2008 TOYOTA FJ CRUISER wheel

113
2−1. Driving procedures
2
When driving
NOTICE
 If you get a flat tire while driving
A flat or damaged tire may cause the following situations. Hold the steering
wheel firmly and gradually press the brake pedal to slow down the vehicle.
 It may be difficult to control your vehicle.
The vehicle will make abnormal sounds.
The vehicle will behave abnormally.
Replace a flat tire with a new one. (
P. 342)
 When encountering flooded roads
Do not drive on a road that has flooded after heavy rain etc. Doing so may
cause the following serious damage to the vehicle.
 Engine stalling
Short in electrical components
Engine damage caused by water immersion
In the event that you drive on a flooded road and the vehicle is flooded, be
sure to have your Toyota dealer check the following.
Brake function
Changes in quantity and quality of oil and fluid used for the engine, trans−
mission, transfer (4WD vehicles), differentials, etc.
 Lubricant condition for the propeller shaft, bearings and suspension joints
(where possible) and the function of all joints, bearings, etc.

114
2−1. Driving procedures
Engine (ignition) switch
 Engine switch
LOCK
The steering wheel is locked
and the key can be removed.
ACC
Some electrical components
such as the audio system can
be used.
ON
All electrical components can
be used.
START
For starting the engine.
 Starting the engine
Automatic transmission
Check that the parking brake is set.
Check that the shift lever is set in P.
Sit in the driver ’s seat and firmly depress the brake pedal.
Turn the engine switch to the START position and start the
engine.
Manual transmission
Check that the parking brake is set.
Check that the shift lever is set in N.
Firmly depress the brake pedal and clutch pedal.
Turn the engine switch to the START position and start the
engine.

115
2−1. Driving procedures
2
When driving
 Turning the key from ACC to LOCK
 Steering lock release
 If the engine does not start
The engine immobilizer system may not have been deactivated. ( P. 68)
 Key reminder function
A buzzer sounds if the driver ’s door is opened, while the engine switch is in
the ACC or LOCK position to remind you to remove the key.
CAUTION
 When starting the engine
Always start the engine while sitting in the driver’s seat. Do not depress the
accelerator while starting the engine under any circumstances.
Doing so may cause an accident resulting in death or serious injury.
Shift the shift lever to P (auto−
matic transmission) or N (man−
ual transmission). (
P. 1 1 7119)
Push in the key and turn to the
LOCK position.
When starting the engine, the engine
switch may seem stuck in the LOCK posi−
tion. To free it, turn the key while turning
the steering wheel slightly in either direc−
tion.

128 2−2. Instrument cluster
 Indicators
The indicators inform the driver of the operating state of the
vehicle’s various systems.
Turn signal indicator
(
P. 121)(if equipped)
Active traction control
system indicator (
P.
148)
Headlight high beam
indicator (
P. 131)
*
(if equipped)
AUTO LSD indicator
(
P. 150)
Security indicator
(
P. 68)(if equipped)
Four−wheel drive
indicator(
P. 146)
(Automatic
transmission
vehicles)
Shift position and shift
range indicators
(
P. 117)
(if equipped)
Center differential lock
indicator (
P. 144)
(if equipped)
Rear differential lock
indicator (
P. 152)
(if equipped)
Cruise control indicator
(
P. 136)
*AIR BAG ON indicator
(
P. 85)
*Slip indicator
(
P. 148, 150, 156)
*AIR BAG OFF indicator
(
P. 85)
*VSC OFF indicator
(
P. 157)

144
2−4. Using other driving systems
Four−wheel drive system (4WD models with a manual transmission)
Use the fourwheel drive control lever to select the following transfer
modes.
The center differential lock indicator comes on when the LL or HL mode is
selected.
H (high speed position)
Normal driving
HL (high speed position, center differential locked)
When your vehicle’s wheel gets stuck in ditch or when you are driving
on a slippy or bumpy surface.
N (neutral position)
No power is delivered to the wheels.
LL (low speed position, center differential locked)
Driving requiring maximum power and traction such as climbing or
descending steep hills, off−road driving and hard pulling in sand or mud,
etc.

145
2−4. Using other driving systems
2
When driving
 Shifting between H and HL
 You need not to depress the clutch pedal.
If the center differential lock indicator does not come on when you shift
from H to HL, drive straight ahead while accelerating or decelerating.
 If the center differential lock indicator does not go off when you shift from
HL to H, drive straight ahead while accelerating or decelerating, or drive
in reverse.
 Shifting from HL to LL
Stop the vehicle or reduce your speed to less than 5 mph (8 km/h).
Depress the clutch pedal and move the four−wheel drive control lever.
 Shifting from LL to HL
Depress the clutch pedal and move the four−wheel drive control lever.

Shifting to HL or LL
VSC is automatically turned off.
NOTICE
 To prevent damage to the center differential
 For normal driving on dry and hard surface roads, unlock the center differ−
ential.
Shift to H after the wheels are out of the ditch or off the slippery or bumpy
surface.
 Do not shift to any position when the vehicle is cornering or when its
wheels spinning freely off the ground.
Shifting from H to HL while driving
Never move the four−wheel drive control lever if wheels are slipping. Stop
the slipping or spinning before shifting.

146
2−4. Using other driving systems
Four−wheel drive system (4WD models with an automatic transmission)
Use the frontwheel drive control le ver to select the following trans
fer modes.
The four−wheel drive indicator comes on when the H4, N or L4 mode is
selected.
H2 (high speed position, two−wheel drive)
Normal driving.
H4 (high speed position, four−wheel drive)
Greater traction than two wheel drive.
When you experience a loss of power, such as wheel slipping.
N (neutral position)
No power is delivered to the wheels.
L4 (low speed position, four−wheel drive)
Driving requiring maximum power and traction such as climbing or
descending steep hills, off−road driving and hard pulling in sand or mud,
etc.

147
2−4. Using other driving systems
2
When driving
 Shifting between H2 and H4
 Reduce your speed to less than 50 mph (80 km/h) and shift the front−
wheel drive control lever from H2 to H4.
If you have trouble shifting in cold weather, reduce your speed or stop the
vehicle.
If the four−wheel drive indicator does not go off when you shift from H4 to
H2, drive straight ahead while accelerating or decelerating, or drive in
reverse.
 Shifting between H4 and L4
Stop the vehicle, shift the shift lever to N and shift the front−wheel drive con−
trol lever.
 Shifting to H4 or L4.
VSC is automatically turned off.
Fourwheel drive usage frequency
You should drive in four−wheel drive for at least 10 miles (16 km) each
month.
This will assure that the front drive components are lubricated.
CAUTION
 Shift from H2 to H4 while driving
Never move the front−wheel drive control lever if wheels are slipping.
Stop the slipping or spinning before shifting.
