Safety Warnings and Symbols
A circle with a slash
through it is a safety
symbol which means
“Do Not,” “Do not do this” or
“Do not let this happen.”
A box with the word CAUTION is used to tell about
things that could hurt you or others if you were to ignore
the warning.{CAUTION:
These mean there is something that could hurt
you or other people.
Cautions tell what the hazard is and what to do to avoid
or reduce the hazard. Read these cautions.
A notice tells about something that can damage the
vehicle.
Notice:These mean there is something that could
damage your vehicle.
Many times, this damage would not be covered by the
vehicle’s warranty, and it could be costly. The notice
tells what to do to help avoid the damage.
There are also warning labels on the vehicle which use
the same words, CAUTION or Notice.
iv

Front Seats......................................................1-2
Power Seats..................................................1-2
Power Lumbar ...............................................1-2
Heated Seats.................................................1-3
Heated and Ventilated Seats............................1-3
Power Reclining Seatbacks..............................1-4
Head Restraints.............................................1-5
Rear Seats.......................................................1-6
Heated Seats.................................................1-6
Rear Seat Pass-Through Door.........................1-6
Safety Belts.....................................................1-7
Safety Belts: They Are for Everyone.................1-7
How to Wear Safety Belts Properly.................1-12
Lap-Shoulder Belt.........................................1-21
Safety Belt Use During Pregnancy..................1-27
Safety Belt Extender.....................................1-27
Child Restraints.............................................1-28
Older Children..............................................1-28
Infants and Young Children............................1-31
Child Restraint Systems.................................1-35
Where to Put the Restraint.............................1-37Lower Anchors and Tethers for
Children (LATCH)......................................1-39
Securing a Child Restraint in a
Rear Seat Position....................................1-45
Securing a Child Restraint in the
Right Front Seat Position............................1-47
Airbag System...............................................1-51
Where Are the Airbags?................................1-53
When Should an Airbag Inate?.....................1-56
What Makes an Airbag Inate?.......................1-57
How Does an Airbag Restrain?.......................1-57
What Will You See After an Airbag
Inates?...................................................1-58
Passenger Sensing System............................1-59
Servicing Your Airbag-Equipped Vehicle...........1-64
Adding Equipment to Your
Airbag-Equipped Vehicle
.............................1-64
Restraint System Check..................................1-66
Checking the Restraint Systems......................1-66
Replacing Restraint System Parts
After a Crash............................................1-67
Section 1 Seats and Restraint System
1-1

Front Seats
Power Seats
The power seat controls
are located on the outboard
side of the seats.
To adjust the seat:
Move the seat forward or rearward by sliding the
horizontal control forward or rearward.
Raise or lower the front part of the seat cushion by
moving the front of the horizontal control up or down.
Raise or lower the rear part of the seat cushion by
moving the rear of the horizontal control up or down.
Use the vertical control to recline the seatback.
SeePower Reclining Seatbacks on page 1-4.If the vehicle has the memory feature, you can program
and recall memory settings for seat positions. See
Memory Seat, Mirrors and Steering Wheel on page 2-77.
Power Lumbar
On vehicles with power
lumbar, the control is
located on the outboard
sides of the front seat(s).
To increase or decrease support, press and hold the
front or rear of the control.
To raise or lower the position of the lumbar support,
press and hold the top or bottom of the control.
Vehicles with a memory function allow seat settings to be
saved and recalled. SeeMemory Seat, Mirrors and
Steering Wheel on page 2-77for more information.
1-2

Heated Seats
On vehicles with heated
front seats, the buttons are
located on the climate
control panel.
z(Heated Seat and Seatback):Press the up or down
arrow once to turn on the heated seat at the highest or
lowest setting.
Press the up or down arrows a second time to raise or
lower the setting. Keep pressing the down arrow until the
indicator on the climate control display is off to turn off the
heated seat.A light bar in the climate control display shows the setting:
high, medium, or low. The longest bar shows the high
range and the shortest bar shows the low range.
The heated seat will automatically shut off when the
vehicle is turned off.
Heated and Ventilated Seats
On vehicles with this feature, the buttons are located on
the climate control panel.
z(Heated Seat and Seatback):Press to heat the
seat and seatback.
{(Ventilated Seat):Press to ventilate the seat.
A light bar in the climate control display shows
the setting; high, medium, or low.
Press either button to start that feature at the highest
setting. Each press of the button, decreases the setting.
To turn the feature off, press the button until the light
turns off.
The heated or ventilated seats shut off when the vehicle
is turned off.
1-3

Power Reclining Seatbacks
The front seats have
power reclining seatbacks.
Use the vertical power
seat control located on
the outboard side of
the seat to operate them.
To recline the seatback, press the control toward
the rear of the vehicle.
To raise the seatback, press the control toward the
front of the vehicle.
1-4
