22& Trunk/cargo area
1) Jack handle (page 9-18)
2) Jack (page 9-18)
3) Spare tire (page 9-2)
ProCarManuals.com

Black plate (25,1)
北米Model "A2420BE-B" EDITED: 2006/ 7/ 26
Function settingsA SUBARU dealer can change the settings of the functions shown in the following table to meet your personal requirements. Contact
the nearest SUBARU dealer for details. If your vehicle is equipped with navigation system, the settings for some of these functions can
be changed using the monitor. For details, please refer to the Owner ’s Manual supplement for the monitor.Item Function Possible settingsDefault settingPage
Alarm system Alarm system Operation / Non-operation Operation 2-14
Monitoring start delay time (after
closure of doors) 0 second / 30 seconds 30 seconds
2-16
Impact sensor operation (only vehi-
cles with shock sensors (dealer
option)) Operation / Non-operation Non-operation
2-19
Passive arming Operation / Non-operation Non-operation 2-17
Remote keyless entry system Hazard warning flasher Operation / Non-operation Operation2-8
Audible signal Operation / Non-operation Operation 2-10
Key lock-in prevention Key lock-in prevention Operation / Non-operation Operation2-7
Remote engine start system
(dealer option) Horn chirp confirmation
ON/OFFON7-11
Rear window defogger Rear window defogger Operation for 15 minutes / Con-
tinuous operation Operation for 15 minutes 3-47
Windshield wiper deicer (if
equipped) Windshield wiper deicer
Operation for 15 minutes / Con-
tinuous operation Operation for 15 minutes 3-46
Dome light Operation in interlock with remote
keyless entry system OFF / Short / Normal / Long Normal
6-2
Battery drainage prevention
function Battery drainage prevention function Operation / Non-operation Operation
2-6
23
0
ProCarManuals.com

Black plate (2,1)
Model "ALL_MODEL_MEMO" EDITED: 2006/ 1/ 17
Left Page————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
ProCarManuals.com

Black plate (1,1)
北米Model "A2420BE-B" EDITED: 2006/ 7/ 31
Front seats ........................................................... 1-2
Manual seat ........................................................ 1-3
Power seat (if equipped) ...................................... 1-4
Memory function (Driver ’s seat only,
if equipped) ....................................................... 1-5
Head restraint adjustment .................................... 1-7
Active head restraint ........................................... 1-7
Lumbar support (if equipped) .............................. 1-8
Seat heater (if equipped).................................... 1-8
Rear seats ............................................................ 1-9
Folding down the rear seatback ........................... 1-9
Head restraint adjustment ................................... 1-10
Armrest (if equipped)......................................... 1-11
Loading long objects (Sedan) ............................. 1-12
Seatbelts............................................................. 1-13
Seatbelt safety tips ............................................. 1-13
Emergency Locking Retractor (ELR) ................... 1-14
Automatic/Emergency Locking Retractor (A/ELR) ............................................................ 1-14
Seatbelt warning light and chime ........................ 1-14
Fastening the seatbelt ........................................ 1-16
Seatbelt maintenance ......................................... 1-23
Front seatbelt pretensioners ............................. 1-24
System monitors............................................... 1-25
System servicing ............................................... 1-26
Precautions against vehicle modification ............ 1-27
Child restraint systems..................................... 1-27
Where to place a child restraint system .............. 1-28
Choosing a child restraint system ...................... 1-30
Installing child restraint systems with A/ELR seatbelt ........................................................... 1-30
Installing a booster seat ..................................... 1-33
Installation of child restraint systems by use of lower and tether anchorages (LATCH) .............. 1-35
Top tether anchorages ....................................... 1-37
*SRS airbag (Supplemental Restraint
System airbag) ................................................ 1-40
Vehicle with SRS airbags and lap/shoulder
restraints for driver, front passenger, and
window-side rear passengers . .......................... 1-40
Subaru advanced frontal airbag system .............. 1-45
SRS side airbag and SRS curtain airbag ............. 1-55
SRS airbag system monitors .............................. 1-61
SRS airbag system servicing ... .......................... 1-63
Precautions against vehicle modification ............ 1-64
Seat, seatbelt and SRS airbags
1
ProCarManuals.com

