TM-200
< ON-VEHICLE REPAIR >
OIL PAN
2. Install the oil pan (2) new oil pan gasket.• : Vehicle Front
• : Oil pan bolts
• Clips (1)
• Drian plug (3)
CAUTION:
• Be sure the oil drain plug is located to the rear of thetransmission assembly.
• Before installing oil pan bolts, remove any traces of old sealant from the sealing su rfaces and threaded holes.
• Do not reuse old gasket, replace with a new one.
• Always replace the oil pan bolts as they are self-sealing.
• Partially install the oil pan bolts in a criss-cross pattern to prevent dislocation of the gasket.
3. Install oil pan bolts and clips tighten in numerical order as shown.
4. Install drain plug with new gasket to oil pan and tighten to speci- fication.
CAUTION:
Do not reuse drain plug gasket.
5. Refill the A/T with fluid and check for fluid leakage. Refer to TM-178, "
Checking the A/T Fluid (ATF)".
AWDIA0023ZZ
Oil pan bolts : 7.9 N·m (0.81 kg-m, 70 in-lb)
Drain plug : 34 N·m (3.5 kg-m, 25 ft-lb)
SCIA4113E
Revision: March 2010 2008 QX56
