2008 INFINITI QX56 oil filter

2008
QUICK REFERENCE CHART: QX56
Front Disc Brake
INFOID:0000000006237753
Unit: mm (in)
Rear Disc BrakeINFOID:0000000006237754
Unit: mm (in)
Fluids and LubricantsINFOID:0000000006237752
Brake model AD41VA
Brake pad Standard thickness (new) 12.0 (0.476)
Repair limit thickness 1.0 (0.039)
Disc rotor Standard thickness (new) 30 (1.181)
Repair limit thickness 28 (1.102)
Maximum uneven wear (measured at 8 positions) 0.015 (0.0006)
Runout limit (with it attached to the vehicle) 0.03 (0.001)
Brake model
AD14VE
Brake pad Standard thickness (new) 12.0 (0.472)
Repair limit thickness 1.0 (0.039)
Disc rotor Standard thickness (new) 14.0 (0.551)
Repair limit thickness 12.5 (0.492)
Maximum uneven wear (measured at 8 positions) 0.015 (0.0006)
Runout limit (with it attached to the vehicle) 0.05 (0.002)
Description
Capacity (Approximate)
Metric US measure Imp measure
Fuel 105.8 28 gal 23 1/4 gal
Engine oil
Drain and refill With oil filter change
6.5 6 7/8 qt 5 3/4 qt
Without oil filter change 6.2 6 1/2 qt 5 1/2 qt
Dry engine (engine overhaul) 7.6 8 qt 6 3/4 qt
Cooling system With reservoir
at MAX level
14.4
15 1/4 qt 12 5/8 qt
Automatic transmission fluid (ATF) 10.6 11 1/4 qt 9 3/8 qt
Rear final drive oil 1.75 3 3/4 pt 3 1/8 pt
Transfer fluid 3.0 3 1/8 qt 2 5/8 qt
Front final drive oil 1.6 3 3/8 pt 2 7/8 pt
Power steering fluid (PSF) 1.0 1 1/8 qt 7/8 qt
Brake fluid — — —
Brake grease — — —
Multi-purpose grease — — —
Windshield washer fluid 4.9 5 1/8 qt 4 3/8 qt
Air conditioning system refrigerant 1.08 ± 0.05 kg 2.38 ± 0.11 lb 2.38 ± 0.11 lb
Air conditioning system oil 290 m9.8 fl oz 10.2 fl oz

