2007 TOYOTA AVALON Owners Manual

257
Refer to HomeLink on the internet at:
WWW.HOMELINK.COM
CAUTION
When programming the HomeLink
Universal Transceiver, you may be
operating a garage door or other
device. Make sure people and ob-
jects are out of the way of the ga-
rage door or other device to pre-
vent potential harm or damage.
Do not use this HomeLink Univer-
sal Transceiver with any garage
door opener that lacks the safety
stop and reverse feature as re-
quired by federal safety standards.
(This includes any garage door
opener model manufactured before
April 1, 1982.) A garage door open-
er which cannot detect an object
(signaling the door to stop and re-
verse), does not meet current feder-
al safety standards. Using a garage
door opener without these features
increases risk of serious injury or
death.
This device complies with Part 15 of the
FCC Rules and with RSS −210 of the IC
Rules. Operation is subject to the fol-
lowing two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence that may be received, including
interference that may cause undersired
operation.
WARNING: This transmitter has been
tested and complies with FCC and IC
rules. Changes or modifications not
expressly approved by the party re-
sponsible for compliance could void
the user’s authority to operate the
device.
To use the glove box:
Open by pulling the lever.
Lock by inserting the master key (vehicles
with key cylinder −type ignition switch) or
mechanical key (vehicles with smart key
system) and turning it clockwise.
Unlock by inserting the master key (ve-
hicles with key cylinder −type ignition
switch) or mechanical key (vehicles with
smart key system) and turning it counter-
clockwise.
With the instrument panel lights on, the
glove box light will come on when the
glove box is open.
Glove box

258
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the glove box door
closed while driving.
To use the auxiliary boxes, open the
lids as shown in the following illustra-
tions.
CAUTION
To reduce the chance of injury in
case of an accident or sudden stop,
always keep the auxiliary box
closed while driving.
Type A—It is designed for holding
a light objects, do not place any
heavy objects in it. Heavy objects
may cause the holder to open and
contents to fly out resulting in inju-
ries.
NOTICE
Type A—During hot weather, the inte-
rior of the vehicle becomes very hot.
Do not leave anything flammable or
deformable such as a lighter, glasses,
etc. inside.
Type A (ceiling)
Type B (front console)
Auxiliary boxes

259
Type C (door panel)
Type D (center console)
Type E (rear seat)To access the rear console box, pull up
the lock release lever while raising the
rear console box lid.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the console box closed
while driving.
Rear console box

260
It is possible to use the rear console
box lid as an armrest by moving it as
shown in the illustration.
When using the console box, return the lid
to its original position.Type A (center console)
Type B (rear armrest)Type C (rear armrest)
C u p ho ld ers

261
The cup holders are designed for hold-
ing cups or drinkcans securely.
To use the cup holder, do the following.
Type A—Push on the lid.
Type B—Pull down the rear armrest.
Type C—Pull down the rear armrest and
open the lid on the armrest.
CAUTION
Do not place anything else other
than cups or drinkcans on the cup
holder, as such items may be
thrown about in the compartment
and possibly injure people in the
vehicle during sudden braking or in
an accident.
To reduce the chance of injury in
case of an accident or sudden stop
while driving, keep the cup holder
closed when it is not in use.
To raise the rear electric sunshade,
push the switch. To lower the sun-
shade, push the switch again.
The sunshade works when the ignition
switch is set at ON.
When the selector lever is shifted into
the “R” position while the sunshade is
raised, the sunshade will be automati-
cally lowered. To raise the sunshade,
move the selector lever out of “R”
position and push the switch.
CAUTION
Do not touch the brackets fastening
the sunshade to avoid injuring your
fingers or hands.
Do not put your fingers in the sun-
shade groove while the sunshade is
operating to avoid getting them
caught or injured by the runner.
Rear electric sunshade

262
NOTICE
To prevent the vehicle battery from
being discharged, always operate
the sunshade while the engine is
running.
 Observe the following to avoid dam-
age and/or malfunction:
Do not overload the sunshade mo-
tor and other parts (for instance by
pushing down on the sunshade
bracket while it is opening).
Do not place anything where they
may hinder the opening/closing of
the sunshade.
Do not affix anything to the sun-
shade.
Clean the sunshade groove if there
is any foreign matter or dust on it.
Do not operate the rear electric
sunshade repeatedly for a long time
as its motor may overheat.
This box is designed to hold things like
bottles.This hook is designed to hang things
like grocery bags.
NOTICE
To prevent damage to the hook, avoid
hanging heavy loads on it.
Storage box Grocery bag hooks

263
To secure belongings, hang the cargo
net on the hooks.
NOTICE
Do not use the net to secure sharp
or heavy objects. The net will tear
off.
 Be sure not to twist the net when
hooking.
Use a floor mat of the correct size.
If the vehicle carpet and floor mat have
2 holes, then they are designed for use
with 2 locking clips. Attach the floor mat
to the vehicle carpet using the clips. Lock
the clips into the holes in the vehicle
carpet.CAUTION
Make sure the floor mat is properly
placed on the vehicle carpet. If the
floor mat slips and interferes with the
movement of the pedals during driv-
ing, it may cause an accident.
Cargo net Floor mat

264
