Page 41 of 115
43-
To fold the rear bench seat:
- lower the head restraint,
- press control 1 to unlock the seat
back 2 , - fold the seat back
2 onto the
seat,
- place the seat in the "folded" posi- tion. When repositioning:
- tilt the folded seat rearwards,
- lift the seat back,
- check that the seat is locked cor-
rectly.
Take care not to trap the seat belts.
REAR BENCH SEAT
Page 42 of 115
SEATS44 -
GENERAL POINTS RELATING TO CHILD SEATS
Although one of CITROËN’s main
criteria when designing your vehicle,
the safety of your children also depends
on you.
For maximum safety, please follow
these precautions:
- all children under the age of 12
o r l e s s t h a n o n e m e t r e fi f t y t a l l
must travel in approved child
seats suited to their weight ,
o n s e a t s fi t t e d w i t h a s e a t b e l t o r
ISOFIX mountings * .
- a child weighing less than 9 kg
must travel in the "rearwards-
facing" position in the front.
"Forwards-facing"
When a "forwards-facing" child seat
is installed on the front passenger
seat , adjust the vehicle’s seat to the
intermediate longitudinal position
with the seat back upright and leave
the passenger air bag armed.
* The rules for transporting chil- d r e n a r e s p e c i fi c t o e a c h c o u n t r y .
Consult the current legislation in
your country. Intermediate longitudinal
position
"Rearwards-facing"
When a "rearwards-facing" child seat
is installed on the
front passenger
seat , it is essential that the passenger
air bag * is disarmed. Otherwise, the
child would risk being seriously
injured or killed if the air bag were
t o i n fl a t e .
Page 43 of 115
49SEATS-
ADVICE ON CHILD SEATS
The incorrect installation of a
child seat in a vehicle com-
promises the child’s protection in the
event of an accident.
Remember to fasten the seat belts or
the child seat harnesses keeping the
slack in relation to the child’s body to
a minimum, even for short journeys.
For optimum installation of the "for-
ward facing" child seat, ensure that
the back of the child seat is in contact
with the back of the vehicle’s seat
and that the head restraint does not
cause any discomfort.
If the head restraint has to be removed,
ensure that it is stored or attached se-
curely to prevent it from being thrown
around the vehicle in the event of sharp
braking. Children under the age of 10 must not
travel in the "forward facing" position
on the front passenger seat, unless
the rear seats are already occupied
by other children, cannot be used or
are absent.
Disarm the passenger air bag when
a "rear facing" child seat is installed
on the front seat. Otherwise, the child
would risk being seriously injured or
k i l l e d i f t h e a i r b a g w e r e t o i n fl a t e .
As a safety precaution, do not leave:
- one or more children alone and
unsupervised in a vehicle,
- a child or an animal in a vehicle which is exposed to the sun, with
the windows closed,
- the keys within reach of children inside the vehicle.
Installing a booster seat
The chest part of the seat belt must
be positioned on the child’s shoulder
without touching the neck.
Ensure that the lap part of the seat
belt passes correctly over the child’s
thighs.
CITROËN recommends the use of a
booster seat which has a back, fit-
ted with a seat belt guide at shoulder
level.
To prevent accidental opening
of the doors, use the "Child
lock".
Take care not to open the rear windows
by more than one third.
To protect young children from the
r a y s o f t h e s u n , fi t s i d e b l i n d s o n t h e
rear windows.
Page 44 of 115
45SEATS-
CHILD SEATS RECOMMENDED BY CITROËN
CITROËN offers a complete range of recommended c hild seats which are secured
using a three point seat belt :
Group 0: from birth to 10 kg
Group 0+: from birth to 13 kg
L1
"ROMER Baby-Safe Plus"
Installed in the rear-facing position
Groups 1, 2 and 3: from 9 to 36 kg
L2
"KIDDY Life"
For the safety of young children (from 9 to 18 kg), CITROËN
recommends use of the restraining cushion.
Groups 2 and 3: from 15 to 36 kg
L3
"RECARO Start"
L4
"KLIPPAN Optima" From the age of 6 years
(approximately 22 kg),
the booster is used on its own.
