TROUBLE DIAGNOSIS FOR SYSTEM
BRC-105
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2006 November2007 350Z
TROUBLE DIAGNOSIS FOR SYSTEMPFP:00000
Wheel Sensor SystemNFS0004D
After using the CONSULT-III SELF-DIAG RESULTS to determine the location of the malfunctioning wheel sen-
sor, check all areas to determine the component to be replaced.
CAUTION:

Do not measure the resistance value and also voltage between the sensor terminal with tester etc.,
because the sensor is an active sensor.

Do not expand the terminal of the connector with a/the tester terminal stick, when it does the
inspection with the tester.
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK TIRE
Check air pressure, wear, and size.
Are air pressure, wear, and size within the standard values?
YES >> GO TO 3.
NO >> Adjust air pressure, or replace tire.
3. CHECK SENSOR AND SENSOR ROTOR

Check the condition of the sensor mount (for looseness, etc.).

Check the surface of the front sensor rotor rubber for damage.

Check the rear sensor rotor for damage.
OK or NG
OK >> GO TO 4.
NG >> Repair wheel sensor mount or replace the sensor rotor.
4. CHECK CONNECTOR
1. Disconnect VDC/TCS/ABS control unit connector and malfunctioning wheel sensor connector E42 (FR -
LH) or E27 (FR - RH) or T5 (RR - RH, LH). Check the terminal to see if it is deformed, disconnected,
loose, etc., and replace it if any non-standard condition is found.
2. Reconnect connectors, drive at a speed of approximately 30 km/h (19 MPH) or more for approximately
1minute, and then perform self-diagnosis.
Is the result of self-diagnosis normal?
YES >> The connector terminal contact is loose, damaged, open or shorted.
NO >> GO TO 5.
Self-diagnosis results
FR RH SENSOR-1,-2
FR LH SENSOR- 1,-2
RR RH SENSOR-1,-2
RR LH SENSOR-1,- 2
ABS SENSOR [ABNORMAL SIGNAL]

TROUBLE DIAGNOSIS FOR SYSTEM
BRC-107
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2006 November2007 350Z
Engine SystemNFS0004E
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK ENGINE SYSTEM
1. Conduct an ECM self-diagnosis and repair or replace any non-standard items. Re-conduct the ECM self-
diagnosis.
2. Re-conduct VDC/TCS/ABS control unit self-diagnosis.
OK or NG
OK >> INSPECTION END
NG >> Repair or replace any non-standard items. Re-conduct the self-diagnosis.
VDC/TCS/ABS Control Unit 1NFS0004F
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> Replace VDC/TCS/ABS control unit. Re-conduct the self-diagnosis.
NO >> INSPECTION END
Self-diagnosis results
ENGINE SIGNAL 1
ENGINE SIGNAL 2
ENGINE SIGNAL 3
ENGINE SIGNAL 4
ENGINE SIGNAL 5
ENGINE SIGNAL 6
Self-diagnosis results
CONTROLLER FAILURE

BRC-108
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: 2006 November2007 350Z
Pressure Sensor SystemNFS0004G
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK STOP LAMP SWITCH CONNECTOR
1. Disconnect stop lamp switch connector and VDC/TCS/ABS control unit connector and check the termi-
nals for deformation, disconnection, looseness, and so on. If there is an error, repair or replace the termi-
nal.
2. Securely reconnect the connectors.
3. Start engine.
4. Repeat pumping brake pedal carefully several times, then perform self-diagnosis again.
Is the result of self-diagnosis normal?
YES >> The connector terminal contact is loose, damaged, open or shorted.
NO >> GO TO 3.
3. CHECK STOP LAMP SWITCH
1. Turn ignition switch OFF and disconnect stop lamp switch con-
nector E111.
2. Disconnect stop lamp switch connector
3. Check continuity between stop lamp switch connector terminal 3
and 4.
OK or NG
OK >> GO TO 4.
NG >> Replace stop lamp switch. Refer to BR-8, "
Components" .
Self-diagnosis results
PRESS SEN CIRCUIT
Stop lamp switch Condition Continuity
3 – 4Release stop lamp switch
(When brake pedal is depressed.)Ye s
Push stop lamp switch
(When brake pedal is released.)No
SFIA3390E

TROUBLE DIAGNOSIS FOR SYSTEM
BRC-109
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2006 November2007 350Z
4. CHECK STOP LAMP SWITCH CIRCUIT
1. Turn ignition switch OFF and disconnect VDC/TCS/ABS control
unit connector B114.
2. Check voltage between VDC/TCS/ABS control unit connector
B114 terminal 48 and ground.
OK or NG
OK >> GO TO 5.
NG >> Open or short in harness. Repair or replace the harness.
5. CHECK PRESSURE SENSOR CONNECTOR
1. Disconnect VDC actuator connector E50 and VDC/TCS/ABS control unit connector, check terminals for
deformation, disconnection, looseness, and so on. If there is an error, repair or replace the terminal.
2. Reconnect the connectors and then perform self-diagnosis.
Is the result of self-diagnosis normal?
YES >> The connector terminal contact is loose, damaged, open or shorted.
NO >> GO TO 6.
6. CHECK PRESSURE SENSOR HARNESS
1. Turn ignition switch OFF and disconnect VDC actuator connec-
tor E50 and VDC/TCS/ABS control unit connector B114.
2. Check continuity between VDC/TCS/ABS control unit connector
and VDC actuator connector.
OK or NG
OK >> GO TO 7.
NG >> If the open or short in harness, repair or replace the harness.
7. CHECK PRESSURE SENSOR
1. Connect VDC actuator and VDC/TCS/ABS control unit connectors.
2. Conduct “DATA MONITOR” of the “PRESS SENSOR” to check if the status is normal.
SFIA1896E
VDC/TCS/ABS control unit Ground Measurement condition Voltage
48 —Brake pedal depressed. Battery voltage (Approx. 12 V)
Brake pedal not depressed. Approx. 0 V
VDC/TCS/ABS control unit VDC actuator Continuity
69 30
Ye s 68 31
67 32
SFIA2444E
Condition Data monitor display
When brake pedal is depressed.− 40 – 300 bar
When brake pedal is released. Approx. 0 bar

