Page 1399 of 5883
EC-50
< FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
ELECTRIC IGNITION SYSTEM
1. ECM harness connectors 2. ECM 3. IPDM E/R
4. Fuel pump fuse (15A) 5. Intake valve timing control solenoid
valve6. Knock sensor
7. Refrigerant pressure sensor 8. PCV valve
Vehicle front
PBIB2941E
Page 1406 of 5883
AIR CONDITIONING CUT CONTROL
EC-57
< FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
1. ECM harness connectors 2. ECM 3. IPDM E/R
4. Fuel pump fuse (15A) 5. Intake valve timing control solenoid
valve6. Knock sensor
7. Refrigerant pressure sensor 8. PCV valve
Vehicle front
PBIB2941E
Page 1414 of 5883
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
EC-65
< FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
1. ECM harness connectors 2. ECM 3. IPDM E/R
4. Fuel pump fuse (15A) 5. Intake valve timing control solenoid
valve6. Knock sensor
7. Refrigerant pressure sensor 8. PCV valve
Vehicle front
PBIB2941E
Page 1423 of 5883
EC-74
< FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
COOLING FAN CONTROL
1. ECM harness connectors 2. ECM 3. IPDM E/R
4. Fuel pump fuse (15A) 5. Intake valve timing control solenoid
valve6. Knock sensor
7. Refrigerant pressure sensor 8. PCV valve
Vehicle front
PBIB2941E
Page 1432 of 5883
EVAPORATIVE EMISSION SYSTEM
EC-83
< FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
1. ECM harness connectors 2. ECM 3. IPDM E/R
4. Fuel pump fuse (15A) 5. Intake valve timing control solenoid
valve6. Knock sensor
7. Refrigerant pressure sensor 8. PCV valve
Vehicle front
PBIB2941E
Page 1439 of 5883
EC-90
< FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
INTAKE VALVE TIMING CONTROL
1. ECM harness connectors 2. ECM 3. IPDM E/R
4. Fuel pump fuse (15A) 5. Intake valve timing control solenoid
valve6. Knock sensor
7. Refrigerant pressure sensor 8. PCV valve
Vehicle front
PBIB2941E
Page 1473 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EC-124
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000001670889
1.INSPECTION START
Start engine.
Is en NISSAN TIIDA 2007 Service Repair Manual EC-124
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000001670889
1.INSPECTION START
Start engine.
Is en](/manual-img/5/57395/w960_57395-1472.png)
EC-124
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000001670889
1.INSPECTION START
Start engine.
Is engine running?
YES >> GO TO 8.
NO >> GO TO 2.
2.CHECK GROUND CONNECTION-I
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground Inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace ground connection.
3.CHECK ECM POWER SUPPLY CIRCUIT-I
1. Turn ignition switch OFF and then ON.
2. Check the voltage between ECM harness connector terminals as follows.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
4.DETECT MALFUNCTIONING PART
Check the following.
10A fuse (No. 55)
Harness for open or short between ECM and fuse
>> Repair open circuit or short to ground or short to power in harness or connectors.
5.CHECK ECM GROUND CIRCUIT FOR OPEN AND SHORT-I
1. Disconnect ECM harness connectors.
2. Check the continuity between ECM harness connector and ground.
3. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 6.
6.DETECT MALFUNCTIONING PART
Check the following.
(+) (–)
Vo l ta g e
Connector Terminal Connector Terminal
E16 93F1010
Battery voltage 11
E16 108
ECM
Ground Continuity
Connector Terminal
F1010
Ground Existed 11
E16 108
Page 1475 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EC-126
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
POWER SUPPLY AND GROUND CIRCUIT
NO >> Repair open circuit or short to power in harness or connectors.
11 .CHECK ECM POWER SUPPLY CIRCUIT-VI
1. Di NISSAN TIIDA 2007 Service Repair Manual EC-126
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
POWER SUPPLY AND GROUND CIRCUIT
NO >> Repair open circuit or short to power in harness or connectors.
11 .CHECK ECM POWER SUPPLY CIRCUIT-VI
1. Di](/manual-img/5/57395/w960_57395-1474.png)
EC-126
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
POWER SUPPLY AND GROUND CIRCUIT
NO >> Repair open circuit or short to power in harness or connectors.
11 .CHECK ECM POWER SUPPLY CIRCUIT-VI
1. Disconnect ECM harness connector.
2. Disconnect IPDM E/R harness connector .
3. Check the continuity between ECM harness connector and IPDM E/R harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 13.
NO >> GO TO 12.
12.DETECT MALFUNCTIONING PART
Check the following.
Junction block connectors E8, F8
Harness for open or short between ECM and IPDM E/R
>> Repair open circuit or short to ground or short to power in harness or connectors.
13.CHECK 20A FUSE
1. Disconnect 20A fuse (No. 53) from IPDM E/R.
2. Check 20A fuse.
Is the inspection result normal?
YES >> GO TO 17.
NO >> Replace 20A fuse.
14.CHECK GROUND CONNECTION-II
1. Turn ignition switch OFF.
2. Check ground connection E15, E24. Refer to Ground Inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 15.
NO >> Repair or replace ground connection.
15.CHECK ECM GROUND CIRCUIT FOR OPEN AND SHORT-II
1. Disconnect ECM harness connector.
2. Check the continuity between ECM harness connector and ground.
3. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 17.
NO >> GO TO 16.
16.DETECT MALFUNCTIONING PART
Check the following.
Harness or connectors F8, E8
Harness for open or short between ECM and ground
ECM IPDM E/R
Continuity
Connector Terminal Connector Terminal
F10 32 E43 7 Existed
ECM
Ground Continuity
Connector Terminal
F1010
Ground Existed 11
E16 108
