2008 JEEP LIBERTY Owners Manual

Airbag System Components
The airbag system consists of the following:
²Occupant Restraint Controller (ORC)
²Airbag Warning Light
²Driver Airbag
²Front Passenger Airbag
²Side Curtain Airbags above Side Windows
²Side Remote Acceleration Sensors
²Steering Wheel and Column
²Instrument Panel
²Interconnecting Wiring
²Front Acceleration Sensors
²Driver and Front Passenger Seat Belt Pretensioner and
Retractor
²Front Passenger Seat Track Position Sensors
²Occupant Classification System (OCS) Ð Front Pas-
senger Seat Only
þOccupant Classification Module (OCM)
þPassenger Airbag Disable (PAD) Indicator Light
þWeight Sensors
How The Airbag System Works
²
TheOccupant Restraint Controller (ORC)determines
if a frontal, side, or rollover collision is severe enough
to require the airbags to inflate. The front airbag
inflators are designed to provide different rates of
airbag inflation from direction provided by the ORC.
The ORC may also modify the rate of inflation based
on the occupant size. The ORC receives this data from
the Occupant Classification Module (OCM). The ORC
will detect roll over, but not rear impacts.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57
2

The ORC also monitors the readiness of the electronic
parts of the system whenever the ignition switch is in
the START or ON position. These include all of the
items listed above except the Passenger Airbag Disable
(PAD) Indicator Light, the instrument panel, and the
steering wheel and column. If the key is in the LOCK
position, in the ACC position, or not in the ignition,
the airbags are not on and they will not inflate.
The ORC also turns on the ªAirbag Warning
Lightº and ªPAD Indicator Lightº for 6 to 8
seconds as a self-check when the ignition is
first turned ON. After the self-check, the
ªAirbag Warning Lightº will turn off. The ªPAD
Indicator Lightº will function normally (refer to infor-
mation on Passenger Airbag Disable (PAD) Indicator
Light in this section). If the ORC detects a malfunction
in any part of the system, it turns on the ªAirbagWarning Lightº either momentarily or continuously. A
single chime will sound if the light comes on again
after initial start up.
WARNING!
Ignoring the ªAirbag Warning Lightº in your instru-
ment panel could mean you won't have the airbags to
protect you in a collision. If the light does not come
on, stays on after you start the vehicle, or if it comes
on as you drive, have the airbag system checked right
away.
²TheOccupant Classification System (OCS)is part of
a Federally regulated safety system required for this
vehicle. It is designed to turn off the front passenger
airbag for an empty seat and for occupants classified
in a category other than that of an adult. This could be
a child, teenager, or even a small size adult.
58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

NOTE:Children 12 years and under should always ride
buckled up in a rear seat in an appropriate child restraint.
²ThePassenger Airbag Disable (PAD) Indicator Light
(an amber light located in the center of the instrument
panel) tells the driver and front passenger when the
front passenger airbag is turned off. The ªPAD Indi-
cator Lightº illuminates the words9PASS AIR BAG
OFF9to show that the passenger airbag will not inflate
during a collision requiring airbags. When the front
passenger seat is empty or when very light objects are
placed on the seat, the passenger airbag will not inflate
even though the ªPAD Indicator Lightº is not illumi-
nated.
The ªPAD Indicator Lightº should not be illuminated
when an adult passenger is properly seated in the
front passenger seat. In this case, the airbag is ready to
be inflated if a collision requiring an airbag occurs. For
all other occupants, the ªPAD Indicator Lightº will be
illuminated indicating that the front passenger airbag
Indicator Light Location
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59
2

is turned off and it will not inflate. If the ªPAD
Indicator Lightº is not illuminated,DO NOTassume
the airbag is turned off and move the child restraint to
the rear seat. A deploying passenger airbag can cause
death or serious injury to a child in a rear facing infant
seat.
NOTE:Even though this vehicle is equipped with an
Occupant Classification System, children 12 years and
under should always ride buckled up in a rear seat in an
appropriate child restraint.
Front Passenger
Seat OccupantPassenger Air-
bag Disable
(PAD) Indicator
LightAirbag Status
Adult OFF ON
Grocery Bags,
Heavy Brief-
cases, and Other
Relatively Light
ObjectsON OFF
Empty or Very
Small ObjectsOFF* OFF
* Since the system senses weight, some small objects
will turn the PAD Indicator Light on.
The OCS classifies an occupant using weight sensors
mounted in the base of the front passenger seat. Any
weight on the seat will be sensed by the system. Objects
hanging on the seat or other passengers pushing down
on the seat will also be sensed. The weight of an adult
60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

