2009 CHEVROLET MALIBU Owners Manual

3. Extend the handle on the wheel wrench by pressing
the button and pulling on the end of the wrench.
You must do this before using the wheel wrench.
Removing the Flat Tire and
Installing the Spare Tire
1. Do a safety check before proceeding. SeeChanging
a Flat Tire on page 5-76.
2. If the vehicle has a wheel cover or hubcap that has
plastic wheel nut caps, loosen the plastic nut caps.
You might need to use the wheel wrench to loosen
them. Do not pry off wheel covers or center caps that
have plastic wheel nut caps.
3. Remove the wheel cover or center cap from the
wheel to locate the wheel nuts.
If the vehicle has a wheel cover or hubcap without
plastic wheel nut caps, gently pry on the edge of the
plastic wheel trim to remove it from the wheel to
locate the wheel nuts.
5-79

4. Use the wrench to loosen all the wheel nuts. Do not
remove them yet.5. Position the lift head at the jack location nearest
the at tire. Make sure all of the jack lift head is
touching the jacking ange under the body. Do not
place the jack under a body panel.
6. Put the compact spare tire near the at tire.
5-80

{CAUTION:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack, you
could be badly injured or killed. Never get under
a vehicle when it is supported only by a jack.
{CAUTION:
Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal injury
and vehicle damage, be sure to t the jack lift
head into the proper location before raising the
vehicle.7. Raise the vehicle by turning the wrench clockwise.
Raise the vehicle far enough off the ground so there
is enough room for the compact spare tire to t.
5-81

8. Remove all of the
wheel nuts.
9. Remove the at tire.
{CAUTION:
Rust or dirt on a wheel, or on the parts to which
it is fastened, can make wheel nuts become loose
after time. The wheel could come off and cause an
accident. When changing a wheel, remove any rust
or dirt from places where the wheel attaches to the
vehicle. In an emergency, use a cloth or a paper
towel to do this; but be sure to use a scraper or wire
brush later, if needed, to get all the rust or dirt off.
SeeChanging a Flat Tire on page 5-76.
10. Remove any rust or dirt
from the wheel bolts,
mounting surfaces
and spare wheel.
5-82

11. Install the compact spare tire.
{CAUTION:
Never use oil or grease on bolts or nuts because
the nuts might come loose. The vehicle’s wheel
could fall off, causing a crash.
12. Put the wheel nuts back on with the rounded end
toward the wheel. Tighten each nut by hand or
with the wrench until the wheel is held against
the hub.
13. Lower the vehicle by turning the wrench
counterclockwise. Lower the jack completely.
5-83

{CAUTION:
Wheel nuts that are improperly or incorrectly
tightened can cause the wheels to become loose
or come off. The wheel nuts should be tightened
with a torque wrench to the proper torque
specication after replacing. Follow the torque
specication supplied by the aftermarket
manufacturer when using accessory locking
wheel nuts. SeeCapacities and Specifications
on page 5-108for original equipment wheel nut
torque specications.
Notice:Improperly tightened wheel nuts can
lead to brake pulsation and rotor damage. To avoid
expensive brake repairs, evenly tighten the wheel
nuts in the proper sequence and to the proper torque
specication. SeeCapacities and Specifications on
page 5-108for the wheel nut torque specication.14. Tighten the wheel nuts
rmly in a crisscross
sequence, as shown,
with the wheel wrench.
Notice:Wheel covers will not t on your vehicle’s
compact spare. If you try to put a wheel cover on
the compact spare, the cover or the spare could
be damaged.
Do not try to put a wheel cover on your compact spare
tire. It will not t. Store the wheel cover and wheel nut
caps in the trunk until you have the at tire repaired or
replaced.
5-84

Storing a Flat or Spare Tire and
Tools
Storing a Flat Tire and Tools
{CAUTION:
Storing a jack, a tire, or other equipment in the
passenger compartment of the vehicle could
cause injury. In a sudden stop or collision, loose
equipment could strike someone. Store all these
in the proper place.
To store the at tire and jack in the compact spare tire
compartment:
1. Open the trunk. SeeTrunk on page 2-12.
2. Remove the bolt extension (in the yellow sleeve)
from the jack and remove the center cap from the
wheel.3. Collapse the wrench using the same button used to
extend it.
4. Attach the wrench to the jack by placing the tab on
the wrench into the hole on the side of the jack.
Then place the wrench handle over the tab on the
side of the jack.
5-85

5. Raise the jack to the
height shown and
lock the wrench onto
the jack.
6. Place the jack over the bolt (A) on the oor, making
sure it contacts the bolt. Thread the jack retainer
nut until it contacts the jack.7. With the valve stem up, place the tire on the
compartment oor with the rear of the tire under the
trim panel. The tire may not lay completely at.
8. Line up the bolt with the wheel center.
9. With the yellow cap in place to prevent the wheel
from being scratched, screw the bolt extension
onto the bolt through the wheel center hole.
10. Remove the yellow cap from the bolt extension.
11. Secure the tire and wheel with the larger wing nut.
5-86
