2009 CHRYSLER SEBRING CONVERTIBLE ignition

CavityCartridge
FuseMini
FuseDescription
8—30 Amp
GreenIgnition Off
Draw (IOD)
Sense 2
940 Amp
GreenBattery Feed —
Power Seats - if
equipped/PZEV
Air Pump - if
equipped
10 —20 Amp
YellowBattery Feed —
Cabin Compart-
ment Node
(CCN)
11 —15 Amp
Lt BlueSelectable Power
Outlet
12 —20 Amp
Yellow—CavityCartridge
FuseMini
FuseDescription
13 —20 Amp
Yellow—
14 —10 Amp
RedIgnition Off
Draw (IOD) —
Cabin Compart-
ment Node
(CCN)/ Interior
Lighting
1540 Amp
Green—Battery Feed —
Radiator Fan Re-
lay
16 —15 Amp
Lt.
BlueIGN Run/ACC
— Cigar Lighter/
PWR Sunroof
Mod
MAINTAINING YOUR VEHICLE 407
7

CavityCartridge
FuseMini
FuseDescription
17 —10 Amp
RedIgnition Off
Draw (IOD) —
Wireless Control
Module (WCM)/
Clock/Steering
Control Module
(SCM)
1840 Amp
Green—Battery Feed —
Auto Shutdown
(ASD) Relay
19 —20 Amp
YellowIgnition Off
Draw (IOD) —
Power Amp Feed
2 - if equipped
20 —15 Amp
Lt.
BlueIgnition Off
Draw (IOD) —
RadioCavityCartridge
FuseMini
FuseDescription
21 —10 Amp
Red—
22 —10 Amp
RedIgnition Run —
Climate
Controls/Hot
Cupholder - if
equipped
23 —15 Amp
Lt.
BlueAuto Shutdown
(ASD) Relay Feed
3
24 —25 Amp
ClearBattery Feed —
PWR Sunroof
Feed
25 —10 Amp
RedIgnition Run —
Heated Mirrors -
If Equipped
408 MAINTAINING YOUR VEHICLE

CavityCartridge
FuseMini
FuseDescription
26 —15 Amp
Lt.
BlueAuto Shutdown
(ASD) Relay Feed
2
27 —10 Amp
RedIgnition Run —
Occupant Classi-
fication Module
(OCM)/Occupant
Restraint Control-
ler (ORC)
28 —10 Amp
RedIgnition Run —
Occupant Classi-
fication Module
(OCM)/Occupant
Restraint Control-
ler (ORC)
29 — —Hot Car (No Fuse
Required)CavityCartridge
FuseMini
FuseDescription
30 —20 Amp
YellowIgnition Run —
Heated Seats - If
Equipped
31 —10 Amp
Red—
3230 Amp
Pink—Auto Shutdown
(ASD) Relay Feed
1
33 —10 Amp
RedBattery Feed —
Switch Bank/
Diagnostic Link
Connector/
Powertrain Con-
trol Module
(PCM)
MAINTAINING YOUR VEHICLE 409
7

CAUTION! (Continued)
•When replacing a blown fuse, it is important to
use only a fuse having the correct amperage rating.
The use of a fuse with a rating other than indicated
may result in a dangerous electrical system over-
load. If a properly rated fuse continues to blow, it
indicates a problem in the circuit that must be
corrected.
VEHICLE STORAGE
If you will not be using your vehicle for more than
21 days, you may want to take steps to preserve your
battery.
•Disengage the mini-fuse in the Power Distribution
Center labeled IOD (Ignition Off-Draw).
•Disconnect the negative cable from the battery.
REPLACEMENT BULBS
All the inside bulbs are brass or glass wedge base.
Aluminum base bulbs are not approved and should not
be used for replacement.
LIGHT BULBS — Interior Bulb Number
Front Courtesy/Reading
Lights..................... LED(Dealer Service)
Center Console Courtesy Light...........578/W5W
Glove Box Light......................... 194
Rear Compartment (Trunk) Light............. 579
NOTE:For lighted switches, see your dealer for replace-
ment instructions.
