253
4,115 (162.0)
1,755 (69.1)
1,620 (63.8)
2,500 (98.4)
1,495 (58.9)
1,495 (58.9)
190 (7.5)
270/6704,115 (162.0)
1,755 (69.1)
1,620 (63.8)
2,500 (98.4)
1,495 (58.9)
1,495 (58.9)
190 (7.5)
270/6704,115 (162.0)
1,755 (69.1)
1,620 (63.8)
2,500 (98.4)
1,495 (58.9)
1,495 (58.9)
190 (7.5)
270/6704,115 (162.0)
1,755 (69.1)
1,620 (63.8)
2,500 (98.4)
1,495 (58.9)
1,495 (58.9)
190 (7.5)
270/670
DIMENSIONS 1.6 16V2.0 Multijet
Unit: mm (in.)
2WD 4WD 2WD 4WD
Overall length
Overall width
Overall height
Wheelbase
Track Front
Rear
Ground clearance (Standard A)
Boot volume dm3
WHEELS
Tyre size 205/60 R16
Rim size 16 x 6J
Tyre pressures Tyre inflation pressure values are specified on the label located on the driver’s door post.
When loaded up to 4 people, Eco Tire Pressure as listed below is recommended to achieve
the smallest amount of fuel consumption possible.
Front 280 kPa (2.80 kg/cm², 40 psi) - Rear 260 kPa (2.60 kg/cm², 38 psi)
NOTE If loading over 4 people, follow the specified tire pressure listed on the Tire Information
Label.
Recommended snow chains Radial/Axial thickness:
Recommended snow tire 195/65 R15, 205/60 R16
Wheel geometry Toe-in, front
Camber angle, front
2WD
4WD
Caster angle, front
2WD
4WD10 mm (0.39 in.)
1 ± 1 mm (0.0393 ± 0.0393 in.)
− 0° 23’ ± 1°
− 0° 10’ ± 1°
3° 40’ ± 2°
3° 32’ ± 2°
