2008 TOYOTA 4RUNNER stop start

158
The SRS warning light will come on and
front passenger occupant classification in-
dicator light will indicate OFF" if there is
a malfunction in the front passenger occu-
pant classification system.
(m) Automatic Transmission FluidTemperature Warning Light
(four−wheel drive models)
This light warns that the automatic trans-
mission fluid temperature is too high.
If this light comes on while you are driv-
ing, slow down and pull off the road. Stop
the vehicle at a safe place and put the
selector lever in P". With the engine id-
ling, wait until the light goes off. If the
light goes off, you may start the vehicle
again. If the light does not go off, call a
Toyota dealer or qualified repair shop for
assistance.
NOTICE
Continued driving with the warning
light on may damage the automatic
transmission.
(n) Tire Pressure Warning Light
This light warns that the tire pressure of
one or more of your tires (including the
spare tire) is low. The light comes on
when the engine switch is turned to the
ON" position. It goes off after a few sec-
onds. This indicates that the tire pressure
warning system is functioning properly.
If the warning light comes on, stop your
vehicle in a safe place as soon as pos-
sible and check that the inflation pressure
of all tires (including the spare tire) is as
specified on the tire and loading informa-
tion label. (See Checking tire inflation
pressure" on page 441 in Section 7−2.)
The light should go off a few minutes after
the tire pressure is adjusted.
If the warning light comes on after blink-
ing for 1 minute, the tire pressure warning
system may be malfunctioning. Contact
your Toyota dealer.
For details, see Tire pressure warning
system" on page 197 in Section 1−7. (o) Low Windshield Washer Fluid Level
Warning Light (for vehicles sold in
Canada)
The light warns that the windshield washer
fluid level is too low. Add washer fluid at
your earliest opportunity. (For instructions,
see Adding washer fluid" on page 453 in
Section 7−3.)
(p) Key Reminder Buzzer
This buzzer acts as a reminder to remove
the key when you open the driver’s door
with the engine switch in the ACC" or
LOCK" position.
(q) Parking Brake Reminder Buzzer
The buzzer acts once when the parking
brake is not completely released at the
vehicle speed of 5 km/h (3 mph) or more.
Stop the vehicle and release the parking
brake fully.

175
If the 4LO" (low speed four−wheel drive)
indicator light continues to blink and the
buzzer sounds when you operate the mul-
ti−mode control switch knob to the H4" or
L4" position, drive forward or backward in
a short distance, then stop the vehicle
completely, shift the automatic transmis-
sion selector lever securely into N" and
operate the switch knob again.
If the indicator continues to blink even if
doing so, contact your Toyota dealer as
soon as possible. There may be a trouble
in the four−wheel drive system.
CAUTION
Never operate the multi−mode control
switch knob if the wheels are slip-
ping. Stop the slipping or spinning
before operating.
The traction control system automatical-
ly helps prevent the spinning of rear
wheels when the vehicle is started or
accelerated on slippery road surfaces.
When the engine switch is turned to ON",
the system automatically turns on.
CAUTION
Under certain slippery road condi-
tions, full traction of the vehicle and
power to the rear wheels cannot be
maintained, even though the traction
control system is in operation. Do not
drive the vehicle under any speed or
maneuvering conditions which may
cause the vehicle to lose traction
control. In situations where the road
surface is covered with ice or snow,
your vehicle should be fitted with
snow tires or tire chains. Always
drive at an appropriate and cautious
speed for the present road condi-
tions.
CY16073
NORMAL DRIVING MODE
Leave the system on during ordinary
driving so that it can operate when
needed.
You may hear a sound in the engine
compartment for a few seconds when the
engine is started or just after the vehicle
begins to move. This means that the trac-
tion control system is in the self−check
mode, but does not indicate a malfunction.
When the traction control system is oper-
ating, the following conditions occur:
The system controls the spinning of the
rear wheels. At this time, the slip indi-
cator light blinks.
Traction control system
(two−wheel drive models)

