2007 NISSAN 350Z sensor

TROUBLE DIAGNOSIS FOR SYSTEM
BRC-105
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2006 November2007 350Z
TROUBLE DIAGNOSIS FOR SYSTEMPFP:00000
Wheel Sensor SystemNFS0004D
After using the CONSULT-III SELF-DIAG RESULTS to determine the location of the malfunctioning wheel sen-
sor, check all areas to determine the component to be replaced.
CAUTION:

Do not measure the resistance value and also voltage between the sensor terminal with tester etc.,
because the sensor is an active sensor.

Do not expand the terminal of the connector with a/the tester terminal stick, when it does the
inspection with the tester.
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK TIRE
Check air pressure, wear, and size.
Are air pressure, wear, and size within the standard values?
YES >> GO TO 3.
NO >> Adjust air pressure, or replace tire.
3. CHECK SENSOR AND SENSOR ROTOR

Check the condition of the sensor mount (for looseness, etc.).

Check the surface of the front sensor rotor rubber for damage.

Check the rear sensor rotor for damage.
OK or NG
OK >> GO TO 4.
NG >> Repair wheel sensor mount or replace the sensor rotor.
4. CHECK CONNECTOR
1. Disconnect VDC/TCS/ABS control unit connector and malfunctioning wheel sensor connector E42 (FR -
LH) or E27 (FR - RH) or T5 (RR - RH, LH). Check the terminal to see if it is deformed, disconnected,
loose, etc., and replace it if any non-standard condition is found.
2. Reconnect connectors, drive at a speed of approximately 30 km/h (19 MPH) or more for approximately
1minute, and then perform self-diagnosis.
Is the result of self-diagnosis normal?
YES >> The connector terminal contact is loose, damaged, open or shorted.
NO >> GO TO 5.
Self-diagnosis results
FR RH SENSOR-1,-2
FR LH SENSOR- 1,-2
RR RH SENSOR-1,-2
RR LH SENSOR-1,- 2
ABS SENSOR [ABNORMAL SIGNAL]

BRC-106
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: 2006 November2007 350Z
5. CHECK WHEEL SENSOR HARNESS
1. Turn ignition switch OFF and disconnect wheel sensor connec-
tor E42 (FR - LH), E27 (FR - RH), T5 (RR - RH, LH) and VDC/
TCS/ABS control unit connector B114.
2. Check continuity between terminals. (Also check the continuity
when the steering wheel is turned right and left and when the
sensor harness inside the wheel well is moved.)
OK or NG
OK >> GO TO 6.
NG >> Repair or replace harness and connector that have malfunction.
6. CHECK WHEEL SENSOR POWER SUPPLY CIRCUIT
1. Disconnect malfunctioning wheel sensor connector.
2. Turn ignition switch ON and check voltage between wheel sen-
sor harness connector power supply terminal and ground.
OK or NG
OK >> Replace wheel sensor.
NG >> Replace ABS actuator and electric unit (control unit).
SFIA3246E
Power system Signal system Ground system
WheelVDC/TCS/ABS
control unitWheel sensorVDC/TCS/ABS
control unitWheel sensorVDC/TCS/ABS
control unit
(signal)VDC/TCS/ABS
control unit
(ground)
Front RH 16 1 15 2 16, 15
28, 29 Front LH 10 1 8 2 10, 8
Rear RH 12 1 11 2 12, 11
Rear LH 14 3 13 4 14, 13
Power system : Continuity should exist.
Signal system : Continuity should exist.
Ground system : Continuity should not exist.
Wheel Wheel sensor Ground Voltage
Front RH
1
— 8 V or more Front LH
Rear RH
Rear LH 3
SFIA3399E

BRC-108
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: 2006 November2007 350Z
Pressure Sensor SystemNFS0004G
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK STOP LAMP SWITCH CONNECTOR
1. Disconnect stop lamp switch connector and VDC/TCS/ABS control unit connector and check the termi-
nals for deformation, disconnection, looseness, and so on. If there is an error, repair or replace the termi-
nal.
2. Securely reconnect the connectors.
3. Start engine.
4. Repeat pumping brake pedal carefully several times, then perform self-diagnosis again.
Is the result of self-diagnosis normal?
YES >> The connector terminal contact is loose, damaged, open or shorted.
NO >> GO TO 3.
3. CHECK STOP LAMP SWITCH
1. Turn ignition switch OFF and disconnect stop lamp switch con-
nector E111.
2. Disconnect stop lamp switch connector
3. Check continuity between stop lamp switch connector terminal 3
and 4.
OK or NG
OK >> GO TO 4.
NG >> Replace stop lamp switch. Refer to BR-8, "
Components" .
Self-diagnosis results
PRESS SEN CIRCUIT
Stop lamp switch Condition Continuity
3 – 4Release stop lamp switch
(When brake pedal is depressed.)Ye s
Push stop lamp switch
(When brake pedal is released.)No
SFIA3390E

