Page 14 of 428
’07Camry_U (L/O 0608)
6
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
Ty p e A
LN11008
Ty p e B
1. Audio remote control switches
2. Climate remote control switches
3. Multi−information display control switch
4. Cruise control switch
5. Speech command switch
6. Telephone switches
Without moon roof
With moon roof
Steering switches and
overhead console overview
Steering switchesOverhead console
Page 16 of 428
’07Camry_U (L/O 0608)
8
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
LN11061
1. Engine coolant temperature gauge
2. Service reminder indicators and
indicator lights
3. Tachometer4. Automatic transmission shift position
indicator lights
5. Speedometer
6. Fuel gauge7. Trip meter reset knob/instrument panel
light control knob
8. Odometer and two trip meters and
outside temperature display
9. Automatic transmission shift range
display
Instrument cluster overview
Without multi information display
Page 17 of 428
’07Camry_U (L/O 0608)
9
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
LN11062
1. Engine coolant temperature gauge
2. Service reminder indicators and
indicator lights
3. Tachometer4. Automatic transmission shift position
indicator lights
5. Speedometer
6. Fuel gauge7. Trip meter reset knob/instrument panel
light control knob
8. Multi−information display
9. Automatic transmission shift range
display With multi information display
Page 47 of 428

’07Camry_U (L/O 0608)
39
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
SELECTING DOORS TO BE UNLOCKED
WITH ENTRY FUNCTION
The unlocking operation has 2 modes.
To change the mode, within 1 m (3 ft.)
of the vehicle press the lock switch and
the alarm, trunk opener or unlock
switch simultaneously for five seconds.
The ignition must be turned off.
When the mode is changed, the buzzer
will sound and an indicator is displayed on
the multi−information display as follows:Mode
Door to be
unlocked
Wireless
remote
control
buzzerIndicator
and meter
buzzer
1All doors2 beeps
1 beep
2
Driver ’s
door only
(from
driver ’s
door
switch)
All doors
(from front
passenger ’
s door
switch)
3 beeps
1 beep
Repeating the above process allows you
to toggle between 1 and 2.
Move the lock knob.
To lock: Push the knob forward.
To unlock: Pull the knob backward.
The front doors can be opened by pulling
the inside handle even if the lock knobs
are in the locked position.
CAUTION
Do not pull the inside handle of the
front doors while driving. The doors
will open and an accident may occur.
Toyota strongly recommends that all
children be placed in the rear seat of
the vehicle.
—Locking and unlocking with
inside lock knob
Page 139 of 428
’07Camry_U (L/O 0608)
131
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Gauges, Meters and Service reminder indicators
Fuel gauge132 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine coolant temperature gauge132 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer133 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer and two trip meters134 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside temperature display134 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Multi−information display135 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service reminder indicators and warning buzzers146 . . . . . . . . . . . . . .
SECTION 1 6
Page 142 of 428

’07Camry_U (L/O 0608)
134
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
This meter displays the odometer and
two trip meters when the ignition
switch is on.
1. Odometer—Shows the total distance
the vehicle has been driven.
2. Two trip meters—Show two different
distances independently driven since
the last time each trip meter was set
to zero.
You can use one trip meter to calculate
the fuel economy and the other to
measure the distance on each trip. All
trip meter data is cancelled if the elec-
trical power source is disconnected.3. Trip meter reset knob—Resets the two
trip meters to zero, and also change
the meter display.
To change the meter display, quickly
push and release the knob. The meter
display changes in the order from the
odometer to trip meter A to trip meter
B, then back to the odometer each
time you push.
To reset the trip meter A to zero, dis-
play the meter A reading, then push
and hold the knob until the meter is
set to zero. The same process can be
applied for resetting the trip meter B.The displayed temperature ranges from
−40C (−40F) up to 50C (122F).
The ignition switch must be set at ON.
If an abnormality exists in the connection
of the outside air temperature sensor, “−−”
or “E” will appear on the display. If “−−”
or “E” appears on the display, contact
your Toyota dealer.
There may be a case that “−−” appears
momentarily when the ignition switch is
quickly set to ON. It is normal if it goes
out soon.
Odometer and two trip meters Outside temperature display