176
You may feel vibration or noise in your
vehicle, caused by operation of the
brakes. This indicates the system is
functioning properly.
The slip indicator light comes on for a few
seconds when the engine switch is turned
to ON". If the indicator light does not
come on when the engine switch is turned
on, contact your Toyota dealer.
The brake actuator temperature increases
during continuous operation of the traction
control system, the AUTO LSD" system,
the vehicle stability control system and
the hill−start assist control system such
as on slippery roads.
If the brake actuator temperature becomes
too high while any of the systems is oper-
ating, a buzzer will start to sound intermit-
tently to indicate that the traction control
system can no l onger operate. In this
case, immediately stop your vehicle at a
safe place.
If the system continues to operate, the
buzzer sound changes from intermittent to
continuous. (The continuous buzzer
sounds for about 3 seconds.) At the time the slip indicator light will
come on and the traction control system
temporarily stops operating in order to
protect the brake actuator. (Although the
traction control system does not operate,
there is no problem to continue your driv-
ing.) The system will be automatically re-
stored after a short time and the slip indi-
cator light goes out.
CY16075
TRACTION CONTROL OFF MODE
If your wheels get stuck in an ditch
when you are driving on a severe off
road and sand, turn off the traction
control system. This system that con-
trols engine performance interferes with
the process of freeing your wheels.
To turn off: Briefly push the VSC OFF"
switch.
The AUTO LSD" and slip indicator lights
will come on.
The vehicle stability control system is al-
ways activated, even if the traction control
system is turned off.

177
To turn on: Briefly push the VSC OFF"
switch once again.
The AUTO LSD" and slip indicator lights
will go off.
If the engine is turned off while the
AUTO LSD" and slip indicator lights are
on and then restarted, the indicator lights
will turn off automatically.
When you push and hold the VSC OFF"
switch for 3 seconds or more with the
vehicle stopped, turn off the vehicle stabil-
ity control system. See Vehicle stability
control system" on page 183 in this Sec-
tion.
AUTO LSD" and slip indicator lights come
on for a few seconds when the engine
switch is turned to ON". If the indicator
lights do not come on when the engine
switch is turned to ON", contact your
Toyota dealer.
CAUTION
Do not drive with the traction control
system continuously turned off.
CY16074
VSC OFF" warning light
This light flashing warns that there is a
problem somewhere in the following.
Traction control system
AUTO LSD" system
Vehicle stability control system
Hill−start assist control system
When the system is normal and the en-
gine switch is turned to ON", the warning
light will come on and will go off after a
few seconds.
It is not a malfunction that the warning
light may stay on for 60 seconds after the
engine switch is turned to ON". Depressing the brake pedal repeatedly
may turn on the light. It is normal if it
goes out after a few seconds.
If the VSC OFF" warning light flashes
while driving, the traction control system
does not work. However, as normal brak-
ing operates when being applied, there is
no problem to continue your driving.
In the following cases, contact your Toyota
dealer:
The warning light does not come on
after the engine switch is turned to
ON".
The warning light remains on after the
engine switch is turned to ON".
The warning light flashes while driving.

178
The active traction control system auto-
matically helps prevent the spinning of
4 wheels when the vehicle is started or
accelerated on slippery road surfaces.
When the engine switch is turned to ON",
the system automatically turns on.
CAUTION
Under certain slippery road condi-
tions, full traction of the vehicle and
power to the 4 wheels cannot be
maintained, even though the traction
control system is in operation. Do not
drive the vehicle under any speed or
maneuvering conditions which may
cause the vehicle to lose traction
control. In situations where the road
surface is covered with ice or snow,
your vehicle should be fitted with
snow tires or tire chains. Always
drive at an appropriate and cautious
speed for the present road condi-
tions.
CY16073
NORMAL DRIVING MODE
Leave the system on during the ordi-
nary driving so that it can operate
when needed.
You may hear a sound in the engine
compartment for a few seconds when the
engine is started or just after the vehicle
begins to move. This means that the ac-
tive traction control system is in the self−
check mode, but does not indicate a mal-
function.
When the active traction control system is
operating, the following conditions occur:
The system controls the spinning of the
4 wheels. At this time, the slip indica-
tor light blinks.
You may feel vibration or noise in your
vehicle, caused by operation of the
brakes. This indicates the system is
functioning properly.
The slip indicator light comes on for a few
seconds when the engine switch is turned
to ON". If the indicator light does not
come on when the engine switch is turned
on, contact your Toyota dealer.
The brake actuator temperature increases
during continuous operation of the active
traction control system, the vehicle stabil-
ity control system, the downhill assist con-
trol system and the hill−start assist control
system such as on sli ppery roads. If the
brake actuator temperature becomes too
high while any of the systems is operat-
ing, a buzzer will start to sound intermit-
tently to indicate that the active traction
control system can no longer operate. In
this case, immediately stop your vehicle at
a safe place.
If the system continues to operate, the
buzzer sound changes from intermittent to
continuous. (The continuous buzzer
sounds for about 3 seconds.)
Active traction control system
(four−wheel drive models)

