2007 TOYOTA FJ CRUISER Owners Manual

1112007 FJ CRUISER from Oct. ’06Prod. (OM35873U)
(n) Unengaged “Park” Warning Light(fourwheel drive models)
This light warns that the transmission
“Park” mechanism is not engaged. If the
four −wheel drive control lever is in the “N”
position while the selector lever is in the
“P” position, the transmission will disen-
gage and the wheels will not lock.
CAUTION
To restore the park function, shift the
fourwheel drive control lever out of
“N”, or the vehicle can move.
(o) Key Reminder Buzzer
This buzzer acts as a reminder to remove
the key when you open the driver’s door
with the ignition key in the “ACC” or
“LOCK” position. CHECKING SERVICE REMINDER
INDICATORS (except the low fuel level
warning light)
1. Apply the parking brake.
2. Open one of the side doors, back door or back window.
The open door warning light should
come on.
3. Close the door and back window. The open door warning light should go
off.
4. Turn the ignition key to “ON”, but do not start the engine.
All the service reminder indicators ex-
cept the open door warning light should
come on.
The following service reminder indica-
tors go off after a few seconds:
Engine oil replacement reminder light
“ABS” warning light
“VSC TRAC” warning light
“AUTO LSD” indicator light
(two −wheel drive models)
“VSC OFF” indicator light
(four− wheel drive models, and vehicles
with rear differential lock)
Slip indicator light The SRS warning light goes off after
about 6 seconds.
There may be the case that the “ABS”
warning light (brake assist system
warning light), “VSC TRAC” warning
light and “AUTO LSD” (two
−wheel drive
models), “VSC OFF” (four −wheel drive
models, and vehicles with rear differen-
tial lock) or slip indicator light stay on
for about 60 seconds after the ignition
key is turned to the “ON” position. It
is normal if they go out after a while.
If any service reminder indicator or warn-
ing buzzer does not function as described
above, have it checked by your Toyota
dealer as soon as possible.

11 22007 FJ CRUISER from Oct. ’06Prod. (OM35873U)

11 32007 FJ CRUISER from Oct. ’06Prod. (OM35873U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Ignition switch, Transmission and Parking brake
Ignition switch11 4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Automatic transmission 11 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
Manual transmission 11 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
Four −wheel drive system 120
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Traction control system 123
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
Active traction control system 125
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
“AUTO LSD” system 127
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
Vehicle stability control system 130
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear differential lock system 132
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking brake 134
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Cruise control 135
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Clutch start cancel switch 137
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
SECTION 1 7

11 42007 FJ CRUISER from Oct. ’06Prod. (OM35873U)
TS17001a
“START”—Starter motor on. The key
will return to the “ON” position when
released.
For starting tips, see page 231 in Section
3.
“ON”—Engine on and all accessories
on.
This is the normal driving position.
“ACC”—Accessories such as the radio
operate, but the engine is off.
If you leave the key in the “ACC” or
“LOCK” position and open the driver’s
door, a buzzer will remind you to remove
the key.“LOCK”—Engine is off and the steering
wheel is locked. The key can be re-
moved only at this position.
The selector lever must be put in the “P”
position before turning the key from “ACC”
to the “LOCK” position.
When starting the engine, the key may
seem stuck at the “LOCK” position. To
free it, first be sure the key is pushed all
the way in, and then rock the steering
wheel slightly while turning the key gently.
Approximately five hours after the engine
is turned off, you may hear sound coming
from underneath the luggage compartment
for several minutes. This is normal opera-
tion and does not indicate a malfunction.
(See “Leak detection pump” on page x.)
It is not a malfunction if the needles on
all meters and gauges move slightly when
the key is turned to the “ACC”, “ON” or
“START” position.
CAUTION
For manual transmission:
Never remove the key when the ve-
hicle is moving, as this will lock the
steering wheel and result in loss of
steering control.
NOTICE
Do not leave the key in the “ON”
position if the engine is not running.
The battery will discharge and the
ignition could be damaged.
Ignition switch