Passenger air bag OFF
Page 45 of 115
SEATS46 -
INSTALLING CHILD SEATS SECURED USING THE SEAT BELT
In accordance with European regulations, this table indicates the options for the installation of child seats secured using the
seat belt and universally approved (a), in accordance with the weight of the child and the seat in the vehicle:
(a) Universal child seat: child seat
which can be installed in all vehi-
cles using the seat belt.
(b) Group 0: from birth to 10 kg.
Weight of the child and indicative age
Seat
Below 13 kg
(groups 0 (b) and 0+)
Up to 1 year approx
From 9 to 18 kg
(group 1)
From 1 to 3 years approx
From 15 to 25 kg
(group 2) From 3 to 6 years approx
From 22 to 36 kg
(group 3) From 6 to 10 years approx
Front passenger
seat (c) U U U U
Rear side
seat
U U U U
Rear centre
seat U U U U
(c) Consult the legislation in force in
your country before installing your
child on this seat. U
Seat suitable for the installation of a
child seat secured using a seat belt
and universally approved, "rear facing"
and/or "forward facing".
Page 46 of 115
49SEATS-
ADVICE ON CHILD SEATS
The incorrect installation of a
child seat in a vehicle com-
promises the child’s protection in the
event of an accident.
Remember to fasten the seat belts or
the child seat harnesses keeping the
slack in relation to the child’s body to
a minimum, even for short journeys.
For optimum installation of the "for-
ward facing" child seat, ensure that
the back of the child seat is in contact
with the back of the vehicle’s seat
and that the head restraint does not
cause any discomfort.
If the head restraint has to be removed,
ensure that it is stored or attached se-
curely to prevent it from being thrown
around the vehicle in the event of sharp
braking. Children under the age of 10 must not
travel in the "forward facing" position
on the front passenger seat, unless
the rear seats are already occupied
by other children, cannot be used or
are absent.
Disarm the passenger air bag when
a "rear facing" child seat is installed
on the front seat. Otherwise, the child
would risk being seriously injured or
k i l l e d i f t h e a i r b a g w e r e t o i n fl a t e .
As a safety precaution, do not leave:
- one or more children alone and
unsupervised in a vehicle,
- a child or an animal in a vehicle which is exposed to the sun, with
the windows closed,
- the keys within reach of children inside the vehicle.
Installing a booster seat
The chest part of the seat belt must
be positioned on the child’s shoulder
without touching the neck.
Ensure that the lap part of the seat
belt passes correctly over the child’s
thighs.
CITROËN recommends the use of a
booster seat which has a back, fit-
ted with a seat belt guide at shoulder
level.
To prevent accidental opening
of the doors, use the "Child
lock".
Take care not to open the rear windows
by more than one third.
To protect young children from the
r a y s o f t h e s u n , fi t s i d e b l i n d s o n t h e
rear windows.
Page 47 of 115
47SEATS-
"ISOFIX" MOUNTINGS
These are two rings located between
the seat back and the seat cushion.
This ISOFIX mounting system guar-
a n t e e s r e l i a b l e , s a f e a n d f a s t fi t t i n g o f
the child seat in your vehicle. The
ISOFIX child seats a r e fi t t e d
with two locks which are secured
easily on these rings.
Your vehicle has been approved in ac-
cordance with the ISOFIX
regulation .
T h e s e a t s , r e p r e s e n t e d b e l o w , a r e fi t -
ted with regulation ISOFIX mountings:
Page 48 of 115
48 -
ISOFIX CHILD SEAT RECOMMENDED BY CITROËN AND APPROVED FOR YOUR VEHICLE
I s o fi x K I D D Y
Group 0+: from birth to 13 kg Group 1: from 9 to 18 kg
Installed in the rear facing position, on the rear side seat only. Installed in the forwards facin g position.
The body of this child seat must be in contact with the ba ck
of the vehicle’s front seat. It is imperative that the vehicle’s front seat is adjusted to
the
intermediate longitudinal position.
This child seat can also be used on
s e a t s w h i c h a r e n o t fi t t e d w i t h I S O F I X
mountings. In this case, it is compulsory to secure
the child seat to the vehicle’s seat using
the three-point seat belt.
F o l l o w t h e i n s t r u c t i o n s f o r fi t t i n g
the child seat indicated in the seat
manufacturer’s installation guide.
