2 Instruments and controlsInstrument panel ..................................................................... 2-2
Meters and gauges ............................................................... 2-3
Speedometer and odometer ......................................... 2-4
Tachometer ........................................................................ 2-4
Engine coolant temperature gauge ............................. 2-5
Fuel gauge ......................................................................... 2-5
Compass display (if so equipped) .................................... 2-6
Warning/indicator lights and audible reminders ............ 2-9
Checking bulbs................................................................. 2-9
Warning lights ................................................................... 2-9
Indicator lights ................................................................ 2-14
Audible reminders.......................................................... 2-16
Security systems.................................................................. 2-17
Vehicle security system (if so equipped) ................ 2-17
NISSAN Vehicle Immobilizer System ....................... 2-18
Windshield wiper and washer switch ........................... 2-20
Rear window wiper and washer switch ....................... 2-21
Rear window and outside mirror defroster switch...... 2-22
Headlight and turn signal switch ................................... 2-22
Xenon headlights (if so equipped) .......................... 2-22
Headlight switch ........................................................... 2-23
Daytime running light system (Canada only) ........ 2-25
Instrument brightness control ..................................... 2-26
Turn signal switch ........................................................ 2-27Fog light switch (if so equipped) .............................. 2-27
Hazard warning flasher switch ......................................... 2-27
Horn ........................................................................................ 2-28
Heated seats (if so equipped) ......................................... 2-28
Vehicle Dynamic Control (VDC) OFF switch (if so
equipped) .............................................................................. 2-29
Power outlet.......................................................................... 2-30
Storage .................................................................................. 2-31
Coin box........................................................................... 2-31
Cellular phone holder ................................................... 2-31
Cup holders .................................................................... 2-32
Glove box ........................................................................ 2-33
Console box .................................................................... 2-34
Door pockets .................................................................. 2-36
Cargo net (if so equipped) ......................................... 2-36
Tonneau cover (if so equipped)................................. 2-37
Windows................................................................................ 2-38
Power windows.............................................................. 2-38
Sunroof (if so equipped) ................................................... 2-40
Automatic sunroof ......................................................... 2-40
Interior lights ......................................................................... 2-42
Ceiling light ..................................................................... 2-42
Map light .......................................................................... 2-43
Rear personal light ........................................................ 2-43


06.7.5/Z50-D/V5.0


1. Headlight, fog light* and turn signal switch
2. Trip odometer reset button
3. Instrument brightness control switch
4. Meters/gauges
5. Windshield/rear window wiper and washer
switch
6. Hazard warning flasher switch
7. Center ventilator
8. Audio control
9. Display/clock
10. Rear window defroster and Heated outside
mirror* switch
11. Display screen control and/or Navigation
system*1
12. Passenger supplemental air bag
13. Side ventilator
14. Headlight aiming control switch*
15. Vehicle Dynamic Control (VDC) OFF
switch* or Headlight aiming control*
16. Steering switch for audio control*
17. Fuse box cover
18. Tilting steering wheel lock lever
19. Driver supplemental air bag/Horn
20. Cruise control main/set switch
21. Ignition switch/steering lock
22. Heater/air conditioner control
23. Coin box
24. Outside mirror remote control
25. Cellular phone holder
26. AWD lock switch (AWD models)
27. Heated seat switch*
28. Power outlet cover
29. Glove box
*: if so equipped
SSI0176
INSTRUMENT PANEL2-2
Instruments and controls


06.7.5/Z50-D/V5.0


Zone variation change procedureThe difference between magnetic north and
geographical north is known as variance. In
some areas, this difference can sometimes be
great enough to cause false compass readings.
Follow these instructions to set the variance for
your particular location if this happens:
1. Push the compass switch for more than 3
seconds. The current zone number will ap-
pear in the display.
2. Find your current location and variance one
number on the zone map.
3. Push the compass switch until the new zone
number appears in the display. After you stop
pushing the switch in, the display will show a
compass direction within a few seconds.
Inaccurate compass direction:
1. With the display turned on, push the com-
pass switch for 3 seconds, until the zone
selection comes up (a number will be dis-
played in the mirror compass window).
2. Toggle until correct zone is found and release
switch.
3. It returns to the normal compass mode within
10 seconds of no switch activity.
SIC0611D
Instruments and controls
2-7