TROUBLE DIAGNOSIS FOR SYSTEM
BRC-109
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2006 November2007 350Z
4. CHECK STOP LAMP SWITCH CIRCUIT
1. Turn ignition switch OFF and disconnect VDC/TCS/ABS control
unit connector B114.
2. Check voltage between VDC/TCS/ABS control unit connector
B114 terminal 48 and ground.
OK or NG
OK >> GO TO 5.
NG >> Open or short in harness. Repair or replace the harness.
5. CHECK PRESSURE SENSOR CONNECTOR
1. Disconnect VDC actuator connector E50 and VDC/TCS/ABS control unit connector, check terminals for
deformation, disconnection, looseness, and so on. If there is an error, repair or replace the terminal.
2. Reconnect the connectors and then perform self-diagnosis.
Is the result of self-diagnosis normal?
YES >> The connector terminal contact is loose, damaged, open or shorted.
NO >> GO TO 6.
6. CHECK PRESSURE SENSOR HARNESS
1. Turn ignition switch OFF and disconnect VDC actuator connec-
tor E50 and VDC/TCS/ABS control unit connector B114.
2. Check continuity between VDC/TCS/ABS control unit connector
and VDC actuator connector.
OK or NG
OK >> GO TO 7.
NG >> If the open or short in harness, repair or replace the harness.
7. CHECK PRESSURE SENSOR
1. Connect VDC actuator and VDC/TCS/ABS control unit connectors.
2. Conduct “DATA MONITOR” of the “PRESS SENSOR” to check if the status is normal.
SFIA1896E
VDC/TCS/ABS control unit Ground Measurement condition Voltage
48 —Brake pedal depressed. Battery voltage (Approx. 12 V)
Brake pedal not depressed. Approx. 0 V
VDC/TCS/ABS control unit VDC actuator Continuity
69 30
Ye s 68 31
67 32
SFIA2444E
Condition Data monitor display
When brake pedal is depressed.− 40 – 300 bar
When brake pedal is released. Approx. 0 bar

BRC-110
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: 2006 November2007 350Z
OK or NG
OK >> INSPECTION END
NG >> If the pressure sensor is damaged or malfunctioning, replace the VDC actuator (pressure sensor it
built in).
Steering Angle Sensor SystemNFS0004H
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis item?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK CONNECTOR
1. Disconnect steering angle sensor connector and VDC/TCS/ABS control unit connector and check termi-
nals for deformation, disconnection, looseness, and so on. If there is an error, repair or replace the termi-
nal.
2. Reconnect the connectors and then preform self-diagnosis.
Is the result of self-diagnosis normal?
YES >> The connector terminal contact is loose, damaged, open or shorted.
NO >> GO TO 3.
3. CHECK STEERING ANGLE SENSOR HARNESS
1. Check CAN communication system. Refer to BRC-122, "
CAN Communication System" .
2. Turn ignition switch OFF and disconnect steering angle sensor
connector M22 and VDC/TCS/ABS control unit connector B114.
3. Check continuity between VDC/TCS/ABS control unit connector
terminal 2 and steering angle sensor connector terminal 3.
OK or NG
OK >> GO TO 4.
NG >> If the open or short in harness, repair or replace the har-
ness.
4. CHECK DATA MONITOR
1. Connect steering angle sensor and VDC/TCS/ABS control unit connectors.
2. Conduct “DATA MONITOR” of the “STR ANGLE SIG” to check if the status is normal.
OK or NG
OK >> Re-conduct VDC/TCS/ABS control unit self-diagnosis.
NG >> Replace spiral cable (steering angle sensor) and adjust neutral position of steering angle sensor.
Refer to BRC-79, "
Adjustment of Steering Angle Sensor Neutral Position" .
Self-diagnosis results
ST ANG SEN CIRCUIT
VDC/TCS/ABS control unit Steering angle sensor Continuity
23Yes
SFIA2445E
Steering condition Data monitor
Straight-ahead Approx. 0°
Turn wheel to the right by 90 °Approx. + 90°
Turn wheel to the left by 90 °Approx. - 90°

