Using the telephone91
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
– Press the control button for Dial. The telephone number
entered will be dialled.
Should you have entered a telephone number incorrectly, you can
delete the telephone number you have entered into the speller by
pressing the control button .
Note
•DTMF tones can be entered directly using the speller or loaded
from the telephone numbers stored in the memory lists
page 91.
•The audio source is muted automatically when you make or
receive telephone calls. The mute symbol
page 42, fig. 31 will
then appear in the status line.
•If you activate the voice guidance option off (phone)* in the navi-
gation* function you will not hear any navigation cues while you are
talking on the telephone*
page 119.
•If the MMI display was switched off, it will be switched on auto-
matically for the duration of the telephone call.
Applies to vehicles: with Bluetooth car telephone kit or phone pre-installation
From a list
Important: The telephone mode must be activated

page 26.
Finding and calling a telephone number from a
list
– Press the Memory control button.
– Turn the rotary pushbutton and select Numbers dialled,
Directory, Phone book, Received calls or Missed calls.
– Press the rotary pushbutton. The telephone numbers in
the selected list will appear in the MMI display.
– Turn the rotary pushbutton to the telephone number you
wish to select.
– Press the rotary pushbutton. The selected telephone
number will be entered into the speller automatically.
– To start the call, turn the speller to OK and press the
rotary pushbutton, or
– Press the control button for Dial.
Calling up the Numbers dialled list (shortcut) and
calling a number
– Press the function selector button marked . The
speller will appear on the MMI display. There will be no
phone number in the entry space of the speller.
– Press the control button for Dial. The Numbers dialled list
will appear in the MMI display.
– Turn the rotary pushbutton to the telephone number you
wish to select.
– Press the rotary pushbutton. The selected telephone
number will be entered into the speller automatically.
RETURN
Fig. 85 Selecting a
telephone number
from a list
TEL










Using the telephone 92
– To start the call, turn the speller to OK and press the
rotary pushbutton, or
– Press the control button for Dial.
Note
•In vehicles fitted with the Bluetooth car telephone kit any Missed
calls will be indicated by the symbol
page 91, fig. 85 on the
MMI display.
•The telephone functions will depend on the mobile network
service provider and the mobile phone used. For more information,
contact your service provider.
Applies to vehicles: with Bluetooth car telephone kit or phone pre-installation
Answering and ignoring telephone
calls
Important: There must be an incoming call.
Answering telephone calls
– Turn the rotary pushbutton to Answer and press to
confirm, or– Press the control button for Answer.
Ignoring telephone calls
– Turn the rotary pushbutton to Ignore and press to
confirm, or
– Press the control button for Ignore.
Depending on whether the caller is stored in the phone book and
whether the number is transmitted with the call, the name, the tele-
phone number or Unknown will appear on the MMI display.
Note
•You can answer an incoming call while you are already talking on
the phone. The active telephone call will then be placed on hold
automatically.
•The audio source is muted automatically when you make or
receive telephone calls. The mute symbol
page 42, fig. 31 will
then appear in the status line.
•If you do not want to hear any navigation cues while you are on
the phone, simply switch off the route guidance
page 119.
•You can also answer and ignore incoming calls using the multi-
function steering wheel
page 135.
•In vehicles fitted with phone pre-installation* a call can also be
answered by pressing the talk button on the mobile phone adapter

page 161, fig. 145.
Applies to vehicles: with Bluetooth car telephone kit or phone pre-installation
Ending calls
Important: You must be talking on the phone, or the phone
must be establishing a connection.
A2
Fig. 86 Answering an
incoming call











Using the telephone93
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
– To end a call or stop dialling a number, press the control
button for End call.
Note
•You can also end telephone calls using the multi-function
steering wheel
page 134.
•In vehicles fitted with phone pre-installation* calls can also be
ended by pressing the talk button on the mobile phone adapter

page 161, fig. 145.
Applies to vehicles: with Bluetooth car telephone kit or phone pre-installation
Storing a telephone number in the
directory
You can store a new telephone number or telephone
numbers from the call lists in the directory.
New telephone number
– Enter a telephone number via the speller
page 90.
Stored telephone number
– Press the Memory control button.– Turn the rotary pushbutton and select Numbers dialled,
Phone book, Received calls or Missed calls.
– Press the rotary pushbutton. The available telephone
numbers will be listed in the MMI display.
– Turn the rotary pushbutton to the telephone number you
wish to store.
– Press the rotary pushbutton. The telephone number you
wish to store will be entered into the speller automati-
cally.
Storing an entered telephone number
– Press the Memory control button.
– Turn the rotary pushbutton to Store current number and
press to confirm.
– To make a new entry, turn the rotary pushbutton to New
entry and press to confirm, or
– To add the telephone number to an existing entry, turn
the rotary pushbutton to mark the existing entry and
press it.
– Turn the rotary pushbutton and select Surname

