2007 NISSAN 350Z check engine

BRC-98
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
Note 1: After completing repairs of the shorted sensor circuit, when ignition switch is turned ON, ABS warning lamp turns on. Check that
ABS warning lamp turns off while driving the vehicle at approximately 30 km/h (19 MPH) for approximately 1 minute according to self-
diagnosis procedure. In addition, if wheel sensor 2 is displayed for the wheels, check the wheel sensor circuit and also check the control
unit power voltage.
Note 2: When errors are detected in several systems, including the CAN communication system [U1000], troubleshoot the CAN commu-
nication system.USV LINE [FL-RR]
[C1147]When the primary side VDC change-over valve 1 circuit is open or
short-circuit.
BRC-113, "
Solenoid and
VDC Change-Over Valve
System"
USV LINE [FR-RL]
[C1148]When the secondary side VDC change-over valve 1 circuit is open
or short-circuit.
HSV LINE [FL-RR]
[C1149]When the primary side VDC change-over valve 2 circuit is open or
short-circuit.
HSV LINE [FR-RL]
[C1150]When the secondary side VDC change-over valve 2 circuit is open
or short-circuit.
PRESS SEN CIRCUIT
[C1142]Pressure sensor open-circuit. When a short-circuit is detected. Or,
when a pressure sensor error is detected.BRC-108, "
Pressure Sen-
sor System"
ST ANG SEN CIRCUIT
[C1143]When the steering angle sensor neutral point has deviated. Or,
when a steering angle sensor error is detected.BRC-110, "Steering Angle
Sensor System"
ST ANG SEN SIGNAL
[C1144]Neutral position correction of steering angle sensor is not finished.BRC-79, "Adjustment of
Steering Angle Sensor
Neutral Position"
YAW RATE SENSOR
[C1145]When a yaw rate sensor error is detected. Or, when the yaw rate
sensor circuit is open. When a short-circuit is detected.BRC-111, "Yaw Rate/Side
G Sensor System"
SIDE G - SEN CIRCUIT
[C1146]When there is an error in the side G sensor. Or, when the side G
sensor circuit is open or short-circuited.BRC-111, "Yaw Rate/Side
G Sensor System"
ENGINE SIGNAL 1
[C1130]
Major engine components malfunctioning.BRC-107, "
Engine Sys-
tem"
ENGINE SIGNAL 2
[C1131]
ENGINE SIGNAL 3
[C1132]
ENGINE SIGNAL 4
[C1133]
ENGINE SIGNAL 5
[C1134]
ENGINE SIGNAL 6
[C1135]
EMERGENCY BRAKE
[C1153]When the VDC/TCS/ABS control unit is malfunctioning (excessive
pressure increase or insufficient pressure increase).BRC-121, "
VDC/TCS/
ABS Control Unit 2"
BR FLUID LEVEL LOW
[C1155]The brake fluid level has dropped. Or, when there is a short to
ground in the circuit between the VDC/TCS/ABS control unit and
the fluid level sensor.BRC-121, "Brake Fluid
Level Switch System"
ST ANG SEN COM CIR
[C1156]CAN communication line or steering angle sensor has generated
an error.BRC-122, "CAN Commu-
nication System"
CAN COMM CIRCUIT
[U1000]When VDC/TCS/ABS control unit is not transmitting or receiving
CAN communication signal for 2 seconds or more.BRC-122, "CAN Commu-
nication System"
(Note 2) Display item Malfunction detecting condition Check item

BRC-102
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z

When inspection of the continuity or voltage between units is performed, check connector terminals for
disconnection, looseness, bend, or collapse. If any non-standard condition is detected, repair or replace
applicable part.

Intermittent errors may be caused by a poor connection in the harness, connector, or terminal. Move har-
nesses, harness connectors, or terminals by hand to make sure all connections are solid and undamaged.

If a circuit tester is used for the check, be careful not to forcibly extend any connector terminal.

VDC/TCS/ABS is a system that uses electronic control to perform brake control and engine power control.
Therefore, phenomena like those shown in the following table may occur, but this is because the system is
working normally.
Symptom Symptom description Result
Motor operation noiseThe is a motor operation sound inside VDC/TCS/ABS actuator, and some-
times there is a slight sound when VDC, TCS, or ABS operates.
Normal
Just after the engine starts, the motor operating noise may be heard. This
is a normal status of the system operation check.
System operation check noiseWhen the engine is started, you may barely be able to hear a slight thud-
ding sound from the engine room, but this sound is made by the system
operation check and is normal.Normal
TCS operation
(SLIP indicator lamp ON)TCS may be activated any time the vehicle suddenly accelerates, suddenly
downshifts, or is driven on a road with a varying surface friction coefficient.
Normal
Cancel the VDC/TCS
function for the
inspection on a chas-
sis dynamometer. When inspecting the speedometer, etc., press VDC OFF switch to turn off
TCS function before conducting the work.
When accelerator pedal is depressed on a chassis dynamometer (front
wheel fixing type), the vehicle speed will not increase. This is normal,
because TCS is activated by the stationary front wheels. The warning lamp
may also turn on to show “sensor system error” in this case. This is not a
malfunction either, because the stationary front wheels are detected.
Restart engine, and drive the vehicle at 30 km/h (19 MPH) or higher to
check that the warning lamp no longer turns on.
ABS operation
(longer stopping distance)Stopping distance may be longer for vehicles with ABS when the vehicle
drives on rough or snow-covered roads. Use lower speeds when driving on
these kinds of roads.Normal
Sluggish feelDepending on road circumstances, the driver may have a sluggish feel.
This is normal, because under TCS operation optimum traction has the
highest priority (safety first). Sometimes the driver has a slight sluggish feel
in response to substantial accelerator pedal operation.Normal

