2009 FIAT SEDICI engine coolant

188
15 30 45 60 75 90 105 120 135 150 165 180
●●●●●●●●●●●●
●●●●●●●●●●●●
●●●●●●●●●●●●
●●●●●●●●●●●●
●●●●●●●●●●●●
●● ●●●●
●●●●●●●●●●●●
●●●●●●●●●●●●
●●
●●●●●●
●● ●●●●
●●●●●●●●●●●●
SERVICE SCHEDULE - DIESEL VERSIONS
Service coupons shall be carried out every 15,000 km
Thousands of km
Check tyre condition/wear and adjust pressure, if required
Check lighting system operation (headlights, direction indicators,
hazard lights, passenger compartment lights, boot lights,
instrument panel warning lights, etc.)
Check windscreen wiper/washer operation and adjust nozzles,
if required
Check the position/wear of the windscreen/rearscreen
wiper blades
Check condition and wear of front disc brake pads and brake
pad wear indication
Check rear disc brake pad or shoes condition and wear
Visually inspect the condition of: bodywork,
underbody protection, pipes and hoses (exhaust - fuel - brakes),
rubber parts (gaiters, sleeves, bushes, etc.)
Check and top up, if required, fluid levels (brake/hydraulic clutch
fluid, windscreen washer fluid, battery fluid, engine coolant, etc.)
Visually inspect condition of auxiliary drive belt
Check the handbrake lever travel and adjust it, if required
Check exhaust emissions
Check cleanliness of locks, bonnet and boot, and cleanliness and
lubrication of linkages
183-230 SEDICI LUM FL GB 1E 19-06-2009 11:00 Pagina 188

189
15 30 45 60 75 90 105 120 135 150 165 180
●● ●● ●● ●●
●●●●
●●●●
●
●
●●●
●●●●
●
●●●●
●●●●●●
●●●●●
●
●● ●●●●
●● ●●●●
●● ●●●●
●● ●●●●
●● ●●●●
Thousands of km
Change engine oil and oil filter (DPF versions) (**)
Check air cleaner conditions
Replace air filter cartridge
Change engine coolant
Replace auxiliary drive belt
Replace timing belt (*)
Replace fuel filter (or every 4 years)
Sight inspect fuel tank conditions
Check manual transaxle gear oil level
Change manual transaxle gear oil
Check transmission unit oil level (4x4 version)
Check rear differential oil level (4x4 version)
Change rear differential oil (4x4 version)
(just the first time at 15,000 km)
Check suspension operation
Check steering system
Check engine management system operation
(via diagnostic socket)
Change brake and clutch fluid (or every 2 years)
Replace pollen filter (or every 2 years)
(*) Regardless of the number of kilometres covered, the timing belt should be replaced every 4 years for particularly demanding use
(cold climates, driving in the city, idling for a long time) or in any case every 5 years.
(**) The engine oil and oil filter should be changed when the warning light on the dashboard comes on, or every 2 years.
183-230 SEDICI LUM FL GB 1E 19-06-2009 11:00 Pagina 189

198
IMPORTANT
To avoid damaging your cooling system:
❒Always use a high quality ethylene gly-
col base non- silicate type coolant di-
luted with distilled water at the correct
mixture concentration.
❒Make sure that the proper mix is 50/50
coolant to distilled water and in no case
higher than 70/30. Concentrations
greater than 70/30 coolant to distilled
water will cause overheating conditions.
❒Do not use straight coolant nor plain
water.
❒Do not add extra inhibitors or addi-
tives. They may not be compatible with
your cooling system.
❒Do not mix different types of base
coolants. Doing so may result in accel-
erated seal wear and/ or the possibili-
ty of severe overheating and extensive
engine/automatic transaxle damage.
ENGINE COOLANT
SELECTION OF COOLANT
To maintain optimum performance and
durability of your engine, use PARAFLU
UP.
This type of coolant is best for your cool-
ing system as it:
❒Helps maintain proper engine temper-
ature.
❒Gives proper protection against freez-
ing and boiling.
❒Gives proper protection against cor-
rosion and rust.
Failure to use the proper coolant can dam-
age your cooling system. Your authorized
Fiat Dealership can help you select the
proper coolant.
56KN090
For Gasoline Engine
Model
COOLANT LEVEL CHECK
Check the coolant level at the reservoir
tank, not at the radiator. With the engine
cool, the coolant level should be between
the “FULL” and “LOW” marks.
LOWFUL
L FULLFULL
79JM015
For Diesel Engine Model
183-230 SEDICI LUM FL GB 1E 19-06-2009 11:00 Pagina 198