will cause the system to turn the airbag on. In this case,
the OCS has classified the occupant of the seat as an
adult. An adult occupant needs to sit in a normal position
(with their feet on or near the floor) in order to be
properly classified. Reclining the seat back too far may
change how an occupant is classified by the OCS.
Drivers and adult passengers should verify that the
ªPAD Indicator Lightº is not illuminated when an adult
is riding in the front passenger seat. If an adult occu-
pant's weight is transferred to another part of the vehicle
(like the door or instrument panel), the weight sensors in
the seat may not properly classify the occupant. Objects
lodged under the seat or between the seat and the center
console can prevent the occupant's weight from being
measured properly and may result in the occupant being
improperly classified. Ensure that the front passenger
seat back does not touch anything placed on the back seatbecause this can also affect occupant classification. Also,
if you fold down the rear seat check to be sure it doesn't
touch the front passenger seat.
If the front passenger seat is damaged in any way, it
should only be serviced by an authorized dealer. If the
seat is removed (or even if the seat attachment bolts are
loosened or tightened in any way), take the vehicle to an
authorized dealer.
If there is a fault present in the OCS, the ªAirbag Warning
Lightº (a red light located in the center of the instrument
cluster directly in front of the driver) will be turned on.
This indicates that you should take the vehicle to an
authorized dealer. The ªAirbag Warning Lightº is turned
on whenever there is a fault that can affect the operation
of the airbag system. If there is a fault present in the OCS,
both the ªPAD Indicator Lightº and the ªAirbag Warning
Lightº are illuminated to show that the passenger airbag
is turned off until the fault is cleared. If an object is
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61
2

lodged under the seat and interferes with operation of
the weight sensors, a fault will occur which turns on both
the ªPAD Indicator Lightº and the ªAirbag Warning
Light.º Once the lodged object is removed, the fault will
be automatically cleared after a short period of time.
²TheDriver and Passenger Airbag/Inflator Unitsare
located in the center of the steering wheel and the
passenger side of the instrument panel. When the ORC
detects a collision requiring the airbags, it signals the
inflator units. A large quantity of nontoxic gas is
generated to inflate the front airbags. Different airbag
inflation rates are possible, based on collision severity
and occupant size. The steering wheel hub trim cover
and the upper passenger side of the instrument panel
separate and fold out of the way, as the bags inflate to
their full size. The bags fully inflate in about 50 - 70
milliseconds. This is about half of the time that it takes
to blink your eyes. The bags then quickly deflate while
helping to restrain the driver and front passenger. Thedriver's front airbag gas is vented through the vent
holes in the sides of the airbag. The passenger's front
airbag gas is vented through the vent holes in the sides
of the airbag. In this way, the airbags do not interfere
with your control of the vehicle.²TheOccupant Classification Module (OCM)is lo-
cated beneath the front passenger seat. The OCM
classifies the occupant into categories based on the
measurements made by the seat weight sensors. The
OCM communicates with the Occupant Restraint Con-
troller (ORC). The ORC uses the occupant category to
determine whether the front passenger airbag should
be turned off. It also determines the rate of airbag
inflation during a collision.
²Your vehicle has fourWeight Sensorslocated between
the seat and the floor pan. The weight sensors measure
applied weight and transfers that information to the
OCM.
62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

²TheSide Impact SRS Side Curtain Airbagsare de-
signed to activate only in certain side collisions and
rollover events. When the ORC detects a collision
requiring the side curtain airbag to inflate, it signals
the inflators on the crash side of the vehicle or both
sides of the vehicle for a rollover event. A quantity of
nontoxic gas is generated to inflate the side curtain
airbag. The inflating side curtain airbag pushes the
outside edge of the headliner out of the way and
covers the window. The airbag inflates in about 30
milliseconds (about one quarter of the time that it
takes to blink your eyes) with enough force to injure
you if you are not belted and seated properly, or if
items are positioned in the area where the side curtain
airbag inflates. This especially applies to children. The
side curtain airbag is only about 3
1¤2inches (9 cm) thick
when it is inflated.The front passenger seat assembly contains critical com-
ponents that affect the front passenger airbag deploy-
ment. Correctly functioning front passenger seat compo-
nents are critical for the Occupant Classification System
(OCS) to properly classify the front passenger and calcu-
late the proper airbag deployment. Do not make any
modifications to the front passenger seat components or
assembly.
The following requirements must be strictly adhered to:
²Do not modify the front passenger seat assembly or
components in any way.
²At no time should any supplemental restraint system
(SRS) component or SRS related component or fas-
tener be modified or replaced with any part except
those which are approved by DaimlerChrysler/
Mopar.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63
2

WARNING!
Unapproved modifications or service procedures to
the front passenger seat assembly or its related com-
ponents may inadvertently change the airbag deploy-
ment in case of a frontal crash. This could result in
death or serious injury to the front seat passenger if
the vehicle is involved in an accident. A modified
vehicle may not comply with required Federal Motor
Vehicle Safety Standards (FMVSS).
If A Deployment Occurs
The airbag system is designed to deploy when the
Occupant Restraint Controller (ORC) detects a moderate-
to-severe collision, to help restrain the driver and front
passenger, and then to immediately deflate.NOTE:A collision that is not severe enough to need
airbag protection will not activate the system. This does
not mean something is wrong with the airbag system.
If you do have a collision, which deploys the airbags, any
or all of the following may occur:
²The nylon airbag material may sometimes cause abra-
sions and/or skin reddening to the driver and front
passenger as the airbags deploy and unfold. The
abrasions are similar to friction rope burns or those
you might get sliding along a carpet or gymnasium
floor. They are not caused by contact with chemicals.
They are not permanent and normally heal quickly.
However, if you haven't healed significantly within a
few days, or if you have any blistering, see your doctor
immediately.
64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
