BL-112
TRUNK LID
Revision: 2006 November2007 350Z
Removal and Installation of Trunk Lid HingeNIS0002J
REMOVAL
1. Remove trunk lid stay. Refer to BL-109, "Removal and Installation of Trunk Lid Stay" .
2. Remove trunk lid assembly. Refer to BL-108, "
Removal and Installation of Trunk Lid Assembly" .
3. Remove trunk lid hinge mounting bolts, and then remove trunk
lid hinge.
INSTALLATION
1. Position trunk lid hinge to body side. Temporarily tighten front side bolt and rear side bolt in this order, and
then tighten them to the specified torque.
2. Install trunk lid to trunk lid hinge.
3. Install trunk lid stay.
CAUTION:
Before installing trunk lid hinge, apply anticorrosive agent onto the mounting surface of the vehi-
cle body.
After installation, perform trunk lid fitting adjustment. Refer to BL-107, "Fitting Adjustment" .
Check trunk lid open/close operation after installation.
Apply sealant and the same body color paint to trunk lid hinge and mounting bolts to cover broken
seal area.
Removal and Installation of Lift SpringNIS0002K
REMOVAL
Rotate lift spring bottom clockwise/counterclockwise by approxi-
mately 90 deg, and then remove lift spring.
INSTALLATION
Install in the reverse order of removal.
PIIB1181E
PIIB1180E
TRUNK LID
BL-113
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
Removal and Installation of Trunk Lid WeatherstripNIS0002L
REMOVAL
Pull up and remove engagement with body from weatherstrip joint.
CAUTION:
After removal, do not pull strongly on the weatherstrip.
INSTALLATION
Install in the reverse order of removal.
1. Install the weatherstrip from the front with the vehicle center mark aligned to the weatherstrip mark.
2. At rear side, align the weatherstrip seam to the center of the striker.
3. After installing, pull the weatherstrip lightly to check for looseness.
CAUTION:
The weatherstrip should fit tightly onto the corners and trunk lid rear plate.
1. Storage lid 2. Trunk lid assembly 3. Trunk lid weatherstrip
4. Rear bumper fascia
PIIA7604E
