2008 DODGE CHARGER Owners Manual

Cavity Car-
tridge
FuseMini
FuseDescription
27 Ð 10 Amp
RedOccupant Restraint Con-
troller (ORC)
28 Ð 10 Amp
RedIgnition Run
29 Ð 5 Amp
OrangeCluster/Electronic Sta-
bility Program (ESP) - if
equipped/Powertrain
Control Module (PCM)/
Stop Light Switch
30 Ð 10 Amp
RedDoor Modules/Power
Mirrors/Steering Con-
trol Module (SCM)
31ÐÐÐ
32ÐÐÐ
33ÐÐÐ
34ÐÐÐCavity Car-
tridge
FuseMini
FuseDescription
35 Ð 5 Amp
OrangeAntenna Module - if
equipped/Power Mir-
rors
36 Ð 20 Amp
YellowHands Free Phone - if
equipped/Video Moni-
tor - if equipped/Radio
37 Ð 15 Amp
BlueTransmission
38 Ð 10 Amp
RedCargo Light/Satellite
Receiver (SDARS) Video
- if equipped/Vehicle
Information Module - if
equipped
39 Ð 10 Amp
RedHeated Mirrors - if
equipped
MAINTAINING YOUR VEHICLE 409
7

Cavity Car-
tridge
FuseMini
FuseDescription
40 Ð 5 Amp
OrangeAuto Inside Rearview
Mirror - if equipped/
Heated Seats - if
equipped/Switch Bank
41 Ð 10 Amp
RedAC Heater Control/
Headlights/Tire Pres-
sure Monitoring - if
equipped
42 30 Amp
PinkÐ Front Blower Motor
43 30 Amp
PinkÐ Rear Window Defroster
44 20 Amp
BlueÐ Amplifier - if equipped/
Sunroof - if equipped*Cavities 11, 12, and 13 contain self-resetting fuses
(circuit breakers) that are only serviceable by an autho-
rized dealer. The Cluster and the Driver Seat Switch (if
equipped) are fused by the 25 amp circuit breaker in
Cavity 11. The Passenger Seat Switch (if equipped) is
fused by the 25 amp circuit breaker in Cavity 12. The
Door Modules, the Driver Power Window Switch, and
the Passenger Power Window Switch are fused by the 25
amp circuit breaker in Cavity 13. If you experience
temporary or permanent loss of these systems, see your
authorized dealer for service.
410 MAINTAINING YOUR VEHICLE

CAUTION!
²When installing the Power Distribution Center
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the Power Distribution
Center, and possibly result in an electrical system
failure.
²When replacing a blown fuse, it is important to
use only a fuse having the correct amperage rating.
The use of a fuse with a rating other than indicated
may result in a dangerous electrical system over-
load. If a properly rated fuse continues to blow, it
indicates a problem in the circuit that must be
corrected.
VEHICLE STORAGE
If you are leaving your vehicle dormant for more than 21
days, you may want to take steps to protect your battery.
You may:
²Disconnect the negative cable from the battery.
²Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
insure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
MAINTAINING YOUR VEHICLE 411
7

REPLACEMENT LIGHT BULBS
LIGHT BULBS Ð Interior Bulb Number
Rear Courtesy/Reading Lights.............. W5W
Rear Compartment (Trunk) Light............. 562
Overhead Console Reading Lights............. 578
Visor Vanity Lights.....................A6220
Glove Box Light......................... 194
Door Courtesy.......................... 562
Shift Indicator Light.................JKLE14140
Optional Door Map Pocket /
Cup Holder Lighting....... LED(Serviced at Dealer)
NOTE:For lighted switches, see your dealer for replace-
ment instructions.
All of the interior bulbs are glass wedge base or glass
cartridge types. Aluminum base bulbs are not approved
and should not be used for replacement.LIGHT BULBS Ð Exterior Bulb Number
Low Beam Headlight.....................9006
High Beam Headlight.....................9005
Front Park/Turn Light...................3157A
Front Fog LightÐ
If Equipped..........9145/H10 (Serviced at Dealer)
Front Side Marker.......... 194(Serviced at Dealer)
Tail/Stop Light.........................3057
Tail/Turn Light.........................3057
Rear Side Marker........................ 168
Backup Light........................... 921
Center High Mount Stop Light
(CHMSL)............... LED(Serviced at Dealer)
License................................ 168
412 MAINTAINING YOUR VEHICLE

BULB REPLACEMENT
Low Beam Headlight, High Beam Headlight,
Park/Turn Light, and Front Side Marker Light
1. Open the hood.
NOTE:Removal of the air cleaner filter housing may be
necessary prior to replacing bulbs in the headlight assem-
bly on the driver side of the vehicle.
2. Twist the appropriate bulb and socket assembly
counter-clockwise, and then pull it out of the headlight
assembly.
3. Disconnect the bulb from the socket assembly and
install the replacement bulb.
4. Reinstall the bulb and socket assembly into the head-
light assembly, and then turn it clockwise.
1 Ð High Beam Headlight Bulb
2 Ð Low Beam Headlight BulbMAINTAINING YOUR VEHICLE 4137

CAUTION!
Do not touch the new bulb with your fingers. Oil contami-
nation will severely shorten bulb life. If the bulb comes in
contact with an oily surface, clean the bulb with rubbing
alcohol.
3 Ð Park/Turn Light Bulb4 Ð Side Marker Light Bulb 414 MAINTAINING YOUR VEHICLE

Backup Light, Side Marker Light, Tail/Turn Light,
and Tail/Stop Light
1. Open the Trunk.
2. Remove two fasteners from the back of the tail light
assembly.3. Pull back the trunk liner.
4. Remove the remaining fastener from the back of the
tail light assembly.
5. Push the electrical connector locking tab to the side.
6. Disconnect the electrical connector.
MAINTAINING YOUR VEHICLE 415
7

7. Pull the tail light assembly clear from the vehicle to
access the bulbs.
8. Turn the appropriate bulb and socket assembly
counter-clockwise to remove it from the tail light assem-
bly.
1 Ð Backup Light Bulb
2 Ð Side Marker Light Bulb 416 MAINTAINING YOUR VEHICLE
