2007 NISSAN MURANO engine coolant

1. Tachometer (P.2-4)
2. Turn signal indicator (P.2-27)/Hazard indica-
tor (P.2-27)
3. Speedometer (P.2-4)
4. Engine coolant temperature gauge (P.2-5)
5. Fuel gauge (P.2-5)
6. Reset button for trip odometer (P.2-4)
7. Warning/Indicator lights (P.2-9)
8. Odometer (Total/Twin trip) (P.2-4)
9. CVT shift position indicator (P.5-14,18)
SIC3031
METERS AND GAUGES
Illustrated table of contents
0-7


06.7.5/Z50-D/V5.0


1. Power steering fluid reservoir (P.8-12)
2. Engine oil filler cap (P.8-10)
3. Brake fluid reservoir (P.8-13)
4. Air cleaner (P.8-17)
5. Windshield washer fluid reservoir (P.8-14)
6. Engine coolant reservoir (P.8-8)
7. Drive belts (P.8-16)
8. Radiator filler cap (P.8-8)
9. Engine oil dipstick (P.8-9)
10. Fuse/fusible link holder (P.8-21)
11. Battery (P.8-14)
SDI1760
ENGINE COMPARTMENT CHECK
LOCATIONS0-8
Illustrated table of contents


06.7.5/Z50-D/V5.0


2 Instruments and controlsInstrument panel ..................................................................... 2-2
Meters and gauges ............................................................... 2-3
Speedometer and odometer ......................................... 2-4
Tachometer ........................................................................ 2-4
Engine coolant temperature gauge ............................. 2-5
Fuel gauge ......................................................................... 2-5
Compass display (if so equipped) .................................... 2-6
Warning/indicator lights and audible reminders ............ 2-9
Checking bulbs................................................................. 2-9
Warning lights ................................................................... 2-9
Indicator lights ................................................................ 2-14
Audible reminders.......................................................... 2-16
Security systems.................................................................. 2-17
Vehicle security system (if so equipped) ................ 2-17
NISSAN Vehicle Immobilizer System ....................... 2-18
Windshield wiper and washer switch ........................... 2-20
Rear window wiper and washer switch ....................... 2-21
Rear window and outside mirror defroster switch...... 2-22
Headlight and turn signal switch ................................... 2-22
Xenon headlights (if so equipped) .......................... 2-22
Headlight switch ........................................................... 2-23
Daytime running light system (Canada only) ........ 2-25
Instrument brightness control ..................................... 2-26
Turn signal switch ........................................................ 2-27Fog light switch (if so equipped) .............................. 2-27
Hazard warning flasher switch ......................................... 2-27
Horn ........................................................................................ 2-28
Heated seats (if so equipped) ......................................... 2-28
Vehicle Dynamic Control (VDC) OFF switch (if so
equipped) .............................................................................. 2-29
Power outlet.......................................................................... 2-30
Storage .................................................................................. 2-31
Coin box........................................................................... 2-31
Cellular phone holder ................................................... 2-31
Cup holders .................................................................... 2-32
Glove box ........................................................................ 2-33
Console box .................................................................... 2-34
Door pockets .................................................................. 2-36
Cargo net (if so equipped) ......................................... 2-36
Tonneau cover (if so equipped)................................. 2-37
Windows................................................................................ 2-38
Power windows.............................................................. 2-38
Sunroof (if so equipped) ................................................... 2-40
Automatic sunroof ......................................................... 2-40
Interior lights ......................................................................... 2-42
Ceiling light ..................................................................... 2-42
Map light .......................................................................... 2-43
Rear personal light ........................................................ 2-43


06.7.5/Z50-D/V5.0


*1: Refer to the separate Navigation System
Owner’s Manual.
1. Tachometer
2. Turn signal indicator/Hazard indicator
3. Speedometer
4. Engine coolant temperature gauge
5. Fuel gauge6. Reset button for trip odometer
7. Warning/Indicator lights
8. Odometer (Total/Twin trip)
9. CVT shift position indicator
SIC3031
METERS AND GAUGES
Instruments and controls
2-3