11 52007 FJ CRUISER from Oct. ’06Prod. (OM35873U)
Your automatic transmission has a shift
lock system to minimize the possibility of
incorrect operation. This means you can
only shift out of “P” position when the
brake pedal is depressed (with the ignition
switch in “ON” position).
(a) Selector lever
The shift position is also displayed on the
instrument cluster.
P:Parking, engine starting and key
removal
R: Reverse
N: Neutral
D: Normal driving
(shifting into overdrive possible)
4: Engine braking
(shifting into overdrive not possible)
3, 2: Stronger engine braking
L: Maximum engine braking
Automatic transmission
TS17002a
With the brake pedal depressed
(The ignition switch must be in
“ON” position.)
Shift normally

11 62007 FJ CRUISER from Oct. ’06Prod. (OM35873U)
(b) Normal driving1. Start the engine as instructed in “How to start the engine” on page 232 in
Section 3. The transmission must be in
“P” or “N”.
Four −wheel drive models—
When the four −wheel drive control lever is
in “L4” (low −speed position, four −wheel
drive), the driving pattern selector setting
has no effect on gear shift timing. (See
“Four −wheel drive system (part −time four −
wheel drive models)” on page 120 in this
Section for information of the four −wheel
drive control lever.)
2. With your foot holding down the brake pedal, shift the selector lever to “D”.
When the lever is in the “D” position, the
automatic transmission system will select
the most suitable gear for running condi-
tions such as normal cruising, hill climb-
ing, hard towing, etc.
Tw o −wheel drive models—
Always use the “D” position for better fuel
economy and quieter driving. If the engine
coolant temperature is low, the transmis-
sion will not shift into the overdrive gear
even in the “D” position. Four
−wheel drive models—
Always use the “D” position for better fuel
economy and quieter driving. If the engine
coolant temperature is low or when the
four −wheel drive control lever is in “L4”
(low −speed position, four −wheel drive), the
transmission will not shift into the over-
drive gear even in the “D” position. (See
“Four −wheel drive system (part −time four −
wheel drive models)” on page 122 in this
Section for information of the four −wheel
drive control lever.)
CAUTION
Never put your foot on the accelera-
tor pedal while shifting.
3. Release the parking brake and brake
pedal. Depress the accelerator pedal
slowly for smooth starting.
In normal cruising, the vehicle will start in
first gear and automatically shift up to the
most suitable gear. On inclines, declines
or winding roads, etc., the vehicle shifts
up and down automatically according to
the running conditions to obtain the suit-
able driving power and engine braking. If you need to accelerate rapidly while
driving, depress the accelerator pedal to
the full throttle position. This provides
more acceleration by automatically down-
shifting the transmission to the next lower
gear or beyond, depending on the vehicle
speed.
If engine braking is needed, such as in
descending a long h
ill, see “(c) Using
engine braking”.
AI (Artificial Intelligence) shifting control
AI shifting control selects the most suit-
able shift range automatically according to
the driver ’s operation and driving condi-
tion.
AI shifting control operates automatically
with the selector lever in the “D” position.
Shifting control on the slope: On inclines,
you can drive smoothly with reduced shift-
ing quantity. On declines, the vehicle will
shift down automatically to obtain optimum
engine braking and reduce the driver ’s
foot braking load.
Automatic shifting point change control:
The automatic shifting point control is con-
trolled in the following way to respond to
the driver ’s operation.

