2008.5 Citroen C4 PICASSO Owner's Manual

54
III
C O M F O R T
RECOMMENDED INTERIOR SETTINGS
- Heating/Manual air conditioning
To make the best use of the system, we recommend:
- Automatic air conditioning
With automatic air conditioning, you are recommended to choose AUTO operation.

Action

To have

Cold

or

Max. cold

to start with,
then personal

adjustments
Max. to start
with, then personal
adjustments
ON
ON to start
with, then OFF

Hot

or

Max. hot to
start with,
then personal adjustments
Max. to start
with, then personal
adjustments

ON to start
with, then OFF

Demisting

De-icing
Max. hot OFF

53
III
C O M F O R T
ADDITIONAL AIR CONDITIONING
Additional air conditioning allows you
to optimise comfort levels in warm
weather conditions. It produces ad-
ditional fresh air which is supplied
using the rear air vents. The supply
of warm air via the rear air vents is
not possible using this system.
C. REAR PASSENGER CONTROL PANELS (RIGHT/LEFT)
13. Adjustment of temperature
The rear passengers can adjust their
temperature controls independently
via buttons + and - .
Their preference cannot be greater
than that of the driver by more than
2. The reaching of this maximum
preference is confi rmed by the fl ash-
ing of its display.
14. Adjustment of air blower speed
The air blower operates only when
the engine is running.
To adjust the fl ow of air, press on
button:
to increase the air fl ow,
to decrease the air fl ow. The level of air fl ow is indicated on
the display by the progressive fi lling
of the ventilator blades.
By reducing the fl ow to minimum,
you deactivate the air conditioning
system (OFF).
You can adjust the temperature and
the air fl ow only if the driver enables
you to (see button
6 of the driver’s
control panel).
This warning lamp signifi es
that the passenger controls
are locked, you can adjust
neither the temperature nor
the air fl ow, which remain aligned on
the preferences of the driver.
This warning lamp indi-
cates that the supply of air
is cut off .
This position is recommended in
cold weather conditions, as the air
vents do not supply warm air.

55
III
C O M F O R T
SCENTED AIR FRESHENER
The scented air freshener releases
a fragrance into the passenger com-
partment via the central air vents.

 Rotate the button A to adjust (to
the left to reduce, to the right to
increase) or stop (maximum to
the left) the fl ow of scented air.
The central air vents have to be
open.
 Press the button A , rotating it a
quarter turn to the left as far as it
will go.

 Remove the air freshener from
the dashboard.

 Replace the cartridge (see
§ "Changing the cartridge"). After fi tting or changing a cartridge:

 Place the air freshener back in
its housing.

 Rotate it a quarter turn to the
right.
Adjustment of flow To remove the air freshener To insert the air freshe
ner
The air freshener contains an
empty cartridge when your vehicle
is delivered. You therefore need to
insert a cartridge in order to use
the air freshener.
A cartridge lasts on average 3 months,
based on one hour’s usage per day.

56
III
C O M F O R T
The recharge for the air freshener
consists of a cartridge B and its
sealed container C .

 Remove the protective fi lm D .

 Place the head of the cartridge B
on the button A of the air fresh-
ener.

 Rotate it a quarter turn to lock
it on the button and remove the
container.

 Insert the air freshener into its
housing.
You can change cartridges at any
time, keeping the used cartridges in
their original containers. The air freshener button
A is inde-
pendent of the cartridge. Cartridges
are supplied without the air freshener
button A .
The button of the air freshener A can
only be fi xed into the central dash-
board with a cartridge attached.
Therefore always keep the air fresh-
ener button A and one cartridge.
Recharges are available, depending
on country, either on the Internet site
or from a CITROËN dealer.
Stowage points are provided in the
glovebox for storing of cartridges
and containers. For safety, use only cartridges that
are provided for this purpose.
Retain the containers for the stor-
age of used cartridges.
Do not attempt to take cartridges
apart.
Never recharge the cartridges
with fragrances not supplied by
CITROËN.
Keep them out of reach of children
and animals.
Avoid all contact with the skin and
with the eyes.
In the event of swallowing, consult
a doctor and show him the product
packaging or label.
Do not install or remove a cartridge
while you are driving.
Replacing a cartridge Air freshener button