06.7.5/Z50-D/V5.0


ENGINE COOLANT TEMPERATURE
GAUGEThe gauge indicates the engine coolant tem-
perature.
The engine coolant temperature is within the
normal range
A
when the gauge needle points
within the zone shown in the illustration.
The engine coolant temperature will vary with the
outside air temperature and driving conditions.
CAUTION
If the gauge indicates engine coolant
temperature near the hot (H) end of the
normal range, reduce vehicle speed to
decrease temperature. If the gauge is
over the normal range, stop the vehicle
as soon as safely possible. If the engine
is overheated, continued operation of
the vehicle may seriously damage the
engine. See “If your vehicle overheats”
in the “In case of emergency” section
for immediate action required.
FUEL GAUGEThe gauge indicates the approximate fuel level in
the tank.
The gauge may move slightly during braking,
turning, acceleration, or going up or down hill.
The gauge needle is designed to move to the E
(Empty) position when the ignition switch is
turned to the OFF position.
Refill the fuel tank before the gauge regis-
ters Empty.
SIC3034
SIC3035
Instruments and controls
2-5


06.7.5/Z50-D/V5.0


right and set to the maximum position.

As soon as possible after the windshield is
clean, push the AUTO button to return to the
auto mode.

When the
front defroster button is
pushed, the air conditioner will automatically
be turned on at outside temperatures above
23°F (−5°C) to defog the windshield, and the
air recirculate mode will automatically be
turned off.
Outside air is drawn into the passenger
compartment to improve the defogging per-
formance.
MANUAL OPERATION
Fan speed controlTurn the fan control button
to manually
control the fan speed.
Push the AUTO button to return to automatic
control of the fan speed.
Air recirculationPush the air recirculation button
to recir-
culate interior air inside the vehicle. The indicator
light on the
button will come on.
The air recirculation
cannot be activatedwhen the air conditioner is in the front defrosting
mode
.
Fresh airPush the button
to draw outside air into
the passenger compartment. The indicator light
on the
button will come on.
Automatic intake air controlIn the AUTO mode, the intake air will be con-
trolled automatically. To manually control the
intake air, push the air recirculate
or fresh
air
button. To return to the automatic
control mode, push the indicator-illuminated but-
ton for about 2 seconds. The indicator lights
(both air recirculate and fresh air buttons) will
flash twice, and then the intake air will be
controlled automatically.
Air flow controlPushing the MODE manual air flow control
button selects the air outlet to:
: Air flows from center and side ventila-
tors.: Air flows from center and side ventila-
tors and foot outlets.: Air flows from foot outlets and side
ventilators.
: Air flows from defroster, foot outlets
and side ventilators.
To turn the system offPush the OFF button.OPERATING TIPSWhen the engine coolant temperature and out-
side air temperature are low, the air flow from the
foot outlets may not operate for a maximum of
150 seconds. However, this is not a malfunction.
After the coolant temperature warms up, the air
flow from the foot outlets will operate normally.
Display screen, heater, air conditioner and audio systems
4-25