DLN-3
CEF
G H
I
J
K L
M A
B
DLN
N
O P
PRECAUTIONS .............................................. ..118
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ..
118
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect ............................... ..
118
Precaution for Transfer Assembly and Transfer
Control Unit Replacement .....................................
119
Precaution .............................................................119
Service Notice .......................................................120
PREPARATION .........................................121
PREPARATION .............................................. ..121
Special Service Tool ........................................... ..121
Commercial Service Tool ......................................124
ON-VEHICLE MAINTENANCE ..................125
TRANSFER OIL FILTER ................................ ..125
Removal and Installation .......................................125
TRANSFER FLUID ......................................... ..127
Replacement ....................................................... ..127
Inspection ..............................................................127
ON-VEHICLE REPAIR ...............................128
TRANSFER CONTROL UNIT ........................ ..128
Removal and Installation .......................................128
FRONT OIL SEAL ............................................129
Removal and Installation .......................................129
REAR OIL SEAL ..............................................131
Removal and Installation .......................................131
SIDE OIL SEAL .............................................. ..133
Removal and Installation .......................................133
TRANSFER CONTROL DEVICE ................... ..134
Removal and Installation .......................................134
AIR BREATHER HOSE .................................. ..135
Removal and Installation .......................................135
TRANSFER MOTOR ...................................... ..138
Removal and Installation .......................................138
REMOVAL AND INSTALLA TION .............139
TRANSFER ASSEMBLY ............................... ..139
Removal and Installation .......................................139
DISASSEMBLY AND ASSEMBLY ........... .140
TRANSFER ASSEMBLY ............................... ..140
Disassembly and Assembly ................................ ..140
SERVICE DATA AND SPECIFICATIONS
(SDS) ......... ................................. ................
177
SERVICE DATA AND SPECIFICATIONS
(SDS) ...............................................................
177
General Specification .......................................... ..177
Inspection and Adjustment ....................................177
PROPELLER SHAFT: 2F1310
PRECAUTION ...... ......................................
179
PRECAUTIONS ...............................................179
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ..
179
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect .................................
179
PREPARATION .........................................181
PREPARATION ...............................................181
Commercial Service Tool .................................... ..181
SYMPTOM DIAGNOSIS ............................182
NOISE, VIBRATION, AND HARSHNESS
(NVH) TROUBLESHOOTING .........................
182
NVH Troubleshooting Chart ................................ ..182
ON-VEHICLE REPAIR ...............................183
PROPELLER SHAFT ......................................183
On-Vehicle Service .............................................. ..183
REMOVAL AND INSTALLATION .............184
PROPELLER SHAFT ......................................184
Removal and Installation ..................................... ..184
DISASSEMBLY AND ASSEMBLY ............186
PROPELLER SHAFT ......................................186
Disassembly and Assembly ................................. ..186
SERVICE DATA AND SPECIFICATIONS
(SDS) ............... .......................................... .
188
SERVICE DATA AND SPECIFICATIONS
(SDS) ...............................................................
188
General Specification .......................................... ..188
Snap Ring ..............................................................188
PROPELLER SHAFT: 2S1410
PRECAUTION ...... ......................................
189
PRECAUTIONS ...............................................189
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ..
189
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect .................................
189
PREPARATION .........................................191
PREPARATION ...............................................191
Revision: March 2010 2008 QX56

4WD SYSTEMDLN-17
< FUNCTION DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
CAN CommunicationINFOID:0000000001737099
Refer to LAN-51, "DTC Index".
1. A: Transfer shut off relay E69
B: Transfer shift low relay E47
C: Transfer shift high relay E46 2. A: Actuator
B: Transfer control device F58
C: Actuator lever
D: Transfer case 3. Wait detection switch F59
(View with transfer case removed)
4. A: Clutch pressure switch B: Line pressure switch
C: Transfer fluid temperature sensor
D: 2-4WD shift solenoid valve
E: Clutch pressure solenoid valve
(View with contro l valve removed
from transfer case) 5. A: Neutral 4LO switch F60
B: ATP switch F55
C: Transfer motor F57
D: Transfer terminal cord assembly F56
E: Oil filter 6. Combination meter M23, M24
A: 4WD warning lamp
B: ATP warning lamp
C: 4LO indicator lamp (located in in-
formation display)
D: 4WD shift indicator lamp
7. 4WD shift switch M141 8. Transfer control unit E142, E143 9. Transfer dropping resistor E135
Transfer motor relay E153, E154
(View with battery removed)
Revision: March 2010 2008 QX56

TRANSFER OIL FILTERDLN-125
< ON-VEHICLE MAINTENANCE > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
ON-VEHICLE MAINTENANCE
TRANSFER OIL FILTER
Removal and InstallationINFOID:0000000001604409
REMOVAL
1. Remove the oil filter bolts and oil filter. CAUTION:
• Do not damage center case or oil filter.
• Loosen bolts and detach oil filter evenly.
2. Remove the O-rings (1) from the oil filter (2).
3. Remove the oil filter stud from the oil filter.
4. Remove the O-ring from the oil filter stud.
INSTALLATION
1. Apply ATF to the new O-ring, and install it on the oil filter stud. CAUTION:
Do not reuse O-ring.
2. Install the oil filter stud to the oil filter.
SMT875C
WDIA0285E
SDIA3180E
SDIA3180E
Revision: March 2010 2008 QX56

