Hood Release
To open the hood, do the following:
1. Pull the hood release
lever with this symbol
on it. It is located inside
the vehicle on the lower
left side of the
instrument panel.
2. Then go to the front of the vehicle and nd the
secondary hood release lever. The lever is located
under the front edge of the grille near the center.
Push the release lever up and raise the hood.
Before closing the hood, be sure all the ller caps are
on properly. Then pull the hood down and close it rmly.
5-11

Engine Compartment Overview
Your vehicle may be equipped with front compartment underhood sight shields, which surround the vehicle’s engine
cover. These sight shields will need to be removed in order to access some of the underhood components in
your vehicle.
To remove the sight shields, turn the fasteners on each shield to the left until they pop out. Then remove the fasteners
and lift the shields up and away from the tower to tower brace.
3.6L V6 Engine
5-12

After you have removed the sight shields (if equipped) on the 3.6L V6 engine, here is what you will see:
A. Underhood Fuse Block. SeeUnderhood Fuse Block
on page 5-124.
B. Remote Negative (-) Terminal. SeeJump Starting on
page 5-42.
C. Remote Positive (+) Terminal. SeeJump Starting on
page 5-42.
D. Battery. SeeBattery on page 5-42.
E. Passenger Compartment Air Filter. SeePassenger
Compartment Air Filter on page 3-54.
F. Power Steering Fluid Reservoir. SeePower Steering
Fluid on page 5-37.
G. Engine Oil Fill Cap. See “When to Add Engine Oil”
underEngine Oil on page 5-18.H. Engine Oil Dipstick (Out of View). See “Checking
Engine Oil” underEngine Oil on page 5-18.
I. Brake Master Cylinder Reservoir. See “Brake Fluid”
underBrakes on page 5-39.
J. Engine Coolant Surge Tank and Pressure Cap.
SeeCoolant Surge Tank Pressure Cap on page 5-34
andCooling System on page 5-26.
K. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 5-23.
L. Windshield Washer Fluid Reservoir. See “Adding
Washer Fluid” underWindshield Washer Fluid
on page 5-38.
5-13

4.6L V8 Engine
5-14

After you have removed the sight shields (if equipped) on the 4.6L V8 engine, here is what you will see:
A. Remote Negative (-) Terminal. SeeJump Starting on
page 5-42.
B. Remote Positive (+) Terminal. SeeJump Starting on
page 5-42.
C. Battery. SeeBattery on page 5-42.
D. Passenger Compartment Air Filter. SeePassenger
Compartment Air Filter on page 3-54.
E. Power Steering Fluid Reservoir. SeePower Steering
Fluid on page 5-37.
F. Engine Oil Fill Cap. See “When to Add Engine Oil”
underEngine Oil on page 5-18.
G. Engine Oil Dipstick (Out of View). See “Checking
Engine Oil” underEngine Oil on page 5-18.H. Brake Master Cylinder Reservoir. See “Brake Fluid”
underBrakes on page 5-39.
I. Engine Coolant Surge Tank and Pressure Cap.
SeeCoolant Surge Tank Pressure Cap on page 5-34
andCooling System on page 5-26.
J. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 5-23.
K. Underhood Fuse Block. SeeUnderhood Fuse Block
on page 5-124.
L. Windshield Washer Fluid Reservoir. See “Adding
Washer Fluid” underWindshield Washer Fluid
on page 5-38.
5-15

4.4L V8 STS-V Engine
5-16

After you have removed the sight shields (if equipped) on the 4.4L V8 STS-V engine, here is what you will see:
A. Underhood Fuse Block. SeeUnderhood Fuse Block
on page 5-124.
B. Remote Positive (+) Terminal. SeeJump Starting on
page 5-42.
C. Remote Negative (-) Terminal. SeeJump Starting on
page 5-42.
D. Battery. SeeBattery on page 5-42.
E. Passenger Compartment Air Filter. SeePassenger
Compartment Air Filter on page 3-54.
F. Windshield Washer Fluid Reservoir. See “Adding
Washer Fluid” underWindshield Washer Fluid
on page 5-38.
G. Intercooler System Pressure Cap. SeeEngine
Coolant on page 5-27.
H. Power Steering Fluid Reservoir. SeePower Steering
Fluid on page 5-37.I. Engine Oil Fill Cap. See “When to Add Engine Oil”
underEngine Oil on page 5-18.
J. Engine Oil Dipstick (Out of View). See “Checking
Engine Oil” underEngine Oil on page 5-18.
K. Brake Master Cylinder Reservoir. See “Brake Fluid”
underBrakes on page 5-39.
L. Engine Coolant Surge Tank and Pressure Cap.
SeeCoolant Surge Tank Pressure Cap on page 5-34
andCooling System on page 5-26.
M. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 5-23.
If your vehicle is equipped with front compartment
underhood sight shields, before closing the hood be
sure to reinstall the sight shields. To reinstall the shields,
locate the tabs on the left and right sides and insert them
into the openings in the tower to tower brace. Then insert
the fasteners into the top of the shield and push the
fasteners back into place.
5-17

Engine Oil
Checking Engine Oil
It is a good idea to check the engine oil every time you
get fuel. In order to get an accurate reading, the oil
must be warm and the vehicle must be on level ground.
The engine oil dipstick handle is a yellow loop.
SeeEngine Compartment Overview on page 5-12
for the location of the engine oil dipstick.
1. Turn off the engine and give the oil several minutes
to drain back into the oil pan. If you do not do this,
the oil dipstick might not show the actual level.
2. Pull out the dipstick and clean it with a paper towel
or cloth, then push it back in all the way. Remove it
again, keeping the tip down, and check the level.
When to Add Engine Oil
V6 Engine
V8 Engine
