2007 Peugeot Partner VU Owner's Manual

Special features
THE ALARM SYSTEM*
The alarm offers two types of protec-
tion:
- exterior protection: the alarm
sounds if a door, the boot or the
bonnet is opened;
- interior protection : the alarm
sounds if there is
a variation in
the volume inside the vehicle
(breaking of a window or
movement inside the vehicle).
Setting the alarm
Switch the ignition off and get out of
the vehicle.
Activate the alarm within five minutes
following your exit from the vehicle,
by locking using the remote control
key (the red indicator light on the
switch 1, which can be seen from the
outside, flashes once a second). When the alarm is triggered, the si-
ren sounds and the direction indica-
tors flash for thirty seconds.
After it has been triggered, the alarm
becomes operational again.
Note:
if you wish to lock your vehicle
without setting the alarm, lock it us-
ing the key in the door lock.
Warning
If, on setting the alarm, a door, the
boot or the bonnet are not closed
correctly, the siren sounds for a mo-
ment.
Close the vehicle correctly to set the
alarm.
If the interior protection alarm is trig-
gered ten times in succession, it is
disarmed automatically. It must be
set again in order for it to operate
correctly. Note:
when the alarm is set, but the
remote control no longer works:
 unlock the doors using the key
and open the door; the alarm is
triggered;
 switch the ignition on within ten
seconds; the alarm is disarmed.
Disarming the alarm
Unlock the vehicle using the remote
control key (the red indicator light on
the switch 1 goes out).
Note: if the warning light flashes, it is
a sign that the alarm has been trig-
gered in your absence.
To stop it, switch on the ignition.
* According to country.
To set the alarm with exterior
protection only.
If, while you are away from the vehi-
cle, you wish to leave a window par-
tially open or a pet inside the vehicle,
you need to select exterior protection
only:
• Switch off the ignition.
• Press the button 2 until the light 1
comes on continuously.
• Get out of the vehicle.
• Press the locking button of the
remote control.
• The doors lock.
• The red light on the switch flashes
once a second.
Malfunction
When the ignition is switched on,
fixed lighting of the red indicator light,
located in the centre of the fascia, in-
dicates a siren connection fault.
Contact a PEUGEOT dealer to have
the system checked.
Do not make any modifica-
tions to the alarm system, this
could cause malfunctions.
114 -

57
-Access and starting
FRONT DOORS AND SLIDING
SIDE DOORS
Front doors
Side doors Front doors Side doors
The driver’s door opening control
permits complete unlocking of the
vehicle.
Locking/Unlocking from the
inside
Front doors
To lock, lower button
A.
The closing control of one of the front
doors permits complete locking of
the vehicle.
To unlock and open, lift button A and
pull the handle towards you.
The driver’s door opening control
permits complete unlocking of the
vehicle.
Opening the doors from inside
Opening the doors from outside
Sliding side doors
The side door opening/closing control
only controls the door concerned.
To close, push the control B forwards
and slide the door.
To open, pull the control B rearwards
and slide the door.
If the fuel tank cap is removed,
the right-hand side door can-
not be opened.

58 -Access and starting
Locking from the inside
Lower or raise control C to lock or un-
lock from the inside. Locking from the inside
Pressing control
D operates the
central locking, when the doors are
closed. Automatic central locking
Your vehicle can lock automatically
while driving (speed greater than 6 mph
(10 km/h)). You can activate or deacti-
vate this function.
Unlocking from the inside
Press control D.
It is still possible to open the doors
from the inside. Activation
Press and hold control
D.
Activation of the function is accompa-
nied by an audible signal and a mes-
sage on the multifunction display.
Deactivation
Press and hold control D.
Deactivation of the function is
accompanied by an audible signal.
Notes:
- doors locked and ignition off: the indicator light flashes,
- doors locked and ignition on: the indicator light remains on.

59
-Access and starting
LOCKING/UNLOCKING THE
TAILGATE
To open the tailgate, operate the
handle A and lift it.
You can unlock the tailgate by inserting
the key in the lock B.
REAR DOORS
Opening the doors from outside
To open, pull the rear right door han-
dle C towards you and open the rear
left door by pulling the lever D on the
inside.
You can unlock the rear doors by
inserting the key in the lock E.

59
-Access and starting
LOCKING/UNLOCKING THE
TAILGATE
To open the tailgate, operate the
handle A and lift it.
You can unlock the tailgate by inserting
the key in the lock B.
REAR DOORS
Opening the doors from outside
To open, pull the rear right door han-
dle C towards you and open the rear
left door by pulling the lever D on the
inside.
You can unlock the rear doors by
inserting the key in the lock E.

60 -Access and starting
Opening the doors from inside
The rear door opening controls only
unlock these doors.To open, lift lever
A.
To open the other door, push lever B.
Note: when closing from the inside,
close the right-hand door first ensur-
ing that lever B is in the vertical posi-
tion then close the left-hand door. Opening the rear doors to 180°
To open the rear doors to 180°, re-
lease the check strap
C towards you
when the door is partially open.
When closing the door, the check
strap hooks itself in place again au-
tomatically.

61
-Access and starting
Notes:
The side openings D can be used as
hooking points.
The rear bumper has been strength-
ened to serve as a footrest on entering
the vehicle.LONG LOAD SUPPORT BAR
A support bar is provided for trans-
porting long loads, after opening the
rear roof flap.
Fold back the support bar by lifting
the lever C.
Support it to the door pillar.
Support the long loads to be trans-
ported.
Reposition the support bar with one
hand.
Ensure that it is secured correctly.
REAR ROOF FLAP
To open the rear flap:
- pull the lever A,
- lift the rear flap,
- pass the point of resistance to secure it using the support
struts B.
To close the rear flap:
- check that the support bar is secured correctly,
- lower the rear flap to lock it. Never drive without the sup-
port bar in place.
The rear doors only lock when
the support bar is installed.
When the rear roof flap is open, take
care when driving where height is re-
stricted.
Use a regulation device when a load
protrudes from your vehicle by more
than one metre.
Never rest a load directly on the rear
doors.

62 -Access and starting
OPENING THE BONNET
Inside the vehicle : pull the handle on
the left-hand side, under the fascia.
Outside the vehicle : lift the catch
and raise the bonnet.
BONNET STRUT
Secure the strut to hold the bonnet
open. Before closing the bonnet, re-
place the strut in its housing.
FILLING WITH FUEL
Low fuel level
When the minimum
fuel level in the tank is
reached, this warning
light comes on.
You have enough fuel remaining
to drive for approximately 30 miles
(50 km).
The engine must be switched off
when filling with fuel.
 Insert the key then turn it to the left.
 Remove the cap.
When the cap is removed,
the right-hand sliding side
door cannot be opened.
The key cannot be removed
from the lock until the cap
has been replaced on the
fuel tank.
An indication reminds you which type
of fuel to use.
When you fill your tank, do not con-
tinue after the third cut-off of the
pump. This could cause your vehicle
to malfunction.
The capacity of the tank is approxi-
mately 55 litres for petrol engines
and 60 litres for Diesel engines.

After filling the tank, lock the cap.
To close
Lower the bonnet and release it at
the end of its travel. Check that the
bonnet is locked.