TROUBLE DIAGNOSIS FOR SYSTEM
BRC-111
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2006 November2007 350Z
Yaw Rate/Side G Sensor SystemNFS0004I
CAUTION:
Sudden turns (such as spin turns, acceleration turns), drifting, etc. When VDC function is OFF (VDC
OFF switch ON) may cause the yaw rate/side G sensor system indicate a problem. However this is not
a problem if normal operation can be resumed after restarting the engine.
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
CAUTION:
When on a turntable, such as at a parking structure entrance, or when on a moving object with the
engine running, the VDC OFF indicator lamp might turn on and the self-diagnosis using the CONSULT-
III the yaw rate sensor system might be displayed, but in this case there is no problem with the yaw
rate sensor system. As soon as the vehicle leaves the turntable or moving object, restart the engine to
return the system to normal.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK CONNECTOR
1. Disconnect yaw rate/side G sensor connector and VDC/TCS/ABS control unit connector and check the
terminals for deformation, disconnection, looseness, and so on. If there is an error, repair or replace the
terminal.
2. Reconnect the connectors and then preform self-diagnosis.
Is the result of self-diagnosis normal?
YES >> The connector terminal contact is loose, damaged, open or shorted.
NO >> GO TO 3.
Self-diagnosis results
YAW RATE SENSOR
SIDE G-SENSOR

BRC-112
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: 2006 November2007 350Z
3. CHECK YAW RATE/SIDE G SENSOR HARNESS
1. Turn ignition switch OFF and disconnect yaw rate/side G sensor
connector M51 and VDC/TCS/ABS control unit connector B114.
2. Check continuity between VDC/TCS/ABS control unit vehicle
side connector and yaw rate/side G sensor vehicle side connec-
tor.
OK or NG
OK >> GO TO 4.
NG >> If the open or short in harness, repair or replace the harness.
4. CHECK YAW RATE/SIDE G SENSOR
1. Connect yaw rate/side G sensor and VDC/TCS/ABS control unit connectors.
2. Use “DATA MONITOR” to check if the yaw rate/side G sensor are normal.
OK or NG
OK >> INSPECTION END
NG >> Replace the malfunctioning yaw rate/side G sensor, and then re-conduct the VDC/TCS/ABS con-
trol unit self-diagnosis.
SFIA1890E
VDC/TCS/ABS control unit Yaw rate/side G sensor Continuity
18 5
Ye s 34 3
77 2
78 1
79 4
80 6
Vehicle statusYaw rate sensor
(Data monitor standard)Side G sensor
(Data monitor standard)
When stopped - 4 to + 4 deg/s
- 1.1 to + 1.1 m/s
2
Right turn Negative value Negative value
Left turn Positive value Positive value

BRC-124
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: 2006 November2007 350Z
TROUBLE DIAGNOSIS FOR SYMPTOMSPFP:00007
Excessive ABS Function Operation FrequencyNFS0004S
1. CHECK START
Check brake force distribution.
OK or NG
OK >> GO TO 2.
NG >> Check brake system
2. CHECK FRONT AND REAR AXLE
Make sure there is no excessive play in the front and rear axles.
OK or NG
OK >> GO TO 3.
NG >> Repair.
3. CHECK WHEEL SENSOR AND SENSOR ROTOR
Wheel Sensor Inspection

Wheel sensor mount and damage inspection

Sensor rotor mount and damage inspection

Wheel sensor connector connection inspection

Wheel sensor harness inspection
OK or NG
OK >> GO TO 4.
NG >>

Replace wheel sensor or sensor rotor.

Repair harness.
4. CHECK ABS WARNING LAMP DISPLAY
Make sure the warning lamp turns off approximately 1 sec. After the ignition switch is turned on or when driv-
ing.
OK or NG
OK >> Normal
NG >> Perform self-diagnosis. Refer to BRC-96, "
OPERATION PROCEDURE" .
Unexpected Pedal ReactionNFS0004T
1. CHECK BRAKE PEDAL STROKE
Check brake pedal stroke.
Is the stroke too big?
YES >>
Bleed air from the brake piping.

Check the brake pedal, brake booster, and master cylinder mount for play, looseness, and
brake system for fluid leaks, etc. If any malfunctions are found, make repair.
NO >> GO TO 2.
2. CHECK FUNCTION
Disconnect the VDC/TCS/ABS control unit connector and make sure the braking force is sufficient when the
ABS in not operating. After the inspection, reconnect the connector.
OK or NG
OK >> GO TO 3. CHECK WHEEL SENSOR AND SENSOR ROTOR in BRC-124, "Excessive ABS Func-
tion Operation Frequency" .
NG >> Check brake system.
