspection ...........................................104
SEAT MEMORY INDICATOR LAMP ..............105
Description .............................................................105
Component Function Check ................................105
Diagnosis Procedure ............................................105
Component Inspection ...........................................106
ECU DIAGNOSIS .......................................107
DRIVER SEAT CONTROL UNIT ....................107
Reference Value .................................................. ..107
Wiring Diagram ......................................................112
Fail Safe ................................................................126
DTC Index .............................................................127
AUTOMATIC DRIVE POSITIONER CON-
TROL UNIT ......................................................
128
Reference Value ....................................................128
Wiring Diagram ......................................................131
BCM (BODY CONTROL MODULE) ...............146
Reference Value ....................................................146
Terminal Layout .....................................................148
Physical Values .....................................................148
Wiring Diagram ......................................................154
SYMPTOM DIAGNOSIS ............................159
ADP SYSTEM SYMPTOMS ............................159
Symptom Table ................................................... ..159
NORMAL OPERATING CONDITION .............161
Description .............................................................161
PRECAUTION ............................................162
PRECAUTIONS ...............................................162
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ..
162
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect .................................
162
Precaution for Work ...............................................163
PREPARATION .........................................164
PREPARATION ...............................................164
Special Service Tool ............................................ ..164
Commercial Service Tool ......................................164
ON-VEHICLE REPAIR ...............................165
Revision: December 20092009 QX56

ADP-6
< BASIC INSPECTION >
DIAGNOSIS AND REPAIR WORKFLOW
1. GET INFORMATION FOR SYMPTOM
Get the detailed information from the customer about the symptom (the condition and the environment when
the incident/malfunction occurred).
>> GO TO 2
2. CHECK DTC WITH AUTOMATIC DRIVE POSITIONER SYSTEM
Check “Self Diagnostic Result” with CONSULT-III.
Refer to ADP-127, "DTC Index"
.
Is any symptom described and any DTC is displayed?
Symptom is described, DTC is displayed.>>GO TO 3
Symptom is not described, DTC is displayed.>>GO TO 7
Symptom is described, DTC is not displayed.>>GO TO 4
3. CONFIRM THE SYMPTOM
Try to confirm the symptom described by the customer.
>> GO TO 7
4. CONFIRM THE SYMPTOM
Try to confirm the symptom described by the customer.
>> GO TO 5
5. CHECK NORMAL OPERATING CONDITION
Check normal operating condition. Refer to ADP-161, "Description"
.
Is the incident normal operation?
YES >> Inspection End.
NO >> GO TO 6
6. PERFORM BASIC INSPECTION
Isolate the malfunctioning point with the basic inspection. Refer to ADP-8, "Preliminary Check"
.
>> GO TO 8
7. PERFORM DTC CONFIRMATION PROCEDURE
Perform the confirmation procedure for the detected DTC.
Is the DTC displayed?
YES >> GO TO 9
NO >> Check intermittent incident. Refer to GI-38, "Intermittent Incident"
.
8. PERFORM COMPONENT FUNCTION CHECK
Perform the component function check for the isolated malfunctioning point.
>> GO TO 9
9. DETECT MALFUNCTIONING PART BY DIAGNOSTIC PROCEDURE
Isolate the malfunctioning point by performing the di agnosis procedure relevant to the symptom during the
component diagnosis.
>> GO TO 10
10. REPAIR OR REPLACE
Repair or replace the malfunctioning part.
Revision: December 20092009 QX56

PRE-INSPECTION FOR DIAGNOSTICADP-9
< BASIC INSPECTION >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
PRE-INSPECTION FOR DIAGNOSTIC
Basic InspectionINFOID:0000000004055281
1. CHECK POWER SUPPLY AND DROUND CIRCUIT
Check the power supply and ground circuit as shown below.
 Driver seat control unit: Refer to ADP-47, "DRIVER SEAT CONTROL UNIT : Diagnosis Procedure"
.
 Automatic drive positioner control unit: Refer to ADP-47, "AUTOMATIC DRIVE POSITIONER CONTROL
UNIT : Diagnosis Procedure".
Is the inspection result normally?
YES >> GO TO 2
NO >> Repair or replace the malfunctioning part.
2. CHECK MANUAL FUNCTION
Check the manual function operati ons by operating the relevant switches as shown below.
 Seat (slide, reclining, lifting front, lifting rear)
 Pedal assembly (forward, backward)
 Steering wheel (upward, downward)
 Door mirror
Do all manual functions operate normally?
YES >> GO TO 3
NO (Seat, pedal, door mirror)>>Go to SYMPTOM 1, refer to ADP-159, "Symptom Table"
. And, GO TO 4 if
the result of SYMPTOM 1 is OK.
3. CHECK MEMORY FUNCTION 1
Register the seat positions (refer to Owner’s Manual) and check that all parts of the seat, pedals, steering
wheel and door mirrors move to their memory positions correctly.
Are the operations normal?
YES >> Check each malfunction according to the instruction of the SYMPTOM 4, refer to ADP-159,
"Symptom Table".
No (memory indicator operates normally)>> Go to SYMPTOM 2, refer to ADP-159, "Symptom Table"
.
No (memory indicator does not operate normally either)>> GO TO 5
4. CHECK MEMORY FUNCTION 2
Register the seat positions (refer to Owner’s Manual) and check that all parts of the seat, pedals, steering
wheel and door mirrors move to their memory positions correctly.
Are the operations normal?
YES >> Check intermittent incident. Refer to GI-38, "Intermittent Incident".
NO >> GO TO 7
5. CHECK SEAT MEMORY SW ITCH/MEMORY INDICATOR
Check the seat memory switch/memory switch indicator of the SYMPTOM 5, refer to ADP-159, "Symptom
Table".
Is the inspection result normal?
YES >> GO TO 6
NO >> Repair or replace the malfunctioning part.
6. CHECK OPERATION CONDITION
Check the memory operation conditions (refer to ADP-12, "AUTOMATIC DRIVE POSITIONER SYSTEM :
System Description").
Are all operation conditions fulfilled?
YES >> Go to SYMPTOM 6, refer to ADP-159, "Symptom Table".
NO >> Fulfill the operation conditions. Refer to ADP-12, "AUTOMATIC DRIVE POSITIONER SYSTEM :
System Description".
7. CHECK MECHANISM
Check for the following.
Revision: December 20092009 QX56

