214
30A
30A
30A
20A
15A
15A
15A
–
–
–
–
–
–
–
–
–
Main fuse / Primary fuse
(13)
(14)
(15)
(16)
(17)
(18)
(19)
(20)
(21)
(22)
(23)
(24)
(25)
(26)
(27)
(28)Starting motor fuse
Ignition switch fuse
Blower fan fuse
Air compressor fuse
Throttle motor fuse
Automatic transaxle fuse (if equipped)
Fuel injection fuse
Automatic transaxle relay (if equipped)
Air compressor relay
Fuel pump relay
Condenser fan relay
Front fog light relay
Throttle motor relay
FI MAIN
Starting motor relay
Radiator fan relay
181-224 Fiat16 New GB 3-09-2008 8:18 Pagina 214
216
10A
20A
30A
20A
–
–
–
–
–
–
–
–
–
–
–
–
–
10A
10A
15A
Main fuse / Primary fuse
(19)
(20)
(21)
(22)
(23)
(24)
(25)
(26)
(27)
(28)
(29)
(30)
(31)
(32)
(33)
(34)
(35)
(36)
(37)
(38)Air compressor fuse
Fuel pump fuse
Condenser fan fuse
Fuel injection fuse
Sub heater relay 3
Air compressor relay
Fuel pump relay
Condenser fan relay
Front fog light relay
Sub heater relay 2
Sub heater relay
Starting motor relay
Radiator fan relay
Radiator fan relay
Radiator fan relay
Fuel heater
Fuel injection main
EPI
Fuel injection
INJ DVR
181-224 Fiat16 New GB 3-09-2008 8:18 Pagina 216