199
ADDING COOLANT
Engine coolant is harmful or
fatal if swallowed or inhaled.
Do not drink antifreeze or coolant so-
lution. If swallowed, do not induce
vomiting. Immediately contact a poi-
son control center or a physician.
Avoid inhaling mist or hot vapors; if
inhaled, remove to fresh air. If
coolant gets in eyes, flush eyes with
water and seek medical attention.
Wash thoroughly after handling. So-
lution can be poisonous to animals.
Keep out of the reach of children and
animals.
WARNINGIMPORTANT
❒The mixture you use should contain
50% concentration of antifreeze.
❒If the lowest ambient temperature in
your area is expected to be –35°C
(–31°F) or below, use higher concen-
trations up to 60% following the in-
structions on the antifreeze container.
❒When putting the cap on the reservoir
tank, line up the arrow on the cap and
the arrow on the tank. Failure to follow
this can result in coolant leakage.
If the coolant level is below the “LOW”
mark, more coolant should be added.
When the engine is cool, remove the de-
gassing tank cap by turning it anticlock-
wise slowly to release any pressure. And
add coolant until the degassing tank level
reaches the “FULL” mark. Never fill the
degassing tank above the “FULL” mark.
It is hazardous to remove the
degassing tank cap for Diesel
engine when the water temperature
is high, because scalding fluid and
steam may be blown out under pres-
sure. Wait until the coolant temper-
ature has lowered before removing
the cap.
WARNING
183-230 SEDICI LUM FL GB 1E 19-06-2009 11:00 Pagina 199

200
COOLANT REPLACEMENT
79J007
It is hazardous to remove the
radiator cap when the water
temperature is high, because scalding
fluid and steam may be blown out un-
der pressure. Wait until the coolant
temperature has lowered before re-
moving the cap.
WARNING
For Gasoline Engine Model
❒When the engine is cool, remove the
radiator cap by turning it slowly to the
left until a “stop” is felt. Do not press
down while turning the cap. Wait until
any pressure is released, then press
down on the cap and continue turning
it anticlockwise.For Diesel Engine Model
Since special procedures are required, we
recommend you take your vehicle to your
Fiat Dealership for coolant replacement.
❒Remove the reservoir by lifting it up,
and drain the reservoir completely.
❒Loosen the drain plug attached to the
lower part of the radiator and drain the
coolant into a suitable container.
❒Reinstall the reservoir and fill it with
coolant to the “FULL” line.
❒Tighten the drain plug on the radiator.
❒Fill the radiator with coolant and install
the radiator cap.
❒After filling, let the engine idle for about
2–3 minutes to get rid of air in the cool-
ing system.
❒Stop the engine.
❒Check the coolant level in the radiator
again. If the level has gone down, add
more coolant.
IMPORTANT The coolant must be re-
placed with the vehicle on level ground.
60A212
183-230 SEDICI LUM FL GB 1E 19-06-2009 11:00 Pagina 200