57
III
C O M F O R T
FRONT SEATS
MANUAL ADJUSTMENTS
1. Longitudinal adjustment
Raise the control bar, then slide the
seat to the position desired. 2. Lumbar support
Rotate the control until you attain
the position desired. 3. Seat height adjustment
Raise or lower the the control the
number of times necessary to obtain
the position desired.
4. Backrest angle
Action the control and adjust the an-
gle of the backrest.
It is possible to incline the back-
rest 45° rearwards by tilting it until it
locks; to unlock it, lift the control.
5. Armrest
To adjust the position of the armrest,
pull it up and then fully down, and
then raise it to the desired position.
6. Head restraint
To raise it, pull it upwards. To lower
it, press on the control as well as on
the head restraint.
The adjustment is correct when the
top of the head restraint is level with
the top of the head.
It can also be adjusted for tilt.
To remove it, press on the unlocking
button and pull it upwards.
To adjust the head restraint for-
wards/backwards, move the base of
the head restraint to obtain the posi-
tion desired.
Never drive without the head re-
straints fi tted. They must be in
place and adjusted correctly.

58
III
C O M F O R T
FRONT SEATS
1. Adjustment of the seat height and angle,
longitudinal adjustment 2. Adjustment of backrest
angle and lumbar support
The seats can also be adjusted elec-
trically on a temporary basis:
- on opening one of the front doors,
- after switching off the ignition. Heated seats control
ELECTRIC ADJUSTMENTS
Raise or lower the front of
control
1 to raise or lower
the front of the seat base
(on driver’s seat).
Raise or lower the rear of
control 1 to raise or lower
the seat.
Action control 1 forwards or
rearwards to slide the seat
forwards/backwards. Push the top of control
2 for-
wards or rearwards to adjust
the backrest angle.
Raise or lower control 2 to
increase or decrease the
lumbar support.
With the engine running, the front
seats can be heated separately.

 Use the corresponding adjust-
ment dial, placed on the inner
side of each front seat, to switch
on and select the level of heating
required:
0 : Off.
1 : Low.
2 : Medium.
3 : High.

59
III
C O M F O R T
Storing driving positions
System which takes into account the
electrical settings of the driver's seat
and exterior mirrors. It enables you
to store up to two positions using the
buttons on the side of the driver's
seat. Storing a position
Using buttons M/1/2

 Switch on the ignition.

 Adjust your seat and your exte-
rior mirrors.

 Press button M , then press but-
ton 1 or 2 within four seconds.
An audible signal is heard indi- cating that the position has been
stored.
Storing a new position cancels the
previous position. Recalling a stored position
Ignition on or engine running

 Briefl y press button 1 or 2 to re-
call the corresponding position.
An audible signal is heard indicating
the end of the adjustment.
When the ignition is on, after a few
consecutive position recalls, the
function will be deactivated until the
engine is started, to prevent dis-
charging of the battery.
Vehicle moving

 Press and hold button 1 or 2
until the audible signal is heard
indicating the end of the adjust-
ment.
Do not try to store a driving position
while driving.

60
III
C O M F O R T
REAR HEAD RESTRAINTS
The rear head restraints can be
removed and have two positions:
- high, position for use,
- low, storage position.
To raise a head restraint, pull it up-
wards.
To lower it, press the lug then the
head restraint.
To remove it, place it in the high
position, push the lug and pull it up-
wards.
To refi t it, engage the head restraint
rods in the holes taking care to remain
in the centreline of the seat back.
SECOND ROW SEATS
Longitudinal adjustment
Lift the control A , located at the front
of the seat, then adjust the seat into
the position desired. "Comfort" position
The 3 second-row seats are inde-
pendent of each other and all the
same width. They all can have a
"comfort" position.
Placing a seat in the "comfort"
position

 Pull on the control B and guide
the seat rearwards.
The backrest reclines and the seat
base pivots slightly.
Returning the seat to the initial
position

 Pull on the control B and allow
the seat to come forwards.

Always supervise any move-
ments of seats by children.
Never drive with the head restraints
removed, they must be in place
and correctly adjusted.
