2008 FIAT SEDICI tyre pressure

184
15 30 45 60 75 90 105 120 135 150 165 180
●●●●●●●●●●●●
●●●●●●●●●●●●
●●●●●●●●●●●●
●●●●●●●●●●●●
●●●●●●●●●●●●
●● ●●●●
●●●●●●●●●●●●
●●●●●●●●●●●●
●●
●●
●●●●●●●●●●●●
●● ●●●●
SERVICE SCHEDULE PETROL VERSIONS
Service coupons shall be carried out every 15,000 km
Thousands of km
Check tyre conditions/wear and adjust pressure if required
Check electric system operation headlights,
direction indicators, hazard lights, passenger compartment/
boot light, instrument panel warning lights, etc.)
Check windscreen wiper operation, adjust nozzles if required
Check windscreen blade position/wear
Check front disk brake pad wear conditions and brake
pad wear indicator operation
Check rear disk brake pad or shoes conditions and wear
Sight inspect conditions and integrity of: bodywork and
underbody protection, pipes (exhaust, fuel, brakes),
rubber parts (boots, sleeves, bushes, etc.), brake and
fuel system hoses, axles and axle shafts
Top up fluids (engine coolant, brakes, clutch, battery,
windscreen washer, etc.)
Sight inspect accessory drive belt conditions
Check antievaporation system
Check and adjust handbrake lever stroke, if required
Check and adjust tappet clearance, if required
181-224 Fiat16 New GB 3-09-2008 8:17 Pagina 184

186
15 30 45 60 75 90 105 120 135 150 165 180
●●●●●●●●●●●●
●●●●●●●●●●●●
●●●●●●●●●●●●
●●●●●●●●●●●●
●●●●●●●●●●●●
●● ●●●●
●●●●●●●●●●●●
●●●●●●●●●●●●
●●
●●●●●●
●●●
●● ●●●●
●●●●●●●●●●●●
SERVICE SCHEDULE DIESEL VERSIONS
Service coupons shall be carried out every 15,000 km
Thousands of km
Check tyre conditions/wear and adjust pressure if required
Check electric system operation headlights,
direction indicators, hazard lights, passenger compartment/
boot light, instrument panel warning lights, etc.)
Check windscreen wiper operation, adjust nozzles if required
Check windscreen blade position/wear
Check front disk brake pad wear conditions and brake
pad wear indicator operation
Check rear disk brake pad or shoes conditions and wear
Sight inspect conditions and integrity of: bodywork and
underbody protection, pipes (exhaust, fuel, brakes),
rubber parts (boots, sleeves, bushes, etc.), brake and
fuel system hoses, axles and axle shafts
Top up fluids (engine coolant, brakes, clutch, battery,
windscreen washer, etc.)
Sight inspect accessory drive belt conditions
Check and adjust handbrake lever stroke, if required
Check and adjust tappet clearance, if required
Check exhaust emissions/smoke
Check cleanness of bonnet and boot locks and
lever cleanness and lubrication
181-224 Fiat16 New GB 3-09-2008 8:17 Pagina 186

247
205/60 R16
16 x 6J
Tyre inflation pressure values are specified on the label
located on the driver’s door post
10 mm (254 in.)
10 mm (254 in.)
1 ± 1 mm (0.0393 ± 0.0393 in.)
– 0° 23’ ± 1°
– 0° 10’ ± 1°
3° 40’ ± 2°
3° 32’ ± 2°
WHEELS
Tyres
Rims
Tyre pressure
Recommended snow chains Radial thickness:
Axial thickness:
Wheel geometry Toe-in, front
Camber angle, front
2WD
4WD
Caster angle, front
2WD
4WD
4,115 (162)
1,755 (69.1)
1,605 (63.2)
2,500 (98.4)
1,500 (59.1)
1,495 (58.9)
175 (6.9)
895 (35.2)
720 (28.3)
270/6704,115 (162)
1,755 (69.1)
1,620 (63.8)
2,500 (98.4)
1,495 (58.9)
1,495 (58.9)
190 (7.5)
895 (35.2)
720 (28.3)
270/6704,115 (162)
1,755 (69.1)
1,605 (63.2)
2,500 (98.4)
1,500 (59.1)
1,495 (58.9)
175 (6.9)
895 (35.2)
720 (28.3)
270/6704,115 (162)
1,755 (69.1)
1,620 (63.8)
2,500 (98.4)
1,495 (58.9)
1,495 (58.9)
190 (7.5)
895 (35.2)
720 (28.3)
270/670
DIMENSIONS Unit mm (in.) 1.6 16V1.9 Multijet
2WD 4WD 2WD 4WD
Overall length
Overall width
Overall height
Wheelbase
Track Front
Rear
Ground clearance
Overhang Front
Rear
Boot volume dm3
243-248 Fiat16 New GB 3-09-2008 8:42 Pagina 247