179
At the time, the slip indicator light will
come on and the active traction control
system temporarily stops operating in or-
der to protect the brake actuator. (Al-
though the active traction control system
does not operate, there is no problem to
continue your driving.) The system will be
automatically restored after a short time
and the slip indicator light goes out.
CY16074
VSC OFF" warning light
This light flashing warns that there is a
problem somewhere in the following.
Active traction control system
Vehicle stability control system
Downhill assist control system
Hill−start assist control system
When the system is normal and the en-
gine switch is turned to ON", the warning
light will come on and will go off after a
few seconds.
It is not a malfunction that the warning
light may stay on for 60 seconds after the
engine switch is turned to ON". Depressing the brake pedal repeatedly
may turn on the light. It is normal if it
goes out after a few seconds.
If the VSC OFF" warning light flashes
while driving, the active traction control
system does not work. However, as nor-
mal braking operates when being applied,
there is no problem to continue your driv-
ing.
In the following cases, contact your Toyota
dealer:
The warning light does not come on
after the engine switch is turned to
ON".
The warning light remains on after the
engine switch is turned to ON".
The warning light flashes while driving.

181
When you push and hold the VSC OFF"
switch for 3 seconds or more with the
vehicle stopped, turn off the vehicle stabil-
ity control system. See Vehicle stability
control system" on page 183 in this Sec-
tion.
CY16076
The slip indicator light blinks when the
system is controlling the spinning of the
rear wheels.
The AUTO LSD" and slip indicator lights
come on for a few seconds when the
engine switch is turned to ON". If the
indicator lights does not come on when
the engine switch is turned to ON", con-
tact your Toyota dealer.The brake actuator temperature increases
during continuous operation of the AUTO
LSD" system, the traction control system
and the vehicle stability control system
such as on slippery roads. If the brake
actuator temperature becomes too high
while any of the systems is operating, a
buzzer will start to sound intermittently to
indicate that the AUTO LSD" system can
no longer operate. In this case, immedi-
ately stop your vehicle at a safe place.
If the system continues to operate, the
buzzer sound changes from intermittent to
continuous. (The continuous buzzer
sounds for about 3 seconds.)
At the time the slip indicator light will
come on and the AUTO LSD" system
temporarily stops operating in order to
protect the brake actuator. (Although the
AUTO LSD" system does not operate, it
is no problem to continue driving.) The
system will be automatically restored after
a short time and the slip indicator light
goes off.

187
Multi−mode four−wheel drive modelsIf
the downhill assist control system indica-
tor light flashes, the selector lever may be
in N" or the multi−mode control switch
knob may be in the H2" or H4" position.
If the indicator light does not come on
when the switch is pushed, contact your
Toyota dealer.
CY16073
With the vehicle traveling at a speed of
25 km/h (15 mph) or less, release your
foot from the accelerator or brake pedal
to activate the system. The vehicle will
descend the hill at a low speed. While the
system is operating, the slip indicator light
on the instrument panel will flash and the
stop lights and high mounted stoplight will
be lit.
If you push the DAC" switch to turn the
system off while it is in operation, the
system will stop operating gradually. The
downhill assist control system indicator
light will flash to alert the driver. To con-
tinue driving at a low speed, push the
DAC" switch to turn the system on. The slip indicator light and downhill assist
control system indicator light come on for
a few seconds when the engine switch is
turned to ON". If any of the indicator
lights does not come on when the engine
switch is turned on, contact your Toyota
dealer.
The brake actuator temperature increases
during continuous operation of the h
ill−
start assist control system, the active
traction control system and the vehicle
stability control system. If the brake ac-
tuator temperature becomes too high while
any of the systems is operating, a buzzer
will start to sound intermittently to indicate
that the downhill assist control system can
no longer operate. In this case, stop your
vehicle immediately at a safe place.
If the system continues to operate, the
buzzer sound changes from intermittent to
continuous. (The continuous buzzer
sounds for about 3 seconds.)
