REAR FENDER
WIIA0285E
Revision: March 2010 2008 QX56

BRM-48
< SERVICE INFORMATION >
BODY REPAIR
WIIA0283E
Revision: March 20102008 QX56

BODY REPAIRBRM-49
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
BRM
N
O P
REAR SIDE MEMBER
REAR FLOOR REAR
WIIA0281E
Revision: March 2010 2008 QX56

BRM-50
< SERVICE INFORMATION >
BODY REPAIR
•
CRUSH HORN
WIIA0282E
Revision: March 20102008 QX56

BODY REPAIRBRM-51
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
BRM
N
O P
• Work after 1st crossmember has been removed.
Portions to be welded:
A. Inner side rail crush horn, inner side rail crush horn and outer side rail crush horn.
B. Outer side rail crush horn, outer side rail crush horn and inner side rail crush horn.
Removal Notes
LIIA1083E
Revision: March 2010 2008 QX56

BRM-52
< SERVICE INFORMATION >
BODY REPAIR
• Scribe a straight line on the outer side rail crush horn and inner side rail crush horn along the hole center as
shown in the figure.
• Cut off outer side rail crush horn and inner side rail crush horn along scribed line A. Do not cut on the hole.
• Cut inner side rail crush horn at 45 mm backw ard cut position of cut line A. (along line B)
LIIA1084E
LIIA1085E
Revision: March 2010 2008 QX56

BODY REPAIRBRM-53
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
BRM
N
O P
• After removing outer panel, dress area on the i nner panel surface with a sander or equivalent.
Installation Notes
• Scribe a straight line on the inner side rail crush horn along the hole center as shown in the figure. Cut off
inner side rail crush horn along scribed line.
• Scribe a straight line on the outer side rail crush horn along the hole center as shown in the figure. Cut off
outer side rail crush horn along scribed line.
LIIA1086E
LIIA1087E
LIIA1088E
Revision: March 2010 2008 QX56