06.7.5/Z50-D/V5.0


5 Starting and drivingPrecautions when starting and driving ............................. 5-2
Exhaust gas (Carbon monoxide) .................................. 5-2
Three-way catalyst ........................................................... 5-3
Tire pressure monitoring system (TPMS) ................. 5-3
Avoiding collision and rollover ...................................... 5-5
On-pavement and offroad driving precautions
(AWD) ................................................................................. 5-6
Drinking alcohol/drugs and driving .............................. 5-6
Driving safety precautions.............................................. 5-6
Ignition switch (Except for Intelligent Key equipped
model) ....................................................................................... 5-9
Key positions .................................................................. 5-10
NISSAN Vehicle Immobilizer System (NVIS) ......... 5-10
Ignition switch (Intelligent Key System equipped
model)..................................................................................... 5-10
Ignition switch positions .............................................. 5-11
NISSAN Vehicle Immobilizer System (NVIS) ......... 5-12
Before starting the engine ................................................ 5-12
Starting the engine ............................................................. 5-13
Driving the vehicle ............................................................... 5-13
CVT (Continuously Variable Transmission)............. 5-13
M-CVT (CVT with Manual shift mode)..................... 5-17
Parking brake........................................................................ 5-21
Cruise control ....................................................................... 5-22Precautions on cruise control .................................... 5-22
Cruise control operations ............................................ 5-22
Break-in schedule .............................................................. 5-24
Increasing fuel economy .................................................... 5-24
Using all-wheel drive (AWD) (if so equipped) ............ 5-25
AWD lock switch operations...................................... 5-25
AWD warning light ........................................................ 5-27
Parking/parking on hills...................................................... 5-29
Power steering ..................................................................... 5-30
Brake system ........................................................................ 5-30
Braking precautions ...................................................... 5-30
Anti-lock Braking System (ABS) ............................... 5-31
Vehicle Dynamic Control (VDC) system
(if so equipped) .................................................................. 5-32
Cold weather driving .......................................................... 5-34
Freeing a frozen door lock .......................................... 5-34
Antifreeze ......................................................................... 5-34
Battery .............................................................................. 5-34
Draining of coolant water ............................................ 5-34
Tire equipment................................................................ 5-34
Special winter equipment ............................................ 5-35
Driving on snow or ice ................................................. 5-35
Engine block heater (if so equipped) ....................... 5-35


06.7.5/Z50-D/V5.0


tem may not operate properly and the
“VDC OFF” indicator or “SLIP” indi-
cator or both indicator lights may
illuminate.

The VDC system is not a substitute
for winter tires or tire chains on a
snow-covered road.
FREEING A FROZEN DOOR LOCKTo prevent a door lock from freezing, apply
deicer or glycerin to it through the key hole. If the
lock becomes frozen, heat the key before insert-
ing it into the key hole.ANTIFREEZEIn the winter when it is anticipated that the
temperature will drop below 32°F (0°C), check
antifreeze to assure proper winter protection. For
additional information, see “Engine cooling sys-
tem” in the “8. Maintenance and do-it-yourself”
section.BATTERYIf the battery is not fully charged during extremely
cold weather conditions, the battery fluid may
freeze and damage the battery. To maintain
maximum efficiency, the battery should be
checked regularly. For additional information,
see “Battery” in the “8. Maintenance and do-it-
yourself” section.DRAINING OF COOLANT WATERIf the vehicle is to be left outside without anti-
freeze, drain the cooling system by opening the
drain plug located under the radiator. Refill
before operating the vehicle. See “Engine cool-
ing system” in the “8. Maintenance and do-it-
yourself” section for changing engine coolant.
TIRE EQUIPMENT1. SUMMER tires are of a tread design to
provide superior performance on dry pave-
ment. However, the performance of these
tires will be substantially reduced in snowy
and icy conditions. If you operate your vehicle
on snowy or icy roads, NISSAN recommends
the use of MUD & SNOW or ALL SEASON
tires on all four wheels. Please consult a
NISSAN dealer for the tire type, size, speed
rating and availability information.
2. For additional traction on icy roads, studded
tires may be used. However, some provinces
and states prohibit their use. Check local,
state and provincial laws before installing
studded tires.
Skid and traction capabilities of studded
snow tires, on wet or dry surfaces, may be
poorer than that of non-studded snow
tires.
3. Tire chains may be used. For details, see
“Tire chains” in the “Maintenance and do-it-
yourself” section of this manual.
4. For all-wheel drive:
If you install snow tires, they must also be the
same size, brand, construction and tread
pattern on all four wheels.
COLD WEATHER DRIVING
5-34
Starting and driving


06.7.5/Z50-D/V5.0
