2008 JEEP GRAND CHEROKEE Owners Manual

VEHICLE MODIFICATIONS/ALTERATIONS
WARNING!
Any modifications or alterations to this vehicle could
seriously affect its roadworthiness and safety and
may lead to an accident resulting in serious injury or
death.
INTRODUCTION 9
1

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
CONTENTS
mA Word About Your Keys..................14
NWireless Ignition Node (WIN).............14
NFOB With Integrated Key (FOBIK)..........15
NIgnition Key Removal...................16
NKey-In-Ignition Reminder................17
mSentry Key............................17
NReplacement Keys......................18
NCustomer Key (FOB) Programming..........19
NGeneral Information....................20mSecurity Alarm System Ð If Equipped.........20
NTo Set The Alarm......................20
NTo Disarm The System...................21
mIlluminated Entry........................21
mRemote Keyless Entry.....................21
NTo Unlock The Doors...................22
NTo Lock The Doors.....................23
NTo Release The Liftgate Flipper Glass........24
NUsing The Panic Alarm..................24
2

NProgramming Additional Transmitters........25
NTransmitter Battery Service...............25
NGeneral Information....................26
mRemote Starting System Ð If Equipped........26
mDoor Locks............................28
NManual Door Locks.....................28
NPower Door Locks.....................28
NChild Protection Door Lock...............30
mWindows.............................31
NPower Windows.......................31
NWind Buffeting........................33
mLiftgate...............................34
NLiftgate Flipper Glass...................35mOccupant Restraints......................36
NLap/Shoulder Belts.....................37
NLap/Shoulder Belt Operating Instructions.....38
NAdjustable Upper Shoulder Belt Anchorage....41
NAutomatic Locking Mode Ð If Equipped.....42
NEnergy Management Feature..............42
NSeat Belt Pretensioners...................43
NEnhanced Seat Belt Use Reminder System
(BeltAlert)...........................43
NSeat Belts And Pregnant Women............45
NSeat Belt Extender......................45
NDriver And Front Passenger Supplemental
Restraint Systems (SRS)..................46
NChild Restraint........................58
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

mEngine Break-In Recommendations...........68
mSafety Tips............................69
NExhaust Gas..........................69NSafety Checks You Should Make Inside The
Vehicle..............................69
NSafety Checks You Should Make Outside The
Vehicle..............................70
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13
2

A WORD ABOUT YOUR KEYS
Your vehicle uses a keyless ignition system. This system
consists of a Fob with Integrated Key and a Wireless
Ignition Node (WIN) with integral ignition switch. You
can insert the double-sided integrated key into the igni-
tion switch with either side up.
Wireless Ignition Node (WIN)
The Wireless Ignition Node (WIN) operates similar to an
ignition switch. It has four operating positions, three of
which are detented and one spring-loaded. The detented
positions are LOCK, ACC, and ON. The START position
is a spring-loaded momentary contact position. When
released from the START position, the switch automati-
cally returns to the detented ON position.
Wireless Ignition Node (WIN)
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Fob with Integrated Key (FOBIK)
The Fob with Integrated Key operates the ignition switch.
It also contains the Remote Keyless Entry (RKE) trans-
mitter and a valet key, which stores in the rear of the Fob.
The valet key allows for entry into the vehicle should the
battery in the vehicle or the Fob go dead. You can keep
the valet key with you when valet parking.
To remove the valet key from the Fob, slide the mechani-
cal latch at the top of the Fob sideways with your thumb
and then pull the key out of the Fob with your other
hand.
NOTE:You can insert the double-sided valet key into
the lock cylinders with either side up.
3 Button FOBIK
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15
2

Ignition Key Removal
Place the selector lever in ªPº (Park). Turn the key to the
LOCK position, and remove the key.
NOTE:
²If you try to remove the key before you place the
selector lever in ªPº (Park), it may become trapped
temporarily in the ignition switch. If this occurs, rotate
the key to the right slightly, then remove the key as
described. If a malfunction occurs, the system will trap
the key in the ignition switch to warn you that this
safety feature is inoperable. The engine can be started
and stopped, but the key cannot be removed until you
obtain service.
²For vehicles equipped with the Electronic Vehicle
Information Center (EVIC), the power window
switches, radio, power sunroof (if equipped), and
power outlets will remain active for up to 60 minutesafter the ignition switch is turned to the LOCK posi-
tion. Opening either front door will cancel this feature.
The time for this feature is programmable. For details,
refer to ªDelay Power Off to Accessories Until Exit,º
under ªPersonal Settings (Customer Programmable
Features),º under ªElectronic Vehicle Information
Center (EVIC)º in Section 4 of this manual.
WARNING!
Never leave children alone in a vehicle. Leaving
children in a vehicle unattended is dangerous for a
number of reasons. A child or others could be seri-
ously or fatally injured. Don't leave the keys in the
ignition. A child could operate power windows,
other controls, or move the vehicle.
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