06.7.5/Z50-D/V5.0


4. If the vehicle changes zone, repeat steps 1
thru 3. See map.

If the compass deviates from the correct
indication soon after repeated adjustment,
have the compass checked at an authorized
dealer.

The compass may not indicate the correct
compass point in tunnels or while driving up
or down a steep hill.
(The compass returns to the correct com-
pass point when the vehicle moves to an area
where the geomagnetism is stabilized.)
CAUTION

Do not install a ski rack, antenna,
etc., which are attached to the vehicle
by means of a magnet. They affect
the operation of the compass.

When cleaning the mirror, use a pa-
per towel or similar material damp-
ened with glass cleaner. Do not spray
glass cleaner directly on the mirror as
it may cause the liquid cleaner to
enter the mirror housing.2-8
Instruments and controls


06.7.5/Z50-D/V5.0


To defog/defrost the rear window glass and
outside mirrors (if so equipped), start the engine
and push the switch on
1. The indicator light
A
will come on. Push the switch again to turn
the defroster off.
It will automatically turn off in approximately 15
minutes.
CAUTION
When cleaning the inner side of the rear
window, be careful not to scratch or
damage the rear window defroster.
XENON HEADLIGHTS (if so
equipped)
WARNINGHIGH VOLTAGE

When xenon headlights are on, they
produce a high voltage. To prevent an
electric shock, never attempt to
modify or disassemble. Always have
your xenon headlights replaced at a
NISSAN dealer.

Xenon headlights provide consider-
ably more light than conventional
headlights. If they are not correctly
aimed, they might temporarily blind
an oncoming driver or the driver
ahead of you and cause a serious
accident. If headlights are not aimed
correctly, immediately take your ve-
hicle to a NISSAN dealer and have
the headlights adjusted correctly.
When the xenon headlight is initially turned on,
its brightness or color varies slightly. However,
the color and brightness will soon stabilize.
The life of xenon headlights will be
shortened by frequent on-off operation.
It is generally desirable not to turn off
the headlights for short intervals (for
example, when the vehicle stops at a
traffic signal). Even when the daytime
running lights are active (Canada only),
the xenon headlights do not turn on.
This way the life of the xenon headlights
is not reduced.

If the xenon headlight bulb is close to
burning out, the brightness will drasti-
cally decrease, the light will start blink-
ing, or the color of the light will become
reddish. If one or more of the above
signs appear, contact a NISSAN dealer.
SIC2046
REAR WINDOW AND OUTSIDE
MIRROR DEFROSTER SWITCHHEADLIGHT AND TURN SIGNAL
SWITCH2-22
Instruments and controls


06.7.5/Z50-D/V5.0


Battery saver system
When the headlight switch is in the
or
position while the ignition switch is in
the ON position, the lights will automatically
turn off 5 minutes after the ignition switch has
been turned to the OFF position.

