Lumbar support (if so equipped for
driver’s seat)The lumbar support feature provides lower back
support to the driver. Push each side of the
switch to adjust the seat lumbar area.
REAR SEAT ADJUSTMENT
Folding1. Secure the seat belt at the belt hooks on the
side wall. See “Seat belt hook” later in this
section.
2. Secure the center seat belt and tongues into
the retractor base. See “Stowing rear center
seat belt” later in this section.
3. Put the seat belt buckles into the seat cush-
ion.
See “Storing rear seat belt buckles” later in
this section.4. Remove the head restraints. See “Head re-
straint adjustment” later in this section.
5. Remove any cups from the rear cup holder
and make sure the rear cup holder is empty.
6. Close the tonneau subcover (if so equipped)
from each rear seatback.
7. Pull the strap on the rear seat
A
or pull the
lever
B
beside the cargo area and fold the
seatback.
8. When returning the seatbacks, be sure to
install the head restraints and attach the rear
center seat belt connector.
WARNING
Never allow anyone to ride in the
cargo area or on the rear seat when it
is in the fold-down position. Use of
these areas by passengers without
proper restraints could result in seri-
ous injury in an accident or sudden
stop.
It is extremely dangerous to ride in a
cargo area inside of a vehicle. In a
collision, people riding in these areas
SSS0280
SSS0569
Safety — seats, seat belts and supplemental restraint system
1-5
06.7.5/Z50-D/V5.0
WARNING
The spare tire should be used for
emergency use only. It should be re-
placed with the standard tire at the
first opportunity to avoid possible
tire or differential damage.
Drive carefully while the TEMPO-
RARY USE ONLY spare tire is in-
stalled. Avoid sharp turns and abrupt
braking while driving.
Periodically check spare tire inflation
pressure. Always keep the pressure
of the TEMPORARY USE ONLY spare
tire at 60 psi (420 kPa, 4.2 bar).
With the TEMPORARY USE ONLY
spare tire installed do not drive the
vehicle at speeds faster than 50 MPH
(80 km/h).
When driving on roads covered with
snow or ice, the TEMPORARY USE
ONLY spare tire should be used on
the rear wheel and the original tire
used on the front wheels (drivewheels). Use tire chains only on the
front (original) tires.
Tire tread of the TEMPORARY USE
ONLY spare tire will wear at a faster
rate than the standard tire. Replace
the spare tire as soon as the tread
wear indicators appear.
Do not use the spare tire on other
vehicles.
Do not use more than one spare tire
at the same time.
Do not tow a trailer when the TEM-
PORARY USE ONLY spare tire is in-
stalled.
CAUTION
Do not use tire chains on a TEMPO-
RARY USE ONLY spare tire. Tire
chains will not fit properly and may
cause damage to the vehicle.
Because the TEMPORARY USE
ONLY spare tire is smaller than theoriginal tire, ground clearance is re-
duced. To avoid damage to the ve-
hicle, do not drive over obstacles.
Also, do not drive the vehicle through
an automatic car wash since it may
get caught.
Maintenance and do-it-yourself
8-41
06.7.5/Z50-D/V5.0
