126
To change the radio station:
❒To advance to the next preset station,
push the switch (5) briefly (only MP3
version).
❒To select the previous preset station,
push the switch (6) briefly (only MP3
version).
❒To scan the higher frequency radio
station, push and hold the switch (5).
❒To scan the lower frequency radio sta-
tion, push and hold the switch (6).
To scan the selection on a CD:
❒To advance to the next track on a CD,
push the switch (5).
❒To select the previous track on a CD,
push the switch (6).
For vehicle with navigation system
Refer to the chart below how to use the
switches on the steering wheel. REMOTE AUDIO CONTROLS
(for versions/markets, where provided)
You can control basic functions of the au-
dio system with the switches on the steer-
ing wheel. How to use the switches is dif-
ferent if the navigation system is equipped
or not.
For vehicle without navigation
system
To control the volume:
❒To increase the volume, push the
switch (1).
❒To decrease the volume, push the
switch (2).
❒To mute, push the switch (3).
To select the mode, push the switch (4).
You can also turn on the audio system by
pushing the switch (4).
(3)
(1)
(2)(4)
(5)
(6)
63J305
071-128 SEDICI LUM FL GB 1E 19-06-2009 12:05 Pagina 126
127
SwitchModeSwitch
operation
Tuner CD CD (MP3, WMA)
(1)
(2)
(3)
(4)
(5)
(6)
Push briefly
Push long
Push briefly
Push long
Push briefly
Push long
Push briefly
Push briefly
Push long
Push briefly
Push longincrease the
volume
increase the
volume rapidly
decrease the
volume
decrease the
volume rapidly
scan to a higher
frequency preset
radio station
scan to a lower
frequency preset
radio station
scan to a lower
frequency radio
station
scan to a lower
frequency radio
stationincoming call: answer call
(if installed with optional hands free device)
during a call: end call
(if installed with optional hands free device)
redialing
start the voice control (if installed with optional microphone)increase the
volume
increase the
volume rapidly
decrease the
volume
decrease the
volume rapidly
advance to
next track
fast forward
a track
return to
previous track
fast rewind
a track increase
the volume
increase the
volume rapidly
decrease the
volume
decrease the
volume rapidly
advance to
next track
advance to
next folder
return to
previous track
return to
previous folder Full map navigation system
(3)
(1)
(2)(4)
(5)
(6)
79J233
071-128 SEDICI LUM FL GB 1E 19-06-2009 12:05 Pagina 127
128
SwitchModeSwitch
operation
Music Catcher SD card (MP3, WMA)
(1)
(2)
(3)
(4)
(5)
(6)
Push briefly
Push long
Push briefly
Push long
Push briefly
Push long
Push briefly
Push briefly
Push long
Push briefly
Push longincrease the volume
increase the volume rapidly
decrease the volume
decrease the volume rapidly
advance to next track
advance to next folder
return to previous track
return to previous folderincoming call: answer call
(if installed with optional hands free device)
during a call: end call
(if installed with optional hands free device)
redialing
start the voice control (if installed with optional microphone)increase the volume
increase the volume rapidly
decrease the volume
decrease the volume rapidly
advance to next track
advance to next folder
return to previous track
return to previous folder
Full map navigation system
(3)
(1)
(2)(4)
(5)
(6)
79J233