11 72007 FJ CRUISER from Oct. ’06Prod. (OM35873U)
When the accelerator is depressed
quickly, the vehicle downshifts rapidly
in order to improve acceleration.
When the accelerator is quickly re-
leased, the gear position is maintained
in order to improve engine braking and
reacceleration capabilities.
During hard deceleration the vehicle
downshifts rapidly in order to improve
engine braking and reacceleration capa-
bilities.
(c) Using engine braking
To use engine braking, you can downshift
the transmission as follows:
Shift into the “4” position. The trans-
mission will downshift to fourth gear
and engine braking will be enabled.
Shift into the “3” position. The trans-
mission will downshift to third gear
when the vehicle speed drops down to
or lower than the following speed, and
stronger engine braking will be en-
abled. Tw o −wheel drive models
140 km/h (87 mph)
Four −wheel drive models
Four −wheel drive control lever at
“H2” and “H4”
140 km/h (87 mph) Four
−wheel drive control lever at
“L4” 54 km/h (34 mph)
Shift into the “2” position. The trans-
mission will downshift to second gear
when the vehicle speed drops down to
or lower than the following speed, and
stronger engine braking will be en-
abled.
Tw o −wheel drive models
93 km/h (58 mph)
Four −wheel drive models
Four −wheel drive control lever at
“H2” and “H4” 93 km/h (58 mph)
Four −wheel drive control lever at
“L4” 36 km/h (22 mph)
Shift into the “L” position. The trans-
mission will downshift to first gear
when the vehicle speed drops down to
or lower than the following speed, and
maximum engine braking will be en-
abled.
Tw o −wheel drive models
41 km/h (25 mph) Four
−wheel drive models
Four −wheel drive control lever at
“H2” and “H4”
41 km/h (25 mph)
Four −wheel drive control lever at
“L4” 15 km/h (9 mph)
Vehicles with cruise control—When the
cruise control is being used, even if you
downshift from “D” to “4”, engine braking
will not be enabled because the cruise
control is not cancelled.
For ways to decrease the vehicle speed,
see “Cruise control” on page 135 in this
Section.
CAUTION
Be careful when downshifting on a
slippery surface. Abrupt shifting
could cause the vehicle to skid or
spin.
(d) Using “3”, “2” and “L” positions
The “3”, “2” and “L” positions are used for
strong engine braking as described pre-
viously.

11 82007 FJ CRUISER from Oct. ’06Prod. (OM35873U)
With the selector lever in “3” or “2”, the
vehicle will start in first gear and automat-
ically shift to third gear or second gear.
With the selector lever in “L”, the trans-
mission is engaged in first gear.
NOTICE
Be careful not to overrev the en-
gine. Watch the tachometer to keep
engine rpm from going into the red
zone. The approximate maximum al-
lowable speed for each position is
given below for your reference:
Twowheel drive models
“3” 148 km/h (92 mph) . . . . . . .
“2” 101 km/h (63 mph) . . . . . . .
“L” 58 km/h (36 mph) . . . . . . . .
Fourwheel drive models
Fourwheel drive control lever
at “H2” or “H4”“3” 148 km/h (92 mph) . . . . . . .
“2” 101 km/h (63 mph) . . . . . . .
“L” 58 km/h (36 mph) . . . . . . . .
Fourwheel drive control lever
at “L4” “3” 56 km/h (35 mph) . . . . . . . .
“2” 38 km/h (24 mph) . . . . . . . .
“L” 22 km/h (14 mph) . . . . . . . .
Do not continue hill climbing or
hard towing for a long time in the
“3”, “2” or “L” position. This may
cause severe automatic transmis-
sion damage from overheating. To
prevent such damage, “4” position
should be used in hill climbing or
hard towing.
(e) Backing up
1. Bring the vehicle to a complete stop.
2. With the brake pedal held down with your foot, shift the selector lever to the
“R” position.
NOTICE
Never shift into reverse while the ve-
hicle is moving.
(f) Parking
1. Bring the vehicle to a complete stop.
2. With the brake pedal pressed down, fully depress the parking brake pedal
to apply the parking brake securely.
3. With the brake pedal pressed down, shift the selector lever to the “P” posi-
tion.
CAUTION
Never attempt to move the selector
lever into “P” position under any cir-
cumstances while the vehicle is mov-
ing. Serious mechanical damage and
loss of vehicle control may result.
(g) Good driving practice
If the transmission repeatedly shifts up
and down between fourth gear and
overdrive when climbing a gentle slope,
shift the selector lever to the “4” posi-
tion. Be sure to shift the selector lever
to the “D” position immediately after-
ward.
When towing a trailer, in order to main-
tain engine braking efficiency, do not
use “D” position.
CAUTION
Always keep your foot on the brake
pedal while stopped with the engine
running. This prevents the vehicle
from creeping.
