ILLUMINATED GLOVE BOX
This has areas for storing a bottle of
w a t e r , t h e v e h i c l e ' s h a n d b o o k p a c k ,
etc.
I t s l i d h a s a r e a s f o r s t o r i n g a p e n , a
p a i r o f s p e c t a c l e s , t o k e n s , c a r d s , a
c a n , f r a g r a n c e c a r t r i d g e s . . .
T o o p e n t h e g l o v e b o x , r a i s e t h e
handle and lower the lid.
REFRIGERATED GLOVEBOX
I t m a y b e r e f r i g e r a t e d , d e p e n d i n g o n
y o u r v e h i c l e ’ s e q u i p m e n t , b y a v e n -
tilation duct that can be closed off
manually.
W i t h t h e a i r c o n d i t i o n i n g , t h i s d u c t
distributes the same cooled air as
the vents in the passenger compart-
ment.
T h e r e f r i g e r a t i o n o f y o u r g l o v e b o x
only operates when the engine is
running and the air conditioning is
on.
The lamp comes on au-
tomatically when the lid is
opened. F o r s a f e t y r e a s o n s , t h e
g l o v e b o x s h o u l d r e m a i n
closed when the vehicle is
moving.
Page 96 of 282
80
VI
F I T T I N G S
ILLUMINATED GLOVE BOX
This has areas for storing a bottle of
w a t e r , t h e v e h i c l e ' s h a n d b o o k p a c k ,
etc.
I t s l i d h a s a r e a s f o r s t o r i n g a p e n , a
p a i r o f s p e c t a c l e s , t o k e n s , c a r d s , a
c a n , f r a g r a n c e c a r t r i d g e s . . .
T o o p e n t h e g l o v e b o x , r a i s e t h e
handle and lower the lid.
REFRIGERATED GLOVEBOX
I t m a y b e r e f r i g e r a t e d , d e p e n d i n g o n
y o u r v e h i c l e ’ s e q u i p m e n t , b y a v e n -
tilation duct that can be closed off
manually.
W i t h t h e a i r c o n d i t i o n i n g , t h i s d u c t
distributes the same cooled air as
the vents in the passenger compart-
ment.
T h e r e f r i g e r a t i o n o f y o u r g l o v e b o x
only operates when the engine is
running and the air conditioning is
on.
The lamp comes on au-
tomatically when the lid is
opened. F o r s a f e t y r e a s o n s , t h e
g l o v e b o x s h o u l d r e m a i n
closed when the vehicle is
moving.
Page 117 of 282
98
VIII
S A F E T Y
TRAJECTORY CONTROL SYSTEMS
Anti-skid regulation (ASR) and
electronic stability programme
(ESP)
The anti-skid regulation (also known
as Traction Control) optimises
traction to prevent skidding of the
wheels, by acting on the brakes of
the driving wheels and on the en-
gine.
The electronic stability programme
acts on the brake of one or more
wheels and on the engine to keep
the vehicle on the trajectory required
by the driver.
Activation
These systems are activated auto-
matically each time the vehicle is
started.
They come into operation in the event
of a grip or trajectory problem. T h i s i s i n d i c a t e d b y fl a s h i n g
of this warning lamp on the
instrument panel. Deactivation
I n e x c e p t i o n a l c o n d i t i o n s ( s t a r t i n g a
vehicle which is bogged down, stuck
in snow, on soft ground...), it may be
advisable to deactivate the ASR and
ESP systems, so that the wheels
can move freely and regain grip.
Press the "ESP OFF" button,
located in the centre of the
dashboard. Reactivation
These systems are reactivated au-
tomatically each time the ignition is
switched back on or from 30 mph
(50 km/h).
Press the "ESP OFF" button again
to reactivate them manually.
If this warning lamp comes
on in the instrument panel
and the indicator lamp on the
button comes on, this indi-
cates that the ASR and ESP
systems are deactivated. Operating fault
If this warning lamp comes
on, accompanied by an au-
dible signal and a message
on the multifunction screen,
this indicates a malfunction of these
systems.
Have the systems checked by a
CITROËN dealer.
T h e E S P / A S R s y s t e m s o f f e r e x -
ceptional safety in normal driving,
but this should not encourage the
d r i v e r t o t a k e e x t r a r i s k s o r d r i v e a t
high speed.
The correct functioning of these
systems depends on observation
of the manufacturer's recommen-
dations regarding the wheels (tyres
and rims), the braking components,
the electronic components and the
CITROËN assembly and operation
procedures.
After an impact, have these sys-
tems checked by a CITROËN
dealer.
Page 126 of 282
106
IX
D R I V I N G
PARKING BRAKE
Mechanical brake to hold the vehicle
when stationary.
Applying
Pull the parking brake to immobi-
lise your vehicle.
Releasing
Pull on the handle and press
the button to release the parking
brake.
When the vehicle is being driven,
if this warning lamp and the STOP
warning lamp come on, accompa-
nied by an audible signal and a mes-
sage on the multi-function screen,
this indicates that the parking brake
is still on or has not been properly
released.
When parking on a slope, direct your
wheels against the pavement, pull
the parking brake on and engage
a gear.
5-SPEED MANUAL GEARBOX
Starting the vehicle
Check that the gear lever is in
neutral.
Do not touch the accelerator.
For Diesel engines: turn the
key to position M and wait until
the pre-heating warning lamp
switches off if it has come on.
Operate the starter, turning the
key until the engine starts (no
more than ten seconds).
In temperatures lower than 0 °C,
declutch whilst turning the starter
to facilitate starting. Engaging reverse gear
Push the gear lever to the
right then rearwards.
Only engage reverse gear when
the vehicle is stationary with the
engine at idle.
Page 127 of 282
107
IX
D R I V I N G
(6-SPEED) ELECTRONIC GEARBOX SYSTEM
The (6-speed) electronic gearbox of-
fers a choice between the comfort of
fully automatic operation or the driving
pleasure of manual gear changing.
Therefore, you have a choice of two
driving modes:
- the automatic mode for auto-
matic control of the gears by the
gearbox,
- the sequential mode for manu-
al changing of the gears by the
driver.
6-SPEED MANUAL GEARBOX