236
IF THE ENGINE
OVERHEATS
The engine could overheat temporarily
under severe driving conditions. If the en-
gine coolant temperature gauge indicates
overheating during driving:
❒Turn off the air conditioner, if equipped.
❒Take the vehicle to a safe place and
park.
❒Let the engine run at the normal idle
speed for a few minutes until the indi-
cator is within the normal, acceptable
temperature range between “H” and
“C”.
IF THE ENGINE IS
FLOODED
If the engine is flooded with gasoline, it
may be hard to start. If this happens, press
the accelerator pedal all the way to the
floor and hold it there while cranking the
engine. (Do not operate the starter mo-
tor for more than 15 seconds).
If you see or hear escaping
steam, stop the vehicle in a
safe place and immediately turn off
the engine to let it cool. Do not open
the hood when steam is present.
When the steam can no longer be
seen or heard, open the hood to see
if the coolant is still boiling. If it is, you
must wait until it stops boiling before
you proceed.
WARNING
IF THE STARTER DOES
NOT OPERATE
❒Try turning the ignition switch to the
“START” position with the headlights
turned on to determine the battery
condition. If the headlights go exces-
sively dim or go off, it usually means
that either the battery is flat or the bat-
tery terminal contact is poor. Recharge
the battery or correct battery terminal
contact as necessary.
❒If the headlights remain bright, check
the fuses. If the reason for failure of the
starter is not obvious, there may be a
major electrical problem. Have the ve-
hicle inspected by your authorized
Fiat Dealership.
231-238 SEDICI LUM FL GB 1E 19-06-2009 11:06 Pagina 236

237
❒If you do not find a leak, carefully add
coolant to the reservoir and then the
radiator, if necessary. (Refer to “Engine
Coolant” in the “INSPECTION AND
MAINTENANCE” section.) If the temperature indication does not
come down to within the normal, accept-
able range:
❒Turn off the engine and check that the
water pump belt and pulleys are not
damaged or slipping. If any abnormali-
ty is found, correct it.
❒Check the coolant level in the reser-
voir. If it is found to be lower than the
“LOW” line, look for leaks at the ra-
diator, water pump, and radiator and
heater hoses. If you locate any leaks
that may have caused the overheating,
do not run the engine until these prob-
lems have been corrected.
79J007
– It is hazardous to remove
the radiator cap when the
water temperature is high, because
scalding fluid and steam may be
blown out under pressure. The cap
should only be taken off when the
coolant temperature has lowered.
– To help prevent personal injury,
keep hands, tools and clothing away
from the engine cooling fan and air-
conditioner fan (if equipped). These
electric fans can automatically turn
on without warning.
WARNING
231-238 SEDICI LUM FL GB 1E 19-06-2009 11:06 Pagina 237

254
2WD
4WD
2WD
4WD
M/T
A/T 1,190 (2,623)
1,250 (2,755)1,335 (2,943)
1,370 (3,020)
WEIGHTS Unit: kg (lbs) 1.6 16V2.0 Multijet
Kerb weight (including fuel, spare wheel,
tools and accessories)
185 km/h
175 km/h190 km/h
180 km/h
2WD (M/T)
2WD (A/T)
4WD (M/T)
4WD
4WD6.6 litres (11.6 Imp pt)
6.5 litres (11.4 Imp pt)
50 litres (11.0 Imp gal)
3.9 litres (6.9 Imp pt)
(replacement with oil filter)
2.5 litres (4.4 Imp pt)
5.8 litres (10.2 Imp pt)
(when overhauling)
2.5 litres (4.4 Imp pt)
0.6 litres (1.1 Imp pt)
0.8 litres (1.4 Imp pt)6.5 litres (11.4 Imp pt)
–
50 litres (11.0 Imp gal)
4.4 litres (7.7 Imp pt)
(replacement with oil filter)
2.0 litres (3.5 Imp pt)
–
2.0 litres (3.5 Imp pt)
0.6 litres (1.1 Imp pt)
0.8 litres (1.4 Imp pt)
PERFORMANCE 1.6 16V2.0 Multijet
Top admitted speed after initial vehicle use
CAPACITIES (indicative values) 1.6 16V2.0 Multijet
Coolant
(including reservoir tank)
Fuel tank
Engine oil
Transaxle oil
Transfer oil
Rear differential oil
249-254 SEDICI LUM FL GB 1E 19-06-2009 11:10 Pagina 254