fig. 87.
– Press the rotary pushbutton to open the entry space
Surname. The speller will appear on the MMI display

page 43.
– Using the speller, enter the name and confirm your entry
by turning the speller to mark OK and then pressing the
rotary pushbutton. The entry space will appear in the
MMI display.
Fig. 87 Storing a tele-
phone number in the
directory










Using the telephone95
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
Note
•The option Call waiting must be activated for you to be made
aware of incoming calls during a conversation
page 97. This
option depends on your mobile network service provider.
•The options available during a call may vary depending on the
mobile network service provider.
Applies to vehicles: with Bluetooth car telephone kit
Options during a call
Various options can be used during a call.
– To display the available options on the MMI display while
you are speaking on the phone, press the control button
for Options during the call
fig. 89.
The call options available during a call depend on the current tele-
phone status. For example, if two calls are active the option
Switch*
13) will appear in the MMI display
fig. 89. For example, if
you set up a telephone conference using the Join conference*13)
function, the options Hold and Show conference participants will
appear in the MMI display.
Holding/resuming a call*
13)
The Hold and Resume options allow you to hold a call and retrieve it
later from the hold queue. On hold appears in the display, together
with the amount of time the call has been on hold.
To end a call that is on hold press the control button for End call.
Placing a further call (Dial)*
13)
First select Hold* to place the active call on hold. Then press the
control button for Options or the button on the control
console to close the Options menu. Now enter a telephone number
using the speller
page 90, fig. 83. Select OK or Dial to start dial-
ling.
Press the control button for End call to end whichever call is active.
If you placed a call on hold earlier on, that call will remain on hold.
You can end the call that is on hold by pressing the control button
for End call again.
Switching the microphone on/off
Your caller cannot hear your private conversations when the micro-
phone is off. You can still hear the caller. Mike off appears in the
MMI display.
Fig. 89 Switching
between calls
Fig. 90 Show confer-
ence participants
13)Applies to mobile phones with SIM Access Profile.
RETURN










Using the telephone97
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control deactivated. Once you have bonded your mobile phone, you should
switch this function off to prevent your car telephone (vehicle base
station) from being discovered by other users.
Default settings
This function returns the car telephone settings to the factory
defaults. This will delete your user data, including the phone books
stored in the memory
page 29, any bonded Bluetooth devices

page 24 and your mailbox number.
Call information*
14)
This function determines whether the vehicle occupants can see the
telephone numbers in the MMI display.
•on - the telephone numbers or names are shown in the MMI
display. All call lists are deleted when you switch on this function.
•off - asterisks ******** appear in the MMI display in place of tele-
phone numbers and names during inbound and outbound calls.
Telephone numbers stored on the MMI cannot be accessed. The call
lists are not updated.
Sound focus
•front - to direct the audio output during a telephone call to the
front loudspeakers.
•centre - to direct the audio output during a telephone call to the
front and centre loudspeakers.
Shutdown delay
•Activated (ticked ) - the telephone system remains active for a
period (factory default setting) after you switch off the MMI. You can
still make calls during this period.
•Deactivated (not ticked) - the telephone system shuts down
when you switch off the MMI. In this case, you can use a twin card
shortly after leaving the vehicle
page 30.
Note
The telephone settings depend on your mobile network service
provider.
Applies to vehicles: with Bluetooth car telephone kit
Call options
– Select: Function selector button > function selector
button > Call options.
Call waiting*16)
•Activate - when you are on the phone an audible tone will tell you
if a caller is trying to reach you.
•Deactivate - when you are on the phone you will not be informed
if a caller is trying to reach you.
•Status - to display whether the call waiting function is on or off.
Transmit caller ID*
16)
•Activate - to transmit your telephone number with outbound
calls.
•Deactivate - to suppress your telephone number during
outbound calls.
•Network-dependent - to use the setting agreed in your mobile
network service contract.
•Check status - to check whether the setting for this function is
activated, deactivated or network-dependent.
Automatic redial
•on - to dial a number automatically up to five times if the line is
engaged. Select End call if you want to cancel the automatic redial
function.
16)Applies to mobile phones with SIM Access Profile.
TEL
SETUP










