INTRODUCTION
EAU10100
Welcome to the Yamaha world of motorcycling!
As the owner of the MT-03, you are benefiting from Yamaha’s vast experience and newest technology regarding the de-
sign and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
Please take the time to read this manual thoroughly, so as to enjoy all advantages of your MT-03. The owner’s manual
does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard yourself
and others from trouble and injury.
In addition, the many tips given in this manual will help keep your motorcycle in the best possible condition. If you have
any further questions, do not hesitate to contact your Yamaha dealer.
The Yamaha team wishes you many safe and pleasant rides. So, remember to put safety first!
MY03 01-03 ING 6-10-2005 13:52 Pagina 3

IMPORTANT MANUAL INFORMATION
Particularly important information is distinguished in this manual by the following notations:
WARNING0
NOTE:
CAUTION:
The Safety Alert Symbol means ATTENTION! BECOME ALERT! YOUR SAFETY IS
INVOLVED!
Failure to follow WARNING instructions could result in severe injury or death to the
motorcycle operator, a bystander, or a person inspecting or repairing the motorcycle.
A CAUTION indicates special precautions that must be taken to avoid damage to
the motorcycle.
A NOTE provides key information to make procedures easier or clearer.
NOTE:
This manual should be considered a permanent part of this motorcycle and should remain with it even if the motor-
cycle is subsequently sold.
Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the
most current product information available at the time of printing, there may be minor discrepancies between your
motorcycle and this manual. If you have any questions concerning this manual, please consult your Yamaha dealer..
EWA10030
WARNING0
PLEASE READ THIS MANUAL CAREFULLY AND COMPLETELY BEFORE OPERATING THIS MOTORCYCLE.
* Product and specifications are subject to change without notice.
EAU10151
MY03 01-03 ING 6-10-2005 13:52 Pagina 4

IMPORTANT MANUAL INFORMATION
MT-03
OWNER'S MANUAL
©2006 by Yamaha Motor Italia S.P.A.
2
ndedition, september 2006
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Italia S.P.A.
is expressly prohibited.
Printed in the Italy.
EAUB1011

TABLE OF CONTENTS