U1000 CAN COMM CIRCUITADP-31
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
COMPONENT DIAGNOSIS
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000003775516
Refer to LAN-4, "System Description".
DTC LogicINFOID:0000000003775517
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1. STEP 1
Turn ignition switch ON and wait at least 3 seconds.
>> GO TO 2
2. STEP 2
Check “Self diagnostic result” with CONSULT-III.
Is the DTC detected?
YES >> Perform diagnosis procedure. Refer to LAN-14, "Trouble Diagnosis Procedure".
NO >> Inspection End.
Special Repair RequirementINFOID:0000000003775519
Refer to Owner’s Manual.
DTC Trouble diagnosis
name DTC detecting condition Possible cause
U1000 CAN COMM CIR-
CUIT  Driver seat control unit cannot communicate to other
control units.
 Driver seat control unit c annot communicate for more
than the specified time.  Harness or connectors
(CAN communication line is
open or shorted)
Revision: December 20092009 QX56

ADP-36
< COMPONENT DIAGNOSIS >
B2117 ADJ PEDAL MOTOR
B2117 ADJ PEDAL MOTOR
DescriptionINFOID:0000000003775532
 The pedal adjusting motor is installed to the pedal assembly.
 The pedal adjusting motor is activated with the automatic drive positioner control unit.
 The pedal assembly is adjusted forward/backward by changing the rotation direction of pedal adjustingmotor.
DTC LogicINFOID:0000000003775533
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1. STEP 1
Turn ignition switch ON.
>> GO TO 2
2. STEP 2
Check “Self diagnostic result” with CONSULT-III.
Is the DTC detected?
YES >> Perform diagnosis procedure. Refer to ADP-36, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000003775534
1. CHECK PEDAL ADJUSTING MECHANISM
Check the following.
 Operation malfunction caused by pedal adjusting mech anism deformation or pinched harness or other for-
eign materials
 Operation malfunction and interference wit h other parts by poor installation
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace the malfunctioning part and check again.
2. CHECK FUNCTION
1. Turn ignition switch ON.
2. Check “ADJ PEDAL MOTOR” in "Active test" mode with CONSULT-III.
Is the inspection result normal?
YES >> Pedal adjusting motor circuit is OK.
NO >> GO TO 3
3. CHECK PEDAL ADJUSTING MOTOR CIRCUIT HARNESS CONTINUITY
DTC No. Trouble diagnosis
name DTC detecting condition Possible cause
B2117 ADJ PEDAL MOTOR When any manual or automatic operations are not
performed, if motor operation is detected for 0.1
second or more, status is judged "Output error".  Harness and connectors
(pedal adjusting motor circuit is
opened/shorted, pedal adjusting
motor power supp ly circuit is
opened/shorted.)
 Pedal adjusting motor
Test item Description
ADJ PEDAL MOTOR The pedal adjusting motor is activated by receiving the drive signal.
Revision: December 20092009 QX56

B2117 ADJ PEDAL MOTORADP-37
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit and pedal adjusting motor.
3. Check continuity between automat ic drive positioner control unit
connector M34 (A) terminals 37, 45 and pedal adjusting motor
connector E109 (B) terminals 1, 2.
4. Check continuity between automat ic drive positioner control unit
connector M34 (A) terminals 37, 45 and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair or replace harness.
4. CHECK AUTOMATIC DRIVE POSITION ER CONTROL UNIT OUTPUT SIGNAL
1. Connect the automatic drive positioner control unit and pedal adjusting motor assembly.
2. Check voltage between automatic drive positioner control unit
connector and ground.
Is the inspection result normal?
YES >> Replace pedal adjusting motor assembly. Refer to ADP-169, "Removal and Installation".
NO >> GO TO 5
5. CHECK INTERMITTENT INCIDENT
Refer to GI-38, "Intermittent Incident"
.
Is the inspection result normal?
YES >> Replace automatic drive posit ioner control unit. Refer to ADP-166, "Removal and Installation".
NO >> Repair or replace the malfunctioning part. 37 - 1 : Continuity should exist.
45 - 2 : Continuity should exist.
37 - Ground : Continuity should not exist.
45 - Ground : Continuity should not exist.
ALJIA0195ZZ
Connec-
tor Te r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
M34 37
Ground Pedal adjusting switch ON
(FORWARD operation)
Battery voltage
Other than above 0
45 Pedal adjusting switch ON
(BACKWARD operation)
Battery voltage
Other than above 0
PIIA4806E
Revision: December 20092009 QX56