TROUBLE DIAGNOSIS
BRC-103
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2006 November2007 350Z
ABS WARNING LAMP, VDC OFF INDICATOR LAMP, SLIP INDICATOR LAMP AND BRAKE
WARNING LAMP ON/OFF TIMING
×: ON –: OFF
Note 1:Brake warning lamp will turn on in case of operating parking brake (switch turned on) or of actuating brake fluid level switch
(brake fluid is insufficient).
Basic InspectionNFS0004C
BRAKE FLUID AMOUNT, LEAKS, AND BRAKE PADS INSPECTION
1. Check fluid level in the brake reservoir tank. If fluid level is low, refill the brake fluid.
2. Check brake tubes or hoses and around VDC actuator for leaks. If there is leaking or oozing fluid, check
the following items.

If VDC actuator connection is loose, tighten the piping to the specified torque and re-conduct the leak
inspection to make sure there are no leaks.

If there is damage to the connection flare nut or VDC actuator screw, replace the damaged part and re-
conduct the leak inspection to make sure there are no leaks.

When there is fluid leaking or oozing from a part other than VDC actuator connection, if the fluid is just
oozing out, use a clean cloth to wipe off the oozing fluid and re-check for leaks. If fluid is still oozing out,
replace the damaged part.

When there is fluid leaking or oozing at VDC actuator, if the fluid is just oozing out, use a clean cloth to
wipe off the oozing fluid and re-check for leaks. If fluid is still oozing out, replace the VDC actuator body.
CAUTION:
VDC actuator cannot be disassembled.
3. Check the brake pad degree of wear. Refer to BR-26, "
PAD WEAR INSPECTION" in “Front Disc Brake”
and BR-39, "
PAD WEAR INSPECTION" in “Rear Disc Brake”.
POWER SYSTEM TERMINAL LOOSENESS AND BATTERY INSPECTION
Make sure the battery positive cable, negative cable and ground connection are not loose. In addition, check
the battery voltage to make sure it has not dropped.
ABS WARNING LAMP, VDC OFF INDICATOR LAMP, SLIP INDICATOR LAMP INSPECTION
1. Make sure ABS warning lamp, VDC OFF indicator lamp (when VDC OFF switch is OFF), and SLIP indica-
tor lamp turns ON approximately 1 second when the ignition switch is turned ON. If they do not, check the
VDC OFF indicator lamp and then VDC OFF switch. Refer to BRC-122, "
VDC OFF SWITCH" . Check
CAN communications. Refer to “CAN Communication Inspection”. If there are no errors with VDC OFF
switch and CAN communication system, check combination meter. Refer to BRC-122, "
CAN Communica-
tion System" .
ConditionABS warning
lampVDC OFF indi-
cator lampSLIP indicator
lampBrake warning
lamp (Note 1)Remarks
Ignition switch OFF. — — — — —
Approx. Within 1 seconds
after ignition switch is turned
ON.×××× (Note 1) —
Approx. 1 seconds after igni-
tion switch ON.———× (Note 1)Turns OFF 2 seconds
after engine starts.
VDC OFF switch is turned
ON. (VDC function is OFF.)—×—— —
VDC/TCS/ABS error.××——There is a malfunction
in VDC/TCS/ABS con-
trol unit, SLIP indicator
lamp turns off (when the
power supply or ground
circuits return an error).
×××——
When VDC/TCS is not func-
tioning normally.—××——
EBD error.××××—

BRC-104
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
2. Make sure lamp turns off approximately 1 second after the ignition switch is turned on. If the lamp does
not turn off, conduct self-diagnosis.
3. With the engine running, make sure VDC OFF indicator lamp turns on and off when VDC OFF switch is
turned on and off. If the indicator lamp status does not correspond to switch operation, check the VDC
OFF switch system. Refer to BRC-122, "
VDC OFF SWITCH" .
4. Make sure ABS warning lamp, VDC OFF indicator lamp, and SLIP indicator lamp turn off 2 seconds after
the engine is started. If ABS warning lamp, VDC OFF indicator lamp, and SLIP indicator lamp have not
turned off 10 seconds after the engine has been started, conduct self-diagnosis of the VDC/TCS/ABS
control unit.
5. After conducting the self-diagnosis, be sure to erase the error memory. Refer to BRC-96, "
HOW TO
ERASE SELF-DIAGNOSIS RESULTS"

