Basic operation 42
MMI display
“Standard” menus
After pressing a function selector button page 41, a menu will
appear in the MMI display.
Fig. 30 Setup Naviga-
tion
Fig. 31 Radio
submenu
LegendSymbol /
MarkingExplanation
Heading
Selected mode (e.g. radio fig. 31).
Display in Setup menu: Setup menu in
the selected mode (e.g. Setup Naviga-
tion fig. 30).
In vehicles with a telephone* the net-
work provider and, if applicable, the
roaming symbol
will be shown.
TMC symbolsReception of TMC traffic messages
page 121.
Arrows
pointing
up/downIndicate further menu options
(next/previous page).
CursorPoints to the item selected in a menu.
Selected
optionA selected item is highlighted in white.
Selection boxSelection possibilities for selected
item.
ArrowIndicates more selection or setting
possibilities.
Temperature
display*Selected temperature setting in vehi-
cles with automatic air conditioner*.
Signal
strength indi-
cator*Quality of mobile phone connection,
or
PIN: Entering PIN page 88
PUK: Entering PUK page 88
SIM: Inserting SIM card
Envelope*
Unread text message page 100.
Crossed-out envelope: No more text
messages can be received (SIM card
memory is full) page 100.
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
Basic operation51
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
– Press the button , the rotary pushbutton
and the top right control button simultaneously.
– Then release the buttons. The MMI system will switch off
and then restart.
Other settings
MMI menu language
– Select: Function selector button > control button
Settings > Menu language.
The language of texts shown on the MMI display and the driver
information system as well as the language of the voice guidance*
can be altered.
You can select the languages German, English, French, Italian,
Spanish, Portuguese, Dutch or Russian.
Measurement units
– Select: Function selector button > control button
Settings > Measurement units.
You can alter the measurement units shown on the MMI display, the
driver information system and the air conditioner display.
The units for distance (km or miles), speed (km/h or mph), tempera-
ture (°C or °F) and pressure (bar or psi) can be set.
Applies to vehicles: with speech dialogue system
Speech dialogue system
– Select: Function selector button > control button
Settings > Speech dialogue system.
Repeat command
If Repeat command is activated, the speech dialogue system* will
repeat your commands when switching to another function.
Deleting all name tags
All the name tags (spoken names or telephone numbers) you have
stored will be deleted.
Default settings
– Select: Function selector button > control button
Settings > Default settings.
This function resets the general settings, the sound settings as well
as several of the radio, CD, TV/AV*, telephone* and navigation*
settings to the default settings.
Brightness of the MMI display
– Select: Function selector button > control button
Display > Brightness.
You can alter the brightness of the display by turning the rotary
pushbutton clockwise or anti-clockwise.
SETUPA1A2
A3
SETUP
SETUP
SETUP
SETUP
SETUP
Speech dialogue system 170
Basic operation
Applies to vehicles: with multi-function steering wheel and speech dialogue system
Switching on and off
Important: The MMI system must be switched on
page 40, the air conditioner must not be operated, and
you must not be talking on the phone.
Switching on
– Briefly press the talk button fig. 152 on the
multi-function steering wheel. The signal tone
will indicate that the speech dialogue system is ready.
The volume for any active audio source will then be
muted.
– Say the desired command.
Switching off
– Say the command CANCEL, or
– Press and hold the talk button fig. 152 until you
hear the cue .Note
The speech dialogue system can also be deactivated by pressing
any one of the buttons in the MMI control console page 41.
Applies to vehicles: with multi-function steering wheel and speech dialogue system
Adjusting the volume
Important: The speech dialogue system must be switched
on page 170, and the system must be giving a cue.
– Scroll the right thumbwheel on the multi-function
steering wheel up/down.
Note
You can also adjust the volume by turning the ON/OFF button
page 45.
Applies to vehicles: with multi-function steering wheel and speech dialogue system
Adjusting the basic volume level
You can set the basic volume for the speech dialogue
system via the MMI.
Fig. 152 Talk button
and right thumbwheel
A1
A1
A2
Fig. 153 Adjusting
basic volume
