2008 CHRYSLER SEBRING CONVERTIBLE Owners Manual

²Press the Learn Button on the Garage Door Opener to
complete the training for Rolling Code.
²Did you unplug the device for training, and remember
to plug it back in?
If you are have any problems, or require assistance,
please call toll-free 1±800±355±3515 or, on the Internet at
www.HomeLink.com for information or assistance.
General Information
This device complies with FCC rules part 15 and Industry
Canada RSS-210. Operation is subject to the following
two conditions:
1. This device may not cause harmful interference
2. This device must accept any interference that may be
received including interference that may cause undesired
operationNOTE:The transmitter has been tested and it complies
with FCC and IC rules. Changes or modifications not
expressly approved by the party responsible for compli-
ance could void the user 's authority to operate the
device.
The term ªIC:º before the certification/registration num-
ber only signifies that Industry Canada technical specifi-
cations were met.ELECTRICAL POWER OUTLETS
There are two 12-volt electrical outlets on this vehicle.
Both of the outlets are protected by a fuse.
The instrument panel power outlet, located below the
climate control knobs, has power available only when the
ignition is on. This outlet will also operate a conventional
cigar lighter unit.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161
3

NOTE:If desired, the instrument panel power outlet
can be converted by your authorized dealer to provide
power with the ignition switch while in the ªLOCKº
position.The center console power outlet is powered directly from
the battery (power available at all times). Items plugged
into this outlet may discharge the battery and/or prevent
engine starting.
Instrument Panel Power OutletConsole Interior
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Electrical Outlet Use With Engine Off
CAUTION!
²Many accessories that can be plugged in draw
power from the vehicle's battery, even when not in
use (i.e. cellular phones, etc.). Eventually, if
plugged in long enough, the vehicle's battery will
discharge sufficiently to degrade battery life
and/or prevent engine starting.
²Accessories that draw higher power (i.e. coolers,
vacuum cleaners, lights, etc.) will degrade the
battery even more quickly. Only use these inter-
mittently and with greater caution.
²After the use of high power draw accessories, or
long periods of the vehicle not being started (with
accessories still plugged in), the vehicle must be
driven a sufficient length of time to allow the
generator to recharge the vehicle's battery.
CIGAR LIGHTER AND ASH RECEIVER Ð IF EQUIPPED
Cup Holder Ash Receiver Ð If Equipped
An optional ash receiver is available from your autho-
rized dealer and will fit in either one of the center console
cup holders.
Optional Cup Holder Ash Receiver
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163
3

CAUTION!
For vehicles equipped with the heated and cooled
cup holder, locate the cup holder ash receiver in the
forward cup holder.
The optional ash receiver also comes with a cigar lighter.
Use the power outlet either in the cubby bin compart-
ment below the climate controls or in the console's
bottom storage compartment to power this cigar lighter.
CUP HOLDERS
Front Seat Cup Holder
The cup holder in the center console will accommodate
either two large size cups or two 20 oz. (1¤2liter) bottles or
cans. The one-piece insert can be removed easily for
cleaning. An optional removable ashtray may be located
in one cavity of the cup holder.
Heated or Cooled Cup Holder Ð If Equipped
With this feature, the rear cavity of the cup holder can
keep cool beverages cool, and hot beverages hot. The rear
cup holder heats to 140ÉF (60ÉC) or cools to 35ÉF (1.6ÉC).
The switch is located on the front of the center console
and has three positions: HEAT, OFF, COOL. When the
164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

unit is on and the LED is Red, the cup holder is being
heated. When the LED is Blue, the cup holder is being
cooled.Rear Seat Cup Holders
Cup holders for the rear seat occupants are located in the
armrests. Each cup holder is capable of holding up to a 20
oz. (
1¤2liter) bottle or can.
Heated or Cooled Cup HolderRear Seat Cup Holder
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165
3

CONSOLE FEATURES
Storage
The center console contains a cubby bin with flip-down
cover located below the climate controls. This compart-
ment also contains a 12-volt electrical outlet.
WARNING!
Do not place ashes inside the cubby bin located on
the center console. A fire leading to bodily injury
could result.
Two separate storage compartments are also located
underneath the armrest.
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

The top compartment holds small items, such as a pen
and note pad, while the larger bottom compartment will
hold CDs and alike. The bottom compartment also con-
tains a 12-volt power outlet and a molded-in coin holder
(designed to hold various size coins). The console's front
opening lid allows for easy access to these compartments.
NOTE:
²A notch in the side of the console base allows for use
of a cell phone while it is plugged into the power
outlet with the armrest latched down.
²The power outlet can also energize the cigar lighter in
the optional cup holder ash receiver.
1 Ð Release button for top compartment
2 Ð Release button for bottom compartment
3 Ð Top Compartment
4 Ð Bottom Compartment. You can access this compartment
directly, without first exposing the upper compartment, by oper-
ating the Release Button for the bottom compartment with the
armrest down.UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167
3

Sliding Armrest Ð If Equipped
On some models, the center console armrest slides for-
ward and rearward for added user comfort.
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