TROUBLE DIAGNOSIS FOR SYSTEM
BRC-107
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2006 November2007 350Z
Engine SystemNFS0004E
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK ENGINE SYSTEM
1. Conduct an ECM self-diagnosis and repair or replace any non-standard items. Re-conduct the ECM self-
diagnosis.
2. Re-conduct VDC/TCS/ABS control unit self-diagnosis.
OK or NG
OK >> INSPECTION END
NG >> Repair or replace any non-standard items. Re-conduct the self-diagnosis.
VDC/TCS/ABS Control Unit 1NFS0004F
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> Replace VDC/TCS/ABS control unit. Re-conduct the self-diagnosis.
NO >> INSPECTION END
Self-diagnosis results
ENGINE SIGNAL 1
ENGINE SIGNAL 2
ENGINE SIGNAL 3
ENGINE SIGNAL 4
ENGINE SIGNAL 5
ENGINE SIGNAL 6
Self-diagnosis results
CONTROLLER FAILURE

BRC-108
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: 2006 November2007 350Z
Pressure Sensor SystemNFS0004G
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK STOP LAMP SWITCH CONNECTOR
1. Disconnect stop lamp switch connector and VDC/TCS/ABS control unit connector and check the termi-
nals for deformation, disconnection, looseness, and so on. If there is an error, repair or replace the termi-
nal.
2. Securely reconnect the connectors.
3. Start engine.
4. Repeat pumping brake pedal carefully several times, then perform self-diagnosis again.
Is the result of self-diagnosis normal?
YES >> The connector terminal contact is loose, damaged, open or shorted.
NO >> GO TO 3.
3. CHECK STOP LAMP SWITCH
1. Turn ignition switch OFF and disconnect stop lamp switch con-
nector E111.
2. Disconnect stop lamp switch connector
3. Check continuity between stop lamp switch connector terminal 3
and 4.
OK or NG
OK >> GO TO 4.
NG >> Replace stop lamp switch. Refer to BR-8, "
Components" .
Self-diagnosis results
PRESS SEN CIRCUIT
Stop lamp switch Condition Continuity
3 – 4Release stop lamp switch
(When brake pedal is depressed.)Ye s
Push stop lamp switch
(When brake pedal is released.)No
SFIA3390E

TROUBLE DIAGNOSIS FOR SYSTEM
BRC-111
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2006 November2007 350Z
Yaw Rate/Side G Sensor SystemNFS0004I
CAUTION:
Sudden turns (such as spin turns, acceleration turns), drifting, etc. When VDC function is OFF (VDC
OFF switch ON) may cause the yaw rate/side G sensor system indicate a problem. However this is not
a problem if normal operation can be resumed after restarting the engine.
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
CAUTION:
When on a turntable, such as at a parking structure entrance, or when on a moving object with the
engine running, the VDC OFF indicator lamp might turn on and the self-diagnosis using the CONSULT-
III the yaw rate sensor system might be displayed, but in this case there is no problem with the yaw
rate sensor system. As soon as the vehicle leaves the turntable or moving object, restart the engine to
return the system to normal.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK CONNECTOR
1. Disconnect yaw rate/side G sensor connector and VDC/TCS/ABS control unit connector and check the
terminals for deformation, disconnection, looseness, and so on. If there is an error, repair or replace the
terminal.
2. Reconnect the connectors and then preform self-diagnosis.
Is the result of self-diagnosis normal?
YES >> The connector terminal contact is loose, damaged, open or shorted.
NO >> GO TO 3.
Self-diagnosis results
YAW RATE SENSOR
SIDE G-SENSOR

TROUBLE DIAGNOSIS FOR SYSTEM
BRC-119
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2006 November2007 350Z
Stop Lamp Switch SystemNFS0004M
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK CONNECTOR
1. Disconnect stop lamp switch connector and VDC/TCS/ABS control unit connector and check the termi-
nals for deformation, disconnection, looseness, and so on. If there is an error, repair or replace the termi-
nal.
2. Securely reconnect the connectors.
3. Start engine.
4. Repeat pumping brake pedal carefully several times, then perform self-diagnosis again.
Is the result of self-diagnosis normal?
YES >> The connector terminal contact is loose, damaged, open or shorted.
NO >> GO TO 3.
3. CHECK STOP LAMP SWITCH
1. Turn ignition switch OFF and disconnect stop lamp switch con-
nector E111.
2. Disconnect stop lamp switch connector
3. Check continuity between stop lamp switch connector terminal 3
and 4.
OK or NG
OK >> GO TO 4.
NG >> Replace stop lamp switch. Refer to BR-8, "
Components" .
Self-diagnosis results
STOP LAMP SW
Stop lamp switch Condition Continuity
3 – 4Release stop lamp switch
(When brake pedal is depressed.)Ye s
Push stop lamp switch
(When brake pedal is released.)No
SFIA3390E