DLN-126
< ON-VEHICLE MAINTENANCE >[ATX14B]
TRANSFER OIL FILTER
3. Apply ATF to the two new O-rings (1), and install them on the oil
filter (2).
CAUTION:
Do not reuse O-rings.
4. Install the oil filter to the transfer assembly. Tighten the bolts to the specified torque. Refer to DLN-125, "
Removal and Installa-
tion".
CAUTION:
• Do not damage oil filter.
• Attach oil filter an d tighten bolts evenly.
5. Check the transfer fluid. Refer to DLN-127, "
Inspection".
6. Start the engine for one minute. Then stop the engine and recheck the transfer fluid. Refer to DLN-127, "
Inspection".
WDIA0285E
SDIA2136E
Revision: March 2010 2008 QX56

TRANSFER ASSEMBLYDLN-141
< DISASSEMBLY AND ASSEMBLY > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
40. Retaining plate 41. Driven plate (10 sheet) 42. Drive plate (10 sheet)
43. Return spring assembly 44. Press flange 45. Thrust needle bearing
46. Snap ring 47. Retaining pin 48. L-H fork
49. 2-4 fork 50. Shift fork spring 51. Fork guide
52. Retainer pin 53. Shift rod
1. Dust cover 2. Rear oil seal 3. Rear case
4. Breather tube 5. Seal ring 6. Main oil pump cover
7. Inner gear 8. Outer gear 9. Main oil pump housing
10. D-ring 11. D-ring 12. Clutch piston
13. Thrust needle bearing race 14. Oil strainer 15. O-ring
16. Snap ring 17. Control valve assembly 18. Lip seal (large 5 pieces)
19. Lip seal (small 2 pieces) 20. Gasket 21. Filler plug
22. Oil filter stud 23. O-ring 24. Oil filter
25 ATP switch 26. Neutral-4LO switch 27. Oil pressure check plug
28. Harness bracket 29. Air breather hose clamp 30. Stem bleeder
31. Harness bracket 32. Center case 33. Mainshaft rear bearing
34. C-ring 35. Washer holder 36. Snap ring
37. Sub oil pump housing 38. Outer gear 39. Inner gear
WDIA0302E
Revision: March 2010 2008 QX56

DLN-156
< DISASSEMBLY AND ASSEMBLY >[ATX14B]
TRANSFER ASSEMBLY
38. Remove the sub oil pump cover bolts.
39. Thread two bolts (M4 x 0.8) into the holes of sub oil pump cover
as shown, and pull out to remove the sub oil pump assembly.
40. Remove the outer gear and inner gear from the sub oil pump housing.
41. Remove the oil filter bolts and oil filter. CAUTION:
• Do not damage center case and oil filter.
• Loosen bolts and detach oil filter evenly.
42. Remove the O-rings (1) from the oil filter (2).
SDIA2134E
SMT934C
SDIA2135E
SDIA2136E
WDIA0285E
Revision: March 2010 2008 QX56

TRANSFER ASSEMBLYDLN-157
< DISASSEMBLY AND ASSEMBLY > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
43. Remove the oil filter stud from the oil filter.
44. Remove the O-ring from the oil filter stud.
INSPECTION AFTER DISASSEMBLY
Shift Rod Components
• Check the working face of the shift rod and fork for wear, partial wear, bending and other abnormality. If any is found, replace with a
new one.
• Measure the clearance between the shift fork and sleeve. If it is out of specification, replace it with a new one.
Planetary Carrier
• Measure the end play of each pinion gear. If it is out of specifica-tion, replace the planetary carrier assembly with a new one.
• Check the working face of each gear and bearing for damage, burrs, partial wear, dents and other abnormality. If any is found,
replace the planetary carrier assembly with a new one.
Sun Gear
SDIA3180E
SMT009D
Specification : Less than 0.36 mm (0.0142 in)
SMT010D
Pinion gear end play : 0.1 - 0.7 mm (0.004 - 0.028 in)
PDIA0185E
Revision: March 2010 2008 QX56