BRC-110
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: 2006 November2007 350Z
OK or NG
OK >> INSPECTION END
NG >> If the pressure sensor is damaged or malfunctioning, replace the VDC actuator (pressure sensor it
built in).
Steering Angle Sensor SystemNFS0004H
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis item?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK CONNECTOR
1. Disconnect steering angle sensor connector and VDC/TCS/ABS control unit connector and check termi-
nals for deformation, disconnection, looseness, and so on. If there is an error, repair or replace the termi-
nal.
2. Reconnect the connectors and then preform self-diagnosis.
Is the result of self-diagnosis normal?
YES >> The connector terminal contact is loose, damaged, open or shorted.
NO >> GO TO 3.
3. CHECK STEERING ANGLE SENSOR HARNESS
1. Check CAN communication system. Refer to BRC-122, "
CAN Communication System" .
2. Turn ignition switch OFF and disconnect steering angle sensor
connector M22 and VDC/TCS/ABS control unit connector B114.
3. Check continuity between VDC/TCS/ABS control unit connector
terminal 2 and steering angle sensor connector terminal 3.
OK or NG
OK >> GO TO 4.
NG >> If the open or short in harness, repair or replace the har-
ness.
4. CHECK DATA MONITOR
1. Connect steering angle sensor and VDC/TCS/ABS control unit connectors.
2. Conduct “DATA MONITOR” of the “STR ANGLE SIG” to check if the status is normal.
OK or NG
OK >> Re-conduct VDC/TCS/ABS control unit self-diagnosis.
NG >> Replace spiral cable (steering angle sensor) and adjust neutral position of steering angle sensor.
Refer to BRC-79, "
Adjustment of Steering Angle Sensor Neutral Position" .
Self-diagnosis results
ST ANG SEN CIRCUIT
VDC/TCS/ABS control unit Steering angle sensor Continuity
23Yes
SFIA2445E
Steering condition Data monitor
Straight-ahead Approx. 0°
Turn wheel to the right by 90 °Approx. + 90°
Turn wheel to the left by 90 °Approx. - 90°

TROUBLE DIAGNOSIS FOR SYSTEM
BRC-111
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2006 November2007 350Z
Yaw Rate/Side G Sensor SystemNFS0004I
CAUTION:
Sudden turns (such as spin turns, acceleration turns), drifting, etc. When VDC function is OFF (VDC
OFF switch ON) may cause the yaw rate/side G sensor system indicate a problem. However this is not
a problem if normal operation can be resumed after restarting the engine.
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
CAUTION:
When on a turntable, such as at a parking structure entrance, or when on a moving object with the
engine running, the VDC OFF indicator lamp might turn on and the self-diagnosis using the CONSULT-
III the yaw rate sensor system might be displayed, but in this case there is no problem with the yaw
rate sensor system. As soon as the vehicle leaves the turntable or moving object, restart the engine to
return the system to normal.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK CONNECTOR
1. Disconnect yaw rate/side G sensor connector and VDC/TCS/ABS control unit connector and check the
terminals for deformation, disconnection, looseness, and so on. If there is an error, repair or replace the
terminal.
2. Reconnect the connectors and then preform self-diagnosis.
Is the result of self-diagnosis normal?
YES >> The connector terminal contact is loose, damaged, open or shorted.
NO >> GO TO 3.
Self-diagnosis results
YAW RATE SENSOR
SIDE G-SENSOR

TROUBLE DIAGNOSIS FOR SYSTEM
BRC-113
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2006 November2007 350Z
Solenoid and VDC Change-Over Valve SystemNFS0004J
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK CONNECTOR
1. Disconnect VDC/TCS/ABS control unit connector and solenoid connector E49, E50 and check the termi-
nals for deformation, disconnection, looseness, and so on. If there is an error, repair or replace the termi-
nal.
2. Securely reconnect the connectors and then preform self-diagnosis.
Is the result of self-diagnosis normal?
YES >> The connector terminal contact is loose, damaged, open or shorted.
NO >> GO TO 3.
Self-diagnosis results
IN ABS SOL
OUT ABS SOL
USV LINE [FL-RR]
USV LINE [FR-RL]
HSV LINE [FL-RR]
HSV LINE [FR-RL]

BRC-116
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: 2006 November2007 350Z
ABS Motor and Motor Relay SystemNFS0004K
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK CONNECTOR
1. Disconnect VDC relay box connector E47, E48, E222 and VDC/TCS/ABS control unit connector and
check the terminals for deformation, disconnection, looseness, and so on. If there is an error, repair or
replace the terminal.
2. Securely reconnect the connectors and then preform self-diagnosis.
Is the result of self-diagnosis normal?
YES >> The connector terminal contact is loose, damaged, open or shorted.
NO >> GO TO 3.
3. CHECK ABS MOTOR AND MOTOR RELAY POWER SYSTEM
1. Disconnect VDC relay box connectors E48.
2. Check voltage between VDC relay box connector and ground.
OK or NG
OK >> GO TO 4.
NG >> The circuit between battery and VDC relay box terminal
10 is open or shorted. Repair the circuit.
Self-diagnosis results
PUMP MOTOR
VDC relay box Ground Voltage
10 — Battery voltage (Approx. 12 V)
SFIA1892E