When the headlight switch remains in theor
position after the lights auto-
matically turn off, the lights will turn on for 5
minutes when the headlight switch is turned
to the OFF position and then turned to the
or
position.CAUTION
Even though the battery saver feature
automatically turns off the headlights
after a period of time, you should turn
the headlight switch to the OFF position
when the engine is not running to avoid
discharging the vehicle battery.
Headlight aiming control (if so
equipped)Depending on the number of occupants in the
vehicle and the load it is carrying, the headlight
axis may be higher than desired. If the vehicle is
traveling on a hilly road, the headlights may
directly hit the rearview mirror of the vehicle
ahead or the windshield of the oncoming vehicle.
The light axis can be lowered with the operation
of the switch.
The larger the number designated on the switch,
the lower the axis.When traveling with no heavy load or on a flat
road, select position 0.
WARNING
Xenon headlights are extremely bright
compared to conventional headlights. If
the xenon headlights hit the rearview
mirror of the vehicle ahead or the wind-
shield of oncoming vehicle, the driver of
these vehicles may have difficulty driv-
ing because of the brightness. Use the
headlight aiming control switch to lower
the light axis. See “Xenon headlights”
earlier in this section for additional in-
formation.DAYTIME RUNNING LIGHT SYSTEM
(CANADA ONLY)The daytime running lights automatically illumi-
nate when the engine is started with parking
brake released. The daytime running lights op-
erate with the headlight switch in the OFF
position or in the
position.
The daytime running lights may come on after
turning the switch to the OFF position and
SIC1911
Instruments and controls
2-25


06.7.5/Z50-D/V5.0


CEILING LIGHTThe ceiling light has a three-position switch.
When the switch is in the ON position
1, the
light will illuminate.
When the switch is in the OFF position
2, the
light will turn off.
When the switch is in the DOOR position3,
the light will illuminate when a door is opened.
The light will stay on for about 30 seconds when:

The doors are unlocked by the remote key-
less entry system, a key, power door lock
switch or using the Intelligent Key systemwhile all doors are closed.

The driver’s door is opened and then closed
while the key is removed from the ignition
switch or the ignition switch is turned to the
LOCK position (Intelligent Key system).

The key is removed from the ignition switch or
the ignition switch is turned to the LOCK
position (Intelligent Key system) while all
doors are closed.
The ceiling light will turn off while the 30 second
timer is activated, when:

The driver’s door is locked by the remote
keyless entry system, a key or the power door
lock switch.

The ignition switch is turned ON.
When the ceiling light switch or map light
switch or rear personal light switch is in the
ONposition, the ceiling, map, rear and
vanity mirror lights will automatically turn
off 30 minutes after the ignition switch has
been turned to the ACC or OFF position. To
turn on the light again, turn the ignition
switch to the ONposition.
After the above procedure, the ceiling, map, rear
personal and vanity mirror lights will automati-
cally turn off 30 minutes after the latest operationof the following with the ignition switch in the
ACC or OFF position:

Opening or closing any door

Locking or unlocking with the remote keyless
entry system, a key, the lock-unlock switch or
the ignition switch is turned to the LOCK
position (Intelligent Key system).

Inserting or removing a key from the ignition
switch
These lights will turn on again when any of the
above operations is performed after the lights
have turned off automatically. (The lights will turn
off 30 minutes after the latest operation of the
above as well.)
CAUTION

Turn off the ceiling, map, rear and
vanity mirror lights when you leave
the vehicle.

Do not use for extended periods of
time with the engine stopped. This
could result in a discharged battery.
SIC2063
INTERIOR LIGHTS2-42
Instruments and controls


06.7.5/Z50-D/V5.0


MAP LIGHTTo turn on the light, push the plastic surface
A
of the light. Push it again to turn off the light.
REAR PERSONAL LIGHTThe rear personal light has a three-position
switch. (
A: DOOR,
B: OFF,
C: ON)
When the switch is in the DOOR position
A,
the light will illuminate when a door is opened.
When the ceiling light or the map light
switch or rear personal light switch is in the
ONposition
C, the ceiling, map, rear per-
sonal and vanity mirror lights will auto-
matically turn off 30 minutes after the ig-
nition switch has been turned to the OFF
position
B. To turn on the light again, turn
the ignition switch to the ONposition.
CAUTION

Turn off the ceiling, map, rear and
vanity mirror lights when you leave
the vehicle.

Do not use for extended periods of
time with the engine stopped. This
could result in a discharged battery.
SIC2068
Front
SIC2069
Rear
Instruments and controls
2-43


06.7.5/Z50-D/V5.0
