Removing the Spare Tire
The compact spare tire is located under the
vehicle, in front of the rear bumper. SeeCompact
Spare Tire on page 463for more information
about the compact spare.
A. Rear
Convenience
Center
B. Lug wrench
C. Storage
Compartment
Cap HoleD. Hoist Shaft
E. Compact
Spare Tire
F. Retainer
G. Hoist Shaft
Assembly1. Open the storage compartment door of the
convenience center that is nearest the liftgate.
2. Move the carpet cutout that is located through
the hole of the storage compartment.
3. Attach the lug wrench into the hoist shaft.
4. Turn the lug wrench counterclockwise to lower
the spare tire to the ground. Continue turning
the wrench until the spare tire can be pulled out
from under the vehicle.
5. Tilt the retainer and slip it through the wheel
opening to remove the spare tire from the
cable.
449
ProCarManuals.com

6. Turn the wrench clockwise to raise the cable
back up after removing the spare tire.
Do not store a full-size or a at road tire under
the vehicle. SeeStoring a Flat or Spare Tire
and Tools on page 459.
To continue changing the at tire, seeRemoving
the Flat Tire and Installing the Spare Tire on
page 451.
If the spare tire will not lower, the secondary latch
could be engaged.Do the following to check the cable:
1. Check under the vehicle to see if the cable is
visible.
2. If it is not visible, seeSecondary Latch
System on page 456.
If it is visible, rst try to tighten the cable by
turning the lug wrench clockwise until you hear
two clicks or feel it skip twice. You cannot
over-tighten the cable.
3. Loosen the cable by turning the wrench
counterclockwise three or four turns.
4. If the spare tire has not lowered, tighten the
cable all the way and then loosen it at least
two times.
If the spare tire did lower to the ground,
continue with Step 5 under “Removing the
Spare Tire (Vehicles with the Rear
Convenience Center)” listed previously.
5. If you still cannot lower the spare tire to the
ground, seeSecondary Latch System on
page 456.
450
ProCarManuals.com

Removing the Flat Tire and
Installing the Spare Tire
1. Do a safety check before proceeding. See
Changing a Flat Tire on page 447for more
information.
2. If the vehicle has a wheel cover, loosen the
plastic nut caps with the wheel wrench. They
will not come off. Then, using the at end
of the wheel wrench, pry along the edge of the
cover until it comes off. Be careful; the
edges may be sharp. Do not try to remove the
cover with your bare hands.
Store the wheel cover securely in the rear of
the vehicle until you have the at tire
repaired or replaced.
If your vehicle has aluminum wheels, remove
the wheel nut caps using the wheel wrench.3. Loosen the wheel nuts — but do not remove
them — using the lug wrench. For wheels
with a wheel lock key, use the wheel lock key
between the lock nut and lug wrench. The
key is supplied in the front passenger
door pocket.
Notice:If your vehicle has wheel locks and an
impact wrench is used to remove the wheel
nuts, the lock nut or wheel lock key could be
damaged. Do not use an impact wrench to
remove the wheel nuts if your vehicle has
wheel locks.
451
ProCarManuals.com

4. To identify the appropriate jacking location, nd
the triangle (A) about 12 inches (30.5 cm) from
the front tire or (B) about 10.5 inches (27 cm)
from the rear tire.
The triangle is located near each wheel on the
vehicle’s exterior.
Notice:If a jack is used to raise the vehicle
without positioning it correctly, your vehicle
could be damaged. When raising your vehicle
on a jack, avoid contact with the rear axle
control arms.
5. Do not raise the vehicle yet. Put the compact
spare tire near you.
{CAUTION:
Getting under a vehicle when it is jacked
up is dangerous. If the vehicle slips off
the jack you could be badly injured or
killed. Never get under a vehicle when it
is supported only by a jack.
{CAUTION:
Raising your vehicle with the jack
improperly positioned can damage the
vehicle and even make the vehicle fall.
To help avoid personal injury and vehicle
damage, be sure to t the jack lift head
into the proper location before raising
the vehicle.
452
ProCarManuals.com

6. Attach the lug wrench to the jack, and turn the
wrench clockwise to raise the jack head
3 inches (7.6 cm).
7. Place the jack under the vehicle as identied
in Step 3. Raise the vehicle by turning the lug
wrench clockwise in the jack. Raise the
vehicle far enough off the ground so that there
is enough room for the spare tire to t
under the wheel well.
8. Remove all the wheel nuts and the at tire.
9. Remove the plastic spare tire heat shield by
pulling the rubber latch. Store the plastic
spare tire heat shield. SeeStoring a Flat or
Spare Tire and Tools on page 459for
more information.
453
ProCarManuals.com

{CAUTION:
Rust or dirt on the wheel, or on the parts
to which it is fastened, can make the
wheel nuts become loose after time. The
wheel could come off and cause an
accident. When changing a wheel, remove
any rust or dirt from the places where the
wheel attaches to the vehicle. In an
emergency, a cloth or a paper towel can
be used to do this; but be sure to use a
scraper or wire brush later, if needed, to
get all the rust or dirt off.
{CAUTION:
Never use oil or grease on studs or nuts.
Because the nuts might come loose. The
vehicle’s wheel could fall off, causing a
serious accident.10. Remove any rust or
dirt from the wheel
bolts, mounting
surfaces, and spare
wheel.
11. Install the compact spare tire.
12. Lower the vehicle by attaching the lug wrench
to the jack and turning the wrench
counterclockwise. Lower the jack completely.
454
ProCarManuals.com

{CAUTION:
Incorrect wheel nuts or improperly
tightened wheel nuts can cause the wheel
to come loose and even come off. This
could lead to an accident. Be sure to use
the correct wheel nuts. If you have to
replace them, be sure to get new GM
original equipment wheel nuts. Stop
somewhere as soon as you can and have
the nuts tightened with a torque wrench to
the proper torque specication. See
Capacities and Specifications on page 483
for wheel nut torque specication.Notice:Improperly tightened wheel nuts can
lead to brake pulsation and rotor damage.
To avoid expensive brake repairs, evenly
tighten the wheel nuts in the proper sequence
and to the proper torque specication. See
Capacities and Specifications on page 483for
the wheel nut torque specication.
13. Tighten the wheel
nuts rmly in a
crisscross sequence,
as shown.
Notice:Wheel covers will not t on your
vehicle’s compact spare. If you try to put a
wheel cover on the compact spare, the cover or
the spare could be damaged.
455
ProCarManuals.com

Secondary Latch System
Your vehicle has an underbody mounted tire hoist
assembly equipped with a secondary latch
system. It is designed to stop the compact spare
tire from suddenly falling off your vehicle if the
cable holding the spare tire is damaged. For the
secondary latch to work, the tire must be
stowed with the valve stem pointing down. See
Storing a Flat or Spare Tire and Tools on page 459
for instructions on storing the spare tire correctly.
{CAUTION:
Before beginning this procedure read all
the instructions. Failure to read and follow
the instructions could damage the hoist
assembly and you and others could get
hurt. Read and follow the instructions
listed next.To release the spare tire from the secondary latch,
do the following:
{CAUTION:
Someone standing too close during the
procedure could be injured by the jack. If
the spare tire does not slide off the jack
completely, make sure no one is behind
you or on either side of you as you pull
the jack out from the under spare.
1. If the cable is not visible, start this procedure
at Step 3.
