< ON-VEHICLE REPAIR >[AUDIO SYSTEM]
REAR DOOR SPEAKER
REAR DOOR SPEAKER
Removal and InstallationINFOID:0000000001601495
REAR DOOR SPEAKER
Removal
1. Remove the rear door finisher. Refer to
INT-11, "Removal and Installation".
2. Remove the rear door speaker screws.
3. Disconnect the rear door speaker connector.
4. Remove the rear door speaker.
Installation
Installation is in the reverse order of removal.
REAR DOOR TWEETER
Removal
1. Remove the rear door finisher. Refer to INT-11, "Removal and Installation".
2. Remove the rear door tweeter screws (A).
3. Remove the rear door tweeter (1).
Installation
Installation is in the reverse order of removal.
WKIA1492E
ALNIA0269ZZ
Revision: March 2010 2008 QX56

AV
BACK DOOR SPEAKERAV-171
< ON-VEHICLE REPAIR > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
BACK DOOR SPEAKER
Removal and InstallationINFOID:0000000001601614
REMOVAL
1. Remove the back door lower finisher. Refer to INT-21, "Removal and Installation".
2. Remove the back door speaker screws (A).
3. Pull out the back door speaker (1), disconnect the back door speaker connector and remove the back door speaker (1).
INSTALLATION
Installation is in the reverse order of removal.
ALNIA0421ZZ
Revision: March 2010 2008 QX56

AV-172
< ON-VEHICLE REPAIR >[AUDIO SYSTEM]
SUBWOOFER
SUBWOOFER
Removal and InstallationINFOID:0000000001601615
SUBWOOFER (BOSE SYSTEM)
Removal
1. Remove the front seat LH. Refer to SE-49, "Removal and Installation".
2. Disconnect the subwoofer connector.
3. Remove the subwoofer bolts.
4. Remove the subwoofer.
Installation
Installation is in the reverse order of removal.
WKIA1496E
Revision: March 2010 2008 QX56

AV
DVD PLAYERAV-173
< ON-VEHICLE REPAIR > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
DVD PLAYER
Removal and InstallationINFOID:0000000001601498
REMOVAL
1. Disconnect the battery negative terminal.
2. Remove the center console bin. Refer to IP-20, "
Removal and Installation".
3. Remove the DVD player screws (A) and remove the DVD player (1).
INSTALLATION
Installation is in the reverse order of removal.
ALNIA0271ZZ
Revision: March 2010 2008 QX56

AV-174
< ON-VEHICLE REPAIR >[AUDIO SYSTEM]
STEERING SWITCH
STEERING SWITCH
Removal and InstallationINFOID:0000000001601496
REMOVAL
1. Remove the steering wheel. Refer to ST-18, "Removal and Installation".
2. Remove the steering wheel rear cover.
3. Pull the steering wheel audio control out of the steering wheel, disconnect the steering wheel audio con-
trol switch connector.
4. Remove the steering wheel audio control switch finisher screws and remove the steering wheel audio control switch finisher.
INSTALLATION
Installation is in the reverse order of removal.
1. Steering wheel audio control switch
finisher 2. Steering wheel audio control switch 3. Steering wheel
4. Steering wheel audio control switch connector
ALNIA0270ZZ
Revision: March 2010 2008 QX56

AV
REAR AUDIO REMOTE CONTROL UNITAV-175
< ON-VEHICLE REPAIR > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
REAR AUDIO REMOTE CONTROL UNIT
Removal and InstallationINFOID:0000000001601497
REMOVAL
CAUTION:
Wrap removal tool with clean shop cl oth to prevent damage to the headliner.
1. Carefully remove the rear audio remote control unit from the rear roof console assembly (1).
2. Disconnect connectors and remove the rear audio remote con- trol unit.
INSTALLATION
Installation is in the reverse order of removal.
ALNIA0276ZZ
Revision: March 2010 2008 QX56

AV-176
< ON-VEHICLE REPAIR >[AUDIO SYSTEM]
DVD ENTERTAINMENT SYSTEM
DVD ENTERTAINMENT SYSTEM
Removal and InstallationINFOID:0000000001601499
REMOVAL
1. Remove the rear roof console. Refer to
INT-17, "Removal and Installation".
2. Disconnect the video monitor connector.
3. Remove the video monitor housing.
4. Remove the video monitor hinge screws.
5. Remove the video monitor.
INSTALLATION
Installation is in reverse order of removal.
WKIA1502E
WKIA1219E
Revision: March 2010 2008 QX56

AV
BOSE SPEAKER AMPAV-177
< ON-VEHICLE REPAIR > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
BOSE SPEAKER AMP
Removal and InstallationINFOID:0000000001601620
REMOVAL
1. Remove the BCM. Refer to BCS-55, "Removal and Installation".
2. Remove the accelerator pedal. Refer to ACC-4, "
Removal and Installation".
3. Disconnect the BOSE speak er amp. connectors.
4. Remove the BOSE speaker amp. and bracket assembly screws and slide the BOSE speaker amp. bracket assembly down.
5. Remove the BOSE speaker amp. screws (A). then remove the BOSE speaker amp. (1).
INSTALLATION
Installation is in the reverse order of removal.
WKIA1605E
ALNIA0268ZZ