Using the telephone99
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control Once the number has been stored, you can call the mailbox by
pressing the control button for Memory.
Note
This service must be set up beforehand. For more information,
contact your service provider.
Applies to vehicles: with Bluetooth car telephone kit
Calling the mailbox
– Select: Function selector button > control button
Memory > Call mailbox.
The mailbox number must be stored first
page 98. This service
must be set up and activated on your mobile network before you
can use it. For more information, contact your service provider.
Applies to vehicles: with Bluetooth car telephone kit
Forwarding calls
– Select: Function selector button > function selector
button > Call forward.
Forward phone calls17)
Incoming calls are forwarded to your mailbox or another number.
You can choose from the following:
•Forward all calls - to forward all incoming phone calls.
•Forward if busy - to forward calls when you are already talking on
the phone.
•Forward if not available - to forward calls when the phone is
switched off.
•Forward if no answer - to forward calls that you do not answer.
Forward fax calls
17)
Incoming fax calls are forwarded to the specified number.
Forward data calls
17)
Incoming data calls are forwarded to the specified number.
Deactivate all fwd settings
17)
All call forward settings can be deleted at once.
Applies to vehicles: with Bluetooth car telephone kit
Network selection
– Select: Function selector button > function selector
button > Network selection.
Login18)
•automatic - your telephone will automatically log into your
mobile service provider network.
•manual - a list of all available networks will appear on the display.
Select a network.
Network selection
18)
The networks for your present location are listed. You can choose
any of the available networks. This function can be used when the
manual login setting is activated.
Note
For further information about networks, please contact your mobile
network service provider.
17)Applies to mobile phones with SIM Access Profile.
TEL
TEL
SETUP
18)Applies to mobile phones with SIM Access Profile.
TEL
SETUP










Using the telephone101
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control Options
20)
The following functions are available under Options when you open
a text message to read it:
•Delete - to delete the open text message.
•Call - to dial the number of the person who sent the text
message.
•Extract number - to copy a telephone number contained in the
open text message into the speller for editing.
Note
•A crossed-out envelope symbol in the status line indicates that
there is not enough memory space available for new text messages.
In this case, you will have to delete one or more text messages from
the SIM card before you can receive further text messages.
•You can write and send text messages using the handset*

page 154.
Other settings for the phone pre-
installation
Applies to vehicles: with phone pre-installation
Options during a call
Important: You must be talking on the phone
page 90.
– Select: Control button Options > Mike off.
Switching microphone on/off
Your caller cannot hear your private conversations when the micro-
phone is off. You can still hear the caller. Mike off appears in the
MMI display.Replacing a call
If you are already talking on the phone when someone else calls, the
options Replace and Ignore will appear on the MMI display.
If you select Replace, the active call will be replaced by the incoming
call. If you select Ignore, the incoming call will be declined.
The display in the MMI may remain for several seconds afterwards
(depends on your type of phone). Should you use the function
Replace or Ignore in the MMI system during this time, it is possible
that the current call will be ended.
Note
The option Call waiting must be activated on your mobile phone for
you to be made aware of incoming calls during a conversation. The
call options depend on your mobile network service provider.
Applies to vehicles: with phone pre-installation
Telephone settings
– Press the > buttons on the MMI control
console and select Telephone settings on the MMI.
Bluetooth settings
•PIN for handsfree mode - to change the factory default (1234).
This PIN number has to be entered when you bond a Bluetooth
mobile phone with the Hands-Free Profile to the on-board phone
system
page 22.
•Remove Bluetooth devices - to delete all bonded mobile phones.
Default settings
The on-board phone system is returned to the factory defaults. This
will delete your user data, including the phone books stored in the
memory
page 23, any bonded Bluetooth devices
page 22 and
your mailbox number.
TELSETUP










Using the telephone103
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control Sort call lists
The telephone numbers in the call lists are sorted by the time of the
call. If this function is activated, the list is sorted in reverse order.
Phone book used
•SIM - SIM card entries are loaded onto the on-board phone
system and displayed on the MMI.
•Telephone - phone book entries on the mobile phone are loaded
onto the on-board phone system and displayed on the MMI.
•SIM+Tel - SIM card entries and phone book entries on the mobile
phone are loaded onto the on-board phone system and displayed
on the MMI.
Note
Depending on your mobile phone, it may not be possible to access
the SIM card entries or phone book entries on your mobile phone.
For further information, please ask an Audi dealer or specialist
retailer.