Black plate (28,1)
北米Model "A2420BE-B" EDITED: 2006/ 7/ 26
1-2
Seat, seatbelt and SRS airbags
Front seats
WARNING
. Never adjust the seat while driv-
ing to avoid the possibility of
loss of vehicle control and of
personal injury.
. Before adjusting the seat, make
sure the hands and feet of rear
seat passengers or luggage are
clear of the adjusting mechan-
ism.
. Seatbelts provide maximum re-
straint when the occupant sits
well back and upright in the seat.
To reduce the risk of sliding
under the seatbelt in a collision,
the front seatbacks should be
always used in the upright posi-
tion while the vehicle is running.
If the front seatbacks are not
used in the upright position in a
collision, the risk of sliding under
the lap belt and of the lap belt
sliding up over the abdomen will
increase, and both can result in
serious internal injury or death.
. The SRS airbags deploy with
considerable speed and force.
Occupants who are out of proper position when the SRS airbag
deploys could suffer very serious
injuries. Because the SRS airbag
needs enough space for deploy-
ment, the driver should always
sit upright and well back in the
seat as far from the steering
wheel as practical while still
maintaining full vehicle control
and the front passenger should
move the seat as far back as
possible and sit upright and well
back in the seat.
WARNING
Put children aged 12 and under in
the rear seat properly restrained at
all times. The SRS airbag deploys
with considerable speed and force
and can injure or even kill children,
especially if they are 12 years of age
and under and are not restrained or
improperly restrained. Because chil-
dren are lighter and weaker than
adults, their risk of being injured
from deployment is greater. Conse-
quently, we strongly recommend
that ALL children (including those
in child seats and those that have
outgrown child restraint devices) sit
in the REAR seat properly re-
strained at all times in a child
restraint device or in a seatbelt,
whichever is appropriate for the
child
’s age, height and weight.
Secure ALL types of child restraint
devices (including forward facing
child seat) in the REAR seats at all
times.
NEVER INSTALL A REARWARD FA-
CING CHILD SEAT IN THE FRONT
SEAT. DOING SO RISKS SERIOUS
INJURY OR DEATH TO THE CHILD
BY PLACING THE CHILD ’S HEAD
TOO CLOSE TO THE SRS AIRBAG.
ProCarManuals.com

Black plate (29,1)
北米Model "A2420BE-B" EDITED: 2006/ 7/ 26
According to accident statistics,
children are safer when properly
restrained in the rear seating posi-
tions than in the front seating posi-
tions. For instructions and
precautions concerning child re-
straint systems, see the “Child re-
straint systems ”section in this
chapter.& Manual seat! Fore and aft adjustmentPull the lever upward and slide the seat to
the desired position. Then release the
lever and move the seat back and forth to
make sure that it is securely locked into
place. !
Reclining the seatback
WARNING
To prevent the passenger from slid-
ing under the seatbelt in the event of
a collision, always put the seatback
in the upright position while the
vehicle is in motion. Also, do not
place objects such as cushions
between the passenger and the
seatback. If you do so, the risk of
sliding under the lap belt and of the
lap belt sliding up over the abdomen
will increase, and both can result in
serious internal injury or death.
Pull the reclining lever up and adjust the
seatback to the desired position. Then
release the lever and make sure the seat
is securely locked into place.
The seatback placed in a reclined position
can spring back upward with force when
released. When operating the reclining
lever to return the seatback, hold it lightly
so that it may be raised back gradually.
Seat, seatbelt and SRS airbags
1-3
–CONTINUED –
1
ProCarManuals.com

Black plate (30,1)
北米Model "A2420BE-B" EDITED: 2006/ 7/ 26
1-4
Seat, seatbelt and SRS airbags
! Seat cushion height adjustment
(driver ’s seat)The height of the seat can be adjusted by
moving the seat cushion adjustment lever
up and down.
When the lever is pushed down, the seat
is lowered.
When the lever is pulled up, the seat rises.
& Power seat (if equipped)! Fore and aft adjustmentTo adjust the seat forward or backward,
move the control switch forward or back-
ward.NOTEDuring backward-forward adjustment
of the seat, you cannot adjust the seat
cushion angle or seat height. !
Reclining the seatback
WARNING
To prevent the passenger from slid-
ing under the seatbelt in the event of
a collision, always put the seatback
in the upright position while the
vehicle is in motion. Also, do not
place objects such as cushions
between the passenger and the
seatback. If you do so, the risk of
sliding under the lap belt and of the
lap belt sliding up over the abdomen
will increase, and both can result in
serious internal injury or death.
ProCarManuals.com

Black plate (31,1)
北米Model "A2420BE-B" EDITED: 2006/ 7/ 26
To adjust the angle of the seatback, move
the control switch.
! Seat cushion angle adjustment
(Driver ’s seat only)To adjust the seat cushion angle, pull up or push down the front end of the control
switch.
!
Seat height adjustment (Driver ’s
seat only)
To adjust the seat height, pull up or push
down the rear end of the control switch.& Memory function (Driver ’s
seat only, if equipped)Two of your favorite seat positions can be
registered. Register the seat position with
button “1” or “2” and retrieve the seat
position by pressing either button.
The following seat positions can be
registered:
. Forward/backward position of the seat
. Angle of seatback .
Angle of seat cushion
. Height of seat
! Registration of seat position
WARNING
.Never adjust the seat while driv-
ing to avoid the possibility of
loss of vehicle control and of
personal injury.
. Before adjusting the seat, make
sure the hands, feet and posses-
sions of rear seat passengers are
clear of the adjusting mechan-
ism.
. Before registering the seat posi-
tion, confirm that the shift lever is
in the “P ” position (AT vehicles)
or the parking brake lever is
applied (MT vehicles).
1. Shift the shift lever in the “P”position
(AT vehicles) or apply the parking brake
(MT vehicles).
2. Adjust the seat position.
Seat, seatbelt and SRS airbags
1-5
– CONTINUED –
1
